Zonelines are packaged room air conditioners that provide cooling and heating for residential and
commercial properties. Available in 7,000, 9,000, 12,000 and 15,000 BTU models. Accessories are available to
duct conditioned air into an adjoining room.
cases.
Operation is similar to previous models, but with a totally new electrical and mechanical design.
Features
Example of features of a AZ65H09DAM with Make Up Air Module:
• Makeup Air: Supplies 35 CFM of continuous, conditioned fresh make up air
• Cooling Capacity: 9,100 BTU @ 230 volts – 8,800 BTU @ 208 volts
•
• : Conditions incoming air above 55% relative humidity
• Reverse Cycle Heat: 8,300 BTU @ 230 volts – 8,100 BTU @ 208 volts
•
• Quiet Operation
• Heat and Freeze Sentinels: Prevents room from over-heating or freezing
• Boost Heat Option: Provides supplemental resistance heat during heat pump mode
• Electronic Temperature Limiting: Prevents over-cooling or over-heating of room
• Electronic Touch Controls: Tactile buttons with LED display

Introduction

: 3.7 COPS
