Latest Production Wiring Diagram
Later production Zonelines utilize a thermal cut-out that looks like the image shown. This
wiring diagram depicts how this cut out is wired into the circuit. NOTE: If this cut out opens,
the compressor will be totally "inoperative". Be sure to check this cut out before replacing the
compressor.
