Camera Introduction; Set Up The Camera - Reolink Argus PT Lite Quick Start Manual

Camera Introduction

1
2
3
7
8
4 6
5
9
10
11
Different states of the status LED:
Red Light: WiFi connection failed
Blue Light: WiFi connection succeeded
3 English
Lens
1
6 IR LEDs
2
Daylight Sensor
3
Built-in PIR Sensor
4
12 Built-in Mic
5
Status LED
6
13
Speaker
7
Reset Hole
8
* Press for more than five seconds to
restore the device to default settings.
Micro SD Card Slot
9
* Rotate the camera's lens to find the
reset hole and the SD card slot.
Power Switch
10
Antenna
11
Charging Port
12
Battery Status LED
13
Blinking: Standby status
On: Working status

Set up the Camera

Set up the Camera Using a Smartphone
Step 1 Scan to download the Reolink App from the App Store or Google Play store.
Step 2 Turn on the power switch to power on the camera.
English 4
