Duct connections
On the top of the unit a sticker indicating the connections
of the Combi has been fitted.
Supply Air
The ducting system leading from the unit to the rooms of
the house.
Extract Air
The ducting system leading from the house wet rooms to
the unit.
Incoming Air
The ducting system leading from the fresh-air roof cowl/
fresh-air grating outdoors to the unit.
Discharge Air
The ducting system leading from the discharge air roof
cowl/discharge air grating to the unit.
Top view
Discharge air
Supply air
Incoming Air
Extract air
Front
9
