Optimal Fine-Tuning of the System

Use air-measuring equipment. Check that all 5 items in the
section above have been carried out before performing the
fine-tuning. Then put the system into operation.
Set up the system for basic ventilation, i.e. speed 2. To
reduce energy consumption as much as possible, first
adjust the overall atmospheric volume to the desired level
by changing the speed settings in the Service Menu.
Then fine-tune the supply air and extract air valves with the
air-measuring equipment. Remember to lock the valves
when performing the fine-tuning and to turn the conducting
plate on the supply air valves so that air blows in the right
direction.
Finally, recheck and fine-tune the overall atmospheric vol-
ume by adjusting the speeds for Step 2 in the Service Menu.
Then adjust Step 1 and Step 3 to an appropriate interval in
relation to Step 2.
Please be aware that the airflow required during heatpump
operation can differ from when only ventilation is required.

Requirements to the Hot Water Circuit

The following materials can be used for the hot water in-
stallation:
• Copper
• Stainless steel
• Brass
• Synthetic materials
This naturally depends on the materials that have already
been used in the water circuit (of the dwelling). Incorrect
material combinations may result in corrosion damage.
This requires particular attention when
galvanised components and
components containing aluminium are used.
14

Initial Operation of the Water Circuit

• Fill the tank via the connector spigot and then air it out by
leaving one of the uppermost hot water spigots open until
no more air comes out.
• Recheck the entire water circuit for leaks.
• Connect the unit to the mains.
Inspect all connections of the water circuit for leaks after
start-up.

Cooling Circuit

The unit is delivered as a preassembled unit. No work needs
to be done on the cooling circuit. The control unit will
automati- cally assume control of all functions and start up
the compressor, fan, etc. in order to maintain the set water
temperature.
