  • Page 1 Gebrauchsanweisung User Manual Optima 300 Varmepumpe Wärmepumpe Heat pump Version 3,02 / 0107...
  • Page 2 1.7 Skema for setpunkter ..11 1.7 Factory default scheme ...44 . Funktion . Funktion . Function 2.1 Controller Optima 300 ..45 2.1 Styring Optima 300 ..1 2.1 Steuerung Optima 300 ..8 2.2 Zusätzliche Funktionen..8 2.2 Ekstra kapacitet ....1 2.2 Extra capacity ....45 2.3 Driftsikkerhed....1...
  • Page 3: Altering Of The Operation Data

    Use this button to change fan speed between low, medium and high. (Level 1, Level 2, Level 3). Optima 300 comes with a factory setup, which enables an To stop the unit press this button 3 - 4 seconds immediate start of the unit. The factory setup is basic and until all levels are switched off.
  • Page 4: Operating Menu

    Optima 300 By pressing “OK”, the control system reverts to the main 7: Cooling menu and the text changes to English. Now all text in To prevent cooling switching in as soon as there is no further need for heat, please set the °C room temperature the display appear in English.
  • Page 5 Genvex logo will begin to flash on the control panel and point to 0.0. If the set point is adjusted to 0,1, the the words “change filter”...
  • Page 6 Optima 300 23: Airflow 3 SUP 30: Clock minute Level 3 is the highest speed and is in use when having Adjust the set point to the relevant number of minutes. many guests, when airing the room, having major activity...
  • Page 7 Optima 300 38: Default values 44: Program info The set point is always 0. If you press OK; the display will Please notice: before resetting the values please show the installed program version for the heat pump. At ensure that the actual set points are noted in the the same time, an automatic exit will be made from the scheme page 43.
  • Page 8 Optima 300 it may be necessary to change this temperature. The temperature may be set between 0 - 10°C. 51: Temp dif. As standard the temperature difference between start- stop compressor is ±0,4°. Under special conditions, it will be an advantage to change the temperature difference.
  • Page 9 Optima 300 1.4 Week program scheme Monday Tuesday Wednesday Hours Minutes Red. T Hours Minutes Red. T Hours Minutes Red. T Thursday Friday Saturday Hours Minutes Red. T Hours Minutes Red. T Hours Minutes Red. T Sunday 1.5 Defrosting program...
  • Page 10: Special Functions

    Optima 300 1.6 Special functions Summertime: Changing the clock between summer- and wintertime is done by simultaneously pressing “Enter” together with “Arrow Up” or “Arrow Down”. This will change the clock hour by 1 hour in the desired direction. Contrast adjustment: Contrast of the display can be changed by pressing the “Info”...
  • Page 11: Factory Default Scheme

    Optima 300 1.7 Factory default scheme Headline Default values Set point range Date: Date: Date: Date: Language 0 -  Room temperature 10.0°c - 30.0°C Not in use Not in use Not in use Cooling ON 0 / 1 Cooling 3 - 10 Min.
  • Page 12 “change filter” and in the operating menu). When cooling begins, the supply the red Genvex logo will flash until the filters has been and extract air fans will switch to speed 3 and the cooling valve MA 7 will open, so that the condenser on the supply changed.
  • Page 13: Maintenance

    Careful handling of the plates is required. They 3.1 Connecting to computer have sharp edges and must not be damaged. In order for the optima 300 to communicate with the Condensate drain: computer (data logger) the communication box “Genvex When changing the filters in the autumn season check data logger”...
  • Page 14: Fault Finding

    Optima 300 4. Fault finding 4.3 Air faults The unit is equipped with the following safety systems: No supply air to living rooms: Error: • Defective fan Blocked bag filter 4.1 High pressure switch • • Fresh air grill blocked by dirt and leaves in the To prevent the compressor exceeding its range of autumn or snow and ice in the winter.
  • Page 15: Electric Diagram

    Optima 300 Electric diagram 1200W 1200W 0-10V +10V 0V 0-10V Controller panel Pressostat Hygrostat 100nF X2 100nF X2 Tekniske ændringer forbeholdes - Technische Änderungen vorbehalten - Subject to Technical Modifications - 830209G/160228...
  • Page 16 Optima 300 6 Flow diagram VP - GE 315 / 40 / 55 / 630 / 840 VP Fresh Air Extract Air Evaporator (cooling coil Condenser (heating coil) Heat exchanger Exhaust Air Supply Air Control panel High pressure switch Compressor...
  • Page 17 Optima 300 8. Flow diagram - GE Mini / Midi - C Evaporator (cooling coil) Extract Air Exhaust air Condenser (heating coil) Fresh air Supply air Controller panel High pressure switch Compressor Tekniske ændringer forbeholdes - Technische Änderungen vorbehalten - Subject to Technical Modifications -...
  • Page 18 Tel.: + 43 (0) 463 / 3 27 69 Tel.: (UK 028) (ROI 048) +44 2076 8708 Fax: +43 (0) 463 / 3 75 48 Fax: (UK 028) (ROI 048) +44 2076 9781 E-Mail: office@pichlerluft.at E-Mail: info@ecosystemsireland.com Technische Angaben ohne Gewähr © Genvex www.genvex.dk...
