  • Page 1 Installation Manual · Vanvex R Domestic water heat pump Version V6.01 - 0408...

  • Page 2: Table Of Contents

    Table of Contents ABOUT THE PRODUCT ........3 Scope of delivery ..........3 Product description ..........3 Technical data ............3 1.4. Refrigerant circuit – description ......3 1.4.1 Cooling system - description ........ 3 1.4.2 Electrical circuit - description ........ 3 1.4.3 Water circuit – description ........3 1.4.4 Requirements circuit ..........4 Water circuit - description ........5...

  • Page 3: About The Product

    1.2 Product description in gaseous form and fed to the compressor. In the compressor, Vanvex R is a domestic water heat pump with a condenser the refrigerant is raised up to a higher pressure and energy on the outside of the tank. The application area and...

  • Page 4: Requirements Circuit

    1.4.4 Refrigerant circuit Component overview No.: Description Compressor Condenser Vaporiser Centrifugal fan Expansion valve Drying filter Pressure switc Magnitic valve One way valve - The right to make changs is reserved -...

  • Page 5: Water Circuit - Description

    This requires special attention with the use of galvanised components and components that contain copper SECTION A-A Vanvex R: Supply air Exhaust air Circuit board Condensate drain...

  • Page 6: Water Circuit - Hydraulics Diagram

    Installation Manual 1.5.3 Water circuit – hydraulics diagram varmt vand warm water Warmwasser cirkulation circulation Zirkulation til sikkerhedsventil to safety valve nach Sicherheitsventil tilslutning koldt vand cold water connection Kaltwasseranschluss tømning draining Entleerung 1 - Main valve 2 - Reducing valve 3 - Test valve 4 - Contra valve 5 - Manometer adapter...

  • Page 7: Electrical Schematic

    Installation Manual 1.6. Electrical shematic PC-COM T1.6AH - The right to make changs is reserved -...

  • Page 8: Before Installation / Placement Into Service

    Safety equipment must be installed to prevent over pressure 2. Remove the transport fittings from the pallet. in the system. 3. Take the Vanvex R off the pallet and place it at the All pipe work must comply with water safety regulations. desired location. Adjust the Vanvex R vertically by adjusting the feet.

  • Page 9: Connection Of Water Pipes

    Installation Manual 2.6 Connection of water pipes During installation the actual pressure and pressure losses must be taken into account regarding pipe dimensions to assure sufficient pressure and water flow rates. The plumbing must be carried out according to regulations. The piping can be made of flexible or solid materials. Care must be taken in respect to corrosion to avoid damages. As for all pressurerized containers the heat pump must also be equipped with safety and check valves on the supply side.
  • Page 10 Installation Manual 4. Removal of product: 7. Removal of 1st piece of wood (can be released if product a: Glide product carefully to one side a bit. bowed a bit to one side). b: Bow over to the same side together with 2 pcs. of wood beneath.

  • Page 11: Installation

    3.4 Air intake and exhaust possibly a filter. As for all pressure vessels, the Vanvex R’s connections must Make sure that there is sufficient free-space around the also be equipped with an approved safety valve on the service Vanvex R.

  • Page 12: Placement Into Service / Operation

    Installation Manual 4. Placement into service / 4.6 Hints for energy savings operation Do not set the water temperature higher than necessary. The best utilisation of the Vanvex Lite occurs at low water The heat pump may only be started with a full water tank! temperatures.
  • Page 13 Note - The right to make changs is reserved -...
  • Page 14 Note - The right to make changs is reserved -...
  • Page 15 - The right to make changs is reserved -...
  • Page 16 Fax: +386/ (0) 2/460 13 55 E-Mail: pichler@pichler-co.si Switzerland SM-HEAG Klimatechnik AG CH-8307 Effretikon Tel.: +41 (0) 52 / 355 11 00 Fax: +41 (0) 52 / 355 11 05 Published by Genvex A/S, Sverigesvej 6, DK-6100 Haderslev E-Mail: info@sm-heag.ch www.genvex.dk...
