- Page 1 PX838 LED Lamp Splitter User manual...
-
Page 2: Table Of Contents
3 Connector description................5 4 Connection scheme...................7 5 Dimensions....................9 6 Technical data..................10 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-0 BDO register number 000005972 www.pxm.pl... -
Page 3: Description
Description PX838 is a device that allows you to connect many LED lamps to one power supply and DMX controller. It is adapted to connect 4 lamps. If all output connectors are not occupied in the LED splitter, jumpers should be used between the pins of the DMX control signal. -
Page 4: Safety Conditions
Safety conditions The PX838 device was created to distribute the 24V DC power supply and the control signal to the PX837 lamps, however, during its installation and use, the following rules must be strictly observed: 1. The device may only be connected to 24V DC. -
Page 5: Connector Description
Connector description DMX + OUT DMX + IN DMX – OUT DMX – IN DMX GND OUT DMX GND IN V– OUT V– IN V+ OUT (24V DC) V+ IN (24V DC) NOTE! The exact connection diagram can be found in point 4. Connection scheme. - Page 6 NOTE! If all output connectors for PX837 lamps are not used on the distributor, you should short DMX – IN pins with DMX – OUT and DMX + IN with DMX + OUT pins. The diagram below shows only used 3 out of 4 output connectors.
-
Page 7: Connection Scheme
Connection scheme PX837 lamp PX837 lamp PX837 lamp DMX in DMX out power supply IN power supply OUT 24V DC 24V DC PX837 lamp... - Page 8 NOTE! Up to 32 PX837 lamps can be connected on one DMX line. Example combinations (max. 32 lights on the DMX line): • 8 splitters with 4 lamps each (32), 10 splitters with 3 lamps each (30), • 3 splitters with 4 lamps each + 4 splitters with 3 lamps each + 4 •...
-
Page 9: Dimensions
Dimensions... -
Page 10: Technical Data
Technical data type PX838 number of lamp outputs housing plastic number of cable gland IP class IP65 color black weight 0.3kg width: 94mm dimensions height: 94mm depth: 57mm... - Page 11 Podłęże, 03.08.2023 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: LED Lamp Splitter Product code: PX838 meets the requirements of the following standards, as well as harmonised standards: PN-EN IEC 63000:2019-01...
