- Page 1 PX949 Splitter DMX-RDM User manual...
-
Page 2: Table Of Contents
8 Device update.....................12 9 Connection scheme..................13 10 Dimensions....................14 11 Technical data..................15 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-0 BDO register number 000005972 www.pxm.pl... -
Page 3: Description
DMX track using a splitter was created. With the PX949 you can split the input DMX signal into 4 independent branches. The individual output lines are galvanically separated from both the input and from each other. -
Page 4: Safety Conditions
Safety conditions PX949 s a device powered with safe voltage up to 12 – 24V DC; however, during its installation and use the following rules must be strictly observed: 1. The device may only be connected to 12 – 24V DC (stabilized voltage) with current-carrying capacity compatible with technical data. -
Page 5: Connectors And Control Elements
Connectors and control elements DMX OUT 2 DMX OUT 4 DMX OUT 1 DMX OUT 3 signal diodes PX949 Splitter DMX-RDM programming keys DMX THRU DMX IN power supply 12 - 24V DC... -
Page 6: Connecting The Dmx Signal
IN connector on the PX949 and then from the DMX THRU connector to the next DMX receivers. If the PX949 is the last device in the DMX line (there is no receiver connected to the DMX THRU output), there should be a terminator – a 120 Ohm resistor –... - Page 7 Splitter PX949 PX949 Splitter DMX-RDM max. 4 splitters in cascade Splitter PX949 Splitter PX949 PX949 PX949 Splitter DMX-RDM Splitter DMX-RDM max. 32 devices (including splitters) RDM Controller, i.e.: PX218 DMX line...
-
Page 8: Indicator Lights
Indicator lights There are diodes on the device housing that indicate the operating status of the device. Action Function the device does not receive the DMX all diodes flash every ~3s signal all diodes flash every ~1s the device receives a DMX signal Meaning of diode colors green bypass... -
Page 9: Output Operating Mode
NOTE! The operating modes can be changed using the button located on the housing. An example of changing the operating mode is on the next page. * – depending on the number of input channels – PX949 recognizes how many DMX channels are received... - Page 10 Example of changing the operating mode of output number 3 from filtering mode to bypass mode: 1. The diodes flash every ~1s or every ~3s (depending on whether there is a DMX input signal). 2. Press the button for ~2s. 3.
-
Page 11: Factory Settings
11. Clicking the button changes the mode. 12. After changing the mode, press and hold the button for ~2s. 13. The third LED flashes, the others light up. 14. At this point you can repeat the steps for the other output by returning to point 6 or leave the device for ~10s –... -
Page 12: Device Update
Device update The update is possible using the PX313 USB/RS485 In device – details can be found in the manual for this module. The device update was also presented in detail on our YouTube channel. https://www.youtube.com/watch?v=TKBV03szddU... -
Page 13: Connection Scheme
Connection scheme PX715 4x700 mA/48V Splitter DMX-RDM PX715 4x700 mA/48V terminator PX949 PX715 4x700 mA/48V terminator RDM Controller i.e.: PX218 next devices DMX terminator connected in the last device... -
Page 14: Dimensions
10 Dimensions PX949 Splitter DMX-RDM... -
Page 15: Technical Data
11 Technical data type PX949 power supply 12 – 24V DC DMX channels (IN = OUT) 24 – 512 number of DMX inputs number of DMX outputs number of modes 3 (filtering / bypass / normal) RDM protocol support yes (in "normal" mode) - Page 16 Podłęże, 16.01.2025 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: Splitter DMX-RDM Product code: PX949 meets the requirements of the following standards, as well as harmonised standards: PN-EN IEC 63000:2019-01...
