- Page 1 PX165 DMX Splitter MANUAL...
-
Page 2: Table Of Contents
Declaration of conformity................The manufacturer reserves the right to change the operation and handling of the controller in order to improve the product. PXM Marek Żupnik spółka komandytowa tel.: 12 385 83 06 fax: 12 626 46 94 Podłęże 654 E-mail: info@pxm.pl... -
Page 3: General Description
The PX165 Splitter is manufactured in a casing for 35 mm DIN rails mounting. 2. SAFETY CONDITIONS PX165 DMX Splitter is a device powered with safe voltage 12-24 V; however, during its installation and use the following rules must be strictly observed: 1. -
Page 4: Dmx Signal Connection
RX+ RX- TX+ TX- VCK+ SYNC PX340 When the PX165 DMX splitter is the last device in a DMX line, pins are supposed to be REMOTE 1 2 3 4 6 7 8 10 11 12... - Page 5 DMX terminator (last device) DMX splitter PX165 PX165 + + + – – – 12-24V DC 120R DMX controller, e.g.: PX340 RX+ RX- TX+ TX- VCK+ SYNC next devices PX340 REMOTE 1 2 3 4 6 7 8 10 11 12...
- Page 6 15A max OUTPUT: OUTPUT: INPUT: 7-24VDC INPUT: 7-24VDC 15A max 15A max OUTPUT: OUTPUT: DMX splitter DMX splitter PX165 PX165 PX165 PX165 + + + – – – + + + – – – 12-24V DC 12-24V DC 120R 120R max.
-
Page 7: The Terminator
3.2. The terminator PUSH 120 Ohm resistor 3.3. Rules for creating DMX connections 1. To connect the devices application of the microphone cable is strictly recommended (two strands in a shield). 2. The devices have to be connected in series. 3. -
Page 8: Technical Specification
5. TECHNICAL SPECIFICATION - DMX line optical isolation yes (1000 V VDC) - DMX signal input clamping screws - DMX signal outputs clamping screws - power supply 12-24 V DC - current consumption 500 mA max. - dimensions: - width 105 mm - heigth 86 mm... -
Page 9: Declaration Of Conformity
30-701 Kraków, Poland fax: +48 12 626 46 94 DECLARATION OF CONFORMITY according to guide lines 2004/108/EC and 2006/95/EC PXM Marek Żupnik spółka komandytowa Name of producer: ul. Przemysłowa 12 Manufacturer’s address: 30-701 Kraków, Poland We declare that our product:...
