Overview of machine software functions (firmware)

The table below provides information about the relevant functionality of the interface machine software
(firmware).
Machine soft-
ware number
(firmware)
0.0.1.0
0.0.2.0
0.0.3.0
0.0.5.0
0.0.6.0
0.0.7.0
099-000769-EW501
04.10.2022
Overview of machine software functions (firmware)
Item number Hardware
platform
042-00973-00000
042-00973-00001
042-00973-00001
042-00973-00001
042-00973-00001
Tetrix XQ / Titan XQ / Phoenix XQ system
Function
00 Initial version
00 Range of metallurgical pulsing extended to cover
50 Hz to 15 kHz. This function is only guaranteed if
01
the version of the Tetrix power source software is at
least 0.2.D.0.
With older software versions, it will be scaled auto-
matically for the range up to 2500 Hz.
02 superPuls and lift arc signals for Phoenix/alpha Q
power sources from version 0.6.5.0 and MM
tigSpeed ON signal for Tetrix/forceTig systems
Advanced JOB selection for MM systems
Optional control voltages for hot wire, oscillation or
filler wire down-slope value
Latched modes implemented for the operating mode
02 Tandem signal problem.
Fix for tigSpeed® control voltage.
Fix for job default signal.
Fix for actual current output.
02 Support for machine series Titan, Phoenix and
Tetrix XQ
Adaptation to average value pulsing.
Selection for automated pulsing.
Support of the extended job selection.
