7.1

Operating modes, start, machine functions

Digital inputs (X5, 8-pole; X10, 12-pole)
Pin no.: Function/
Meaning
X5/1 0V4
X5/2
+24V1
X5/3 Special non-
latched mode
X5/4 Special non-
latched mode
X5/5 Pulsing/standard
X5/6 ext. start 1
X5/7 ext. start 2
Tandem switching
[3]
X5/8 Lift arc On
tigSpeed On
X10/1 0V4
X10/2 24V1
X10/3 Enable start
X10/4 Control voltage
X10/5 Gas test 1
X10/6 Gas test 2 (blow
out)
X10/7 Inching / motor on Digital input
X10/8 Position search
X10/9 Inching function
X10/10
Reverse inching
X10/11 Motor on
X10/12
n.c.
Function of the MIG/MAG pulsing process for devices of the Titan XQ / Phoenix XQ / Phoenix /
(1)
alpha Q series; function of DC pulsing or AC pulsing for devices of the Tetrix XQ / Tetrix / forceTig
series (depending on the process polarity).
Only for Tetrix XQ, Tetrix and forceTig machine series.
[2]
Only for Titan XQ, Phoenix XQ, Phoenix and alpha Q machine series.
[3]
099-000769-EW501
04.10.2022
Overview of plug (jumper) configurations
Signal form for
RINT X12
Digital input
Digital input
Digital input
Digital input
Digital input
[2]
optional
Digital input
[3]
[2]
Digital input
Digital input
Digital input
Digital input
Digital input
Digital input
Digital input
Digital input
[2]
Operating modes, start, machine functions
Standardisation / logic
> see 5.3.4 chapter
> see 5.9 chapter
Active = Pulsing
[1]
Active = welding process start
Active = start auxiliary process
Active = master power source
assignment
[3]
Aktive = lift arc On or tigSpeed
On
Active = release process
> see 5.3.4 chapter
Active = gas test 1 on
Active = gas test 2 on (blow out
machine)
Active = inching/motor on
Active = position search on
Active = continuous inching
Active = reverse inching
Active = switch on cold wire mo-
tor
[2]
