Inching mode

Two different welding wire inching modes are available which can be pre-defined on the RINT X12 by
means of jumper JP8.
Alternatively, the signal can be activated by an external signal:
JP8 1) Operating mode
Inching is performed by means of a ramp function
-
can be overridden by the external X10/9 signal.
(factory setting)
X Inching is always performed at a constant speed
X10/9 signal required.
The constant inching speed can be reconfigured with the EWM Config Tool to enable setting the speed
1)
based on the WF specification (control voltage).
This mode is available in the MAG system operating mode only.
The wire is inched for 2 seconds continuously at 1 m/min and then moved at 6 m/min for 6 seconds.
2)
Inching speed then remains at this final value. The final value depends on the cold wire drive used.
The wire is moved continuously at 3 m/min.
(3)
5.3.4

Operating modes

With jumpers JP9 and JP10 the individual operating modes can be set as a fixed value.
JP9/X5/3
-
-
X
X
Alternatively, the operating mode can also be actuated via the external signals X5/3 and X5/4.
The factory settings are such that JP9 and JP10 are not set.
14
Operating mode with
JP10/X5/4
latched modes disa-
bled
- Non-latched
X Non-latched
- Non-latched
X Special non-latched
. This function
2)
, no external
3)
Operating mode with
latched modes ena-
bled
Non-latched
Latched
Special latched
Special non-latched
