EWM RINTX12 STANDARD Operating Instructions Manual page 22

Design and function
Control signal operation
Process System
type
MIG/MAG
[1]
MIG/MAG
[1]
MIG/MAG
[1]
TIG
[2]
TIG
[2]
TIG
[2]
TIG
[2]
TIG
[2]
TIG
[2]
All
[1] / [2]
All
[1] / [2]
The lowest value that can be set for the cold wire depends on the machine's equipment and the cold
(1)
wire drive in use.
Only for Titan XQ, Phoenix XQ, Phoenix and alpha Q machine series.
[1]
Only for Tetrix XQ, Tetrix and forceTig machine series.
[2]
The lowest value that can be set for the cold wire depends on the equipment and the cold wire drive
(3)
used.
Depending on the software version of the interface and the power source, the following scaling is pos-
[4]
sible: 0...10 V corresponds to 50 Hz to 2500 Hz or 0...10 V corresponds to 50 Hz to 15000 Hz
( > see 7.4 chapter, > see 9 chapter).
22
Input Parameter
X6/3 Wire feed speed
X6/4 Arc length
correction
X6/5 Dynamic correction
X6/3 Welding current nomi-
nal value
X6/4 Cold wire nominal
value
X6/5 Nominal value of the
secondary current for
pulse modes
X6/6 Nominal value for the
pulse time/frequency,
depending on the pulse
mode
Nominal value for the
X6/7
pause time/balance,
depending on the pulse
mode
Depending on the con-
X6/8
figuration, nominal
value for hot wire, hot
wire oscillation fre-
quency or filler wire
down-slope value
X6/1 +10 V signal reference
X6/2 0 V signal reference
Standardisation
0..10 V equivalent to 0 to maximum
value in m/min according to the chosen
nominal value standardisation
0..10 V equivalent to –9.9 V to +9.9 V,
5 V equivalent to 0 V
0..10 V equivalent to –40 to +40,
5 V equivalent to 0
0..10 V equivalent to 0 to maximum
value in A according to the chosen nomi-
nal value standardisation
0..10 V equivalent to 0 to 10.0 m/min
24.0 m/min
0 to 5.00 m/min
(cf. configuration data)
0..10 V equivalent to 0 to maximum
value in A according to the chosen nomi-
nal value standardisation
Thermal pulsing:
0..10 V equivalent to min. freq. to max.
freq.
Pulse length
Metallurgical pulsing
[4]
Thermal pulsing:
0..10 V equivalent to 0.01 s to 10.00 s
pause length
Metallurgical pulsing
0..10 V equivalent to 1% to 100%
Hot wire:
0..10 V equivalent to 0 to hot wire scal-
ing definition
Oscillation:
0..10 V equivalent to 0.1 Hz to 16.0 Hz
Filler wire down-slope value:
0..10 V equivalent to 0 to 10.0 m/min or
24.0 m/min
0 to 5.00 m/min
(cf. configuration data)
---
---
099-000769-EW501
or
[3]
04.10.2022
