5.13.2 TZ-Set

To specify the duration of the stable arc burn time, the parameter TZ-Set was defined. If the arc burns
stably in the ignition phase for this period, the signal I>0 is stored.
Legend
Description
A
Start signal
B Internal start
C Ignition time elapse
D Ignition error message
E
Automatic cut-out
099-000769-EW501
04.10.2022
Design and function
Signals for matching with the positioning device
Figure 5-4
