Design and function
Standard signals for free actuation
5.5.2

Start auxiliary process

This signal can be used to activate the auxiliary arc for TIG welding systems with plasma equipment.
X5/7
Signal active The auxiliary process is activated.
Signal not
active
Only for Tetrix XQ, Tetrix, forceTig, RINT X12 machine series.
[1]
5.5.3

Pulse mode

This signal switches between standard and pulse welding in MIG/MAG processes
X5/5
Signal active
Signal not active
Only for Titan XQ, Phoenix XQ, Phoenix and alpha Q machine series.
[1]
16
Operating mode
Any auxiliary process running is ended.
Operating mode
Pulse welding activated.
Standard welding activated.
.
[1]
