Intended use

Applications

3 Intended use
Hazards due to improper usage!
The machine has been constructed to the state of the art and any regulations and stand-
ards applicable for use in industry and trade. It may only be used for the welding proce-
dures indicated at the rating plate. Hazards may arise for persons, animals and material
objects if the equipment is not used correctly. No liability is accepted for any damages
arising from improper usage!
• The equipment must only be used in line with its designated purpose and by trained or ex-
pert personnel!
• Do not improperly modify or convert the equipment!
The manufacturer's warranty becomes void if non-genuine parts are used!
• Only use system components and options (power sources, welding torches, electrode hold-
ers, remote controls, spare parts and replacement parts, etc.) from our range of products!
• Only insert and lock accessory components into the relevant connection socket when the ma-
chine is switched off.
3.1 Applications
3.1.1

Automation

Automated, robot-controlled welding production with the digital robot power sources.
3.2

Revision

Revision
1.0
1.1
1.2
1.3
1.4
3.3

Use and operation solely with the following machines

RINT X12
8
Date Change
XX.XX.XXXX Draft version
01/03/2015 MAG, superPuls and lift arc signals, selection of advanced JOBs,
EWM Config function, latched modes,
Tetrix, additional control voltage, tigSpeed® activation
01/10/2017 Operating mode of spot welding added
18/10/2021 Chapters Operating modes, Start, Machine functions - order of contact
assignment X10/2 to X10/5 arranged
Notes - new formatting
27/09/2022 Machine series Tetrix XQ, Phoenix XQ, Titan XQ added
Tetrix 352, 452, 552
Tetrix 352 AC/DC
Tetrix 352 AC/DC AW
Tetrix 352, 452, 552, 1002 AW
Tetrix 152, 352, 552 Plasma
Tetrix 152, 352, 552 Plasma AW
forceTig 352 AC/DC
forceTig 552, 1002
WARNING
TIG
Phoenix XQ R 350 , 400, 500, 600 puls
Titan XQ R 350 , 400, 500, 600 puls
Titan XQ R 400 puls AC/DC D
alpha Q 352, 552
Phoenix 352, 452, 552, 1002 RC
Phoenix 552 RC Tandem
alpha Q 352, 552 MM
Phoenix 352, 452, 552, 1002 MM RC
Phoenix 552 MM Tandem
MIG / MAG
