5.3.5

Pulse process

With the JP11 jumper, a pulse process can be pre-defined on the RINT X12.
Alternatively, the signal can also be actuated by an external signal:
JP11 Operating mode
- Standard welding is active. This signal can be overridden by
the external X5/5 signal. (Factory setting)
Pulse welding is active; an external X5/5 signal is not neces-
X
sary.
In Tetrix / forceTig systems, thermal pulsing is controlled with this signal.
5.3.6

JOB selection

The RINT X12 can be permanently configured for the selection of JOBs,
or the signal can be activated by an external signal:
JP12 Operating mode
- JOBs are selected via external machines (e.g. JOB manager)
and the RINT X12 does not analyse the signals for the JOB
numbers. You can override this selection with the external sig-
nal X9/11. (factory setting)
X JOBs are selected via the RINT X12, the signals for the JOB
number are assumed from the RINT X12. No external X9/11
signal is required.
5.4

Special signals

In the following chapter special signals for configuration will be described, which are detected during the
start up phase of the RINT X12.
5.4.1

Configuration of special signals

Jumper X4/5 configures the type of use for the output signals of the relais K5 to K8.
X4/5
Signal active
Signal not active
This configuration applies only to RINT X12 Phoenix / alpha Q.
5.4.2

Advanced JOB mode

With jumper 13 the so-called advanced JOB mode is activated. In this mode, the information for operating
mode and welding type is no longer taken from the X5/3, X5/4 and X5/5 signals but from the information
relating to the respective welding program. This allows complex program sequences to be controlled. For
example, a process can be started with a start program but ended without an end program (or vice
versa).
The advanced JOB mode disables the input for control signal mode; the control signal mode can then no
longer be selected!
5.5

Standard signals for free actuation

The signals described below should be actuated using external signals as required. The signal to be cre-
ated is based on the pre-selection on the actuation logic.
5.5.1

Start process

This signal is used to activate the welding process according to the operating mode set:
X5/6
Signal active The welding process is activated.
Signal not
active
Start can only be given when the signal Enable Start is active!
099-000769-EW501
04.10.2022
Operation mode
The relais are used for process signals
The relais are used for process monitoring
Operating mode
Any welding process running is ended.
Design and function
Special signals
