Parameter
Lift arc signal enabling
Activate control voltage
X6/8
Control voltage X6/8
parameter
Control voltage scaling Value
Filler wire control sig-
nal scaling
Factory reset
099-000769-EW501
04.10.2022
Setting
Not enabled
Enabled
No
Yes
Hot wire
Oscillation
Filler wire down-slope value
10.0 m/min
24.0 m/min
Off
Configuration
Configuration data overview
Tetrix XQ / Titan XQ / Phoenix XQ system
Meaning
The lift arc start is controlled
by the JOB.
The lift arc start is controlled
by the input signal.
No analysis of the analog
channel.
The analog channel.is ana-
lysed based on the control
voltage selection.
The control voltage controls
the hot wire current.
The control voltage controls
the oscillation frequency for
tigSpeed.
The control voltage controls
the down-slope value of the
filler wire for thermal pulsing
mode.
Defines the input scaling for
the hot wire current.
Defines the scaling when se-
lecting the filler wire resolution
in the JOB.
The setting has no function.
The machine will be reset to
the factory settings, effective
on the next start of the ma-
chine.
Available
from SW
0.0.5.0
0.0.5.0
0.0.5.0
0.0.5.0
0.0.5.0
0.0.5.0
