Technical Support and E-Warranty Certificate
www.vevor.com/support
POWDER COATING MACHINE
USER MANUAL
We continue to be committed to offering tools at competitive prices. "Save Half", "Half Price",
or any other similar expressions used by us only represent an estimate of savings you might
benefit from buying certain tools with us compared to the major top brands and do not
necessarily mean to cover all categories of tools offered by us. You are kindly reminded to
verify carefully when placing an order with us if you are saving half in comparison with the top
major brands.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VEVOR JY-SS10L
Summary of Contents for VEVOR JY-SS10L
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support POWDER COATING MACHINE USER MANUAL We continue to be committed to offering tools at competitive prices. "Save Half", "Half Price", or any other similar expressions used by us only represent an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and do not necessarily mean to cover all categories of tools offered by us.
- Page 2 CustomerService@vevor.com This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software...
- Page 3 SAFETY INSTRUCTION AND PRECAUTIONS WARNING: Read this material before using this product. Failure to do so can result in serious injury. Assembly precautions 1.Assemble only according to these instructions. Improper assembly can create hazards. 2. Wear ANSI-approved safety goggles and heavy-duty work gloves during assembly.
- Page 4 6. Inspect before every use; do not use if parts are loose or damaged. 7. Is strictly forbidden to pour strong acidic and alkaline liquid into this product to avoid corrosive tank and cause personal injury. 1. Schematic diagram of JY-SS10L 10L pressure drum parts...
- Page 5 serial number name quantity Pressure barrel body Pressure drum base Barrel lid Sealing rings G-type fastening bolts M10 butterfly nut Fixed pins Circlips Suction tube Outlet relief valve handle 1/4" self-locking quick plug tubing fitting Inlet balloon valve switch Air outlet Intake regulator Pressure gauge Connection header...
- Page 6 2. List of user thread specifications SKU name valve Thread serial specifications number Air intakes American style 1/4" North self-locking quick plug American tubing fitting Standards Air outlet (including American 1/4", threaded opening and closing NPS, 18 teeth valve) Discharge port (with American 3/8", threaded opening and closing NPS, 18 teeth...
- Page 7 3. Preface This paint barrel is composed of inlet balloon valve switch, air pressure regulating valve, safety valve and discharge port. All parts are made of the best materials, and have passed strict quality control, and the appearance is treated with baking paint, so it can achieve the purpose of durability.
- Page 8 2. Pour in the spray material. 3. Close the pressure barrel lid and tighten the butterfly bolts one by one in a diagonal manner. Install the intake regulator on the three-way connector. 4. Close all valves, the sprayer inlet is connected to the barrel outlet (10), and the sprayer inlet is connected to the barrel outlet valve (15).
- Page 9 6. Adjust the intake pressure regulator, rotate clockwise to adjust to the required working pressure, if you want to reduce the pressure in the pressure barrel, rotate in a counterclockwise direction. Maintenance 1. After use, cut off the air source. Open the balloon valve switch on the lid to completely release the air in the barrel, then loosen the butterfly bolt, open the lid of the barrel, pour out the residual paint in the barrel, and clean all parts that have been touched by the paint with an appropriate amount of solvent.
-
Page 10: Troubleshooting
Troubleshooting fault The cause of the failure Exclusion method 1. The air source is not 1. Adjust the air source to The pointer of the pressure normal normal gauge connected to the air 2. The intake valve is not 2. Open the intake valve supply does not move open 3. - Page 11 Make sure to lock the bucket lid diagonally order of operations; 1-2 Items Description Name Powder Coating Machine Model JY-SS10L Parameter Capacity:10L，P(Max):60psi/0.413Mpa Package Size 365x285x285mm G.W. 10KG...
- Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support...
