1.2.2 Front camera (main unit) - rear view

Microphone
Used for voice recording.
Memory card slot
Insert a memory card to save recordings.
Security LED
Indicates that video
is being recorded.

1.2.3 Rear camera (optional)

Security LED
Indicates that the video is being recorded.
Mount connector
Used to connect the mount.
Adhesive mount
Used to fix the rear camera in the vehicle.
Rear camera lens
Records the rear view.
Reset button
Insert the tip of a sharp object to
reset the product when an error
occurs.
Front camera lens
Records the front view.
Connection port
Used to connect the rear
camera to the front camera
using a rear camera cable.
