B. Push "EXTEND REAR" (Fig. 36D) button until jacks contact the ground and lift rear of coach.
Keep button depressed until the carpenter's level bubble is centered.
C. Push "EXTEND DRIV SIDE" (Fig. 36B) and "EXTEND PASS SIDE" (Fig. 36C) buttons until level
bubble is centered.
4. With the coach leveled, press "CONFIRM LEVEL" (Fig. 36E).
5. The touchpad is now in zero mode. If the coach has come out of its level condition, it can be reset into
level condition by following the procedure outlined in step 3.
NOTE: During the, "Auto Level" process, (Fig. 23B), the "Leveling Error" screen (Fig. 27) will appear if:
• The control senses movement in the coach during the leveling process.
• Too much time has passed since the procedure started.
• Jack cylinders have reached full stroke so extend cannot occur.
• Coach is parked on too great of an incline (typically over 4.5 degrees) and cannot complete level
process.
To exit the Leveling Error screen, press Home (Fig. 34A) or Menu (Fig. 34B) icons.
