Summary of Contents for Grundig GD-TI-BP1603T

  • Page 2: Table Of Contents

    Contents 1 Overview ..........................2 1.1 Brief Description ........................2 1.2 Function ..........................2 2 Device Activation and Accessing ....................3 2.1 Activate the Device via IP-Finder ..................3 2.2 Activate the Device via Browser ................... 3 2.3 Login ............................4 2.3.1 Plug-in Installation .....................
  • Page 3 5.3.1 Calibrate Automatically ................... 17 5.3.2 Calibrate Manually ....................18 5.3.3 Verify the Calibration Result ..................19 5.4 Set Rules ..........................19 5.5 Advanced Configuration...................... 21 6 Event and Alarm ........................23 6.1 Set Motion Detection ......................23 6.1.1 Normal Mode ......................23 6.1.2 Expert Mode ......................
  • Page 4 8.1.7 Light .......................... 35 8.1.8 Wiper ........................35 8.1.9 Lens Initialization ..................... 35 8.1.10 Auxiliary Focus......................35 8.1.11 Quick Set Live View ....................35 8.1.12 Lens Parameters Adjustment................. 36 8.2 Set Transmission Parameters ..................... 36 9 Video and Audio ........................38 9.1 Video Settings ........................
  • Page 5 9.2.10 Defog ........................45 9.2.11 Gray Scale ....................... 45 9.2.12 Set Palette ......................46 9.2.13 Set Target Color ...................... 46 9.2.14 DDE ......................... 46 9.2.15 Brightness Sudden Change ..................47 9.2.16 Enhance Regional Image ..................47 9.2.17 Mirror ........................47 9.2.18 Video Standard .......................
  • Page 6 11 Network Settings ......................... 58 11.1 TCP/IP ..........................58 11.1.1 Multicast Discovery ....................59 11.2 Port ............................ 59 11.3 Port Mapping ........................60 11.3.1 Set Auto Port Mapping ..................60 11.3.2 Set Manual Port Mapping ..................61 11.4 Multicast ..........................61 11.5 SNMP ..........................
  • Page 7 12.9.2 Set NTP Server ......................69 12.9.3 Set DST ........................70 12.10 Set RS-232 ........................70 12.11 Set RS-485 ........................70 12.12 Set Same Unit ........................71 12.13 Security ..........................71 12.13.1 Authentication...................... 71 12.13.2 Security Audit Log ....................72 12.13.3 Set IP Address Filter .....................
  • Page 8 Introduction Thank you for purchasing a Grundig product. Before installing or connecting the product, please read first the following documents which you can find in printed form in the product package: - Legal Disclaimer - Safety Instructions - Installation Manual and/or Quick Guide for the respective product model Further information about the product like Data Sheets, CE Documents, etc.

  • Page 9: Overview

    1 Overview 1.1 Brief Description Thermal & Optical Bi-spectrum network camera equipped with built-in GPU which supports intelligent behavior analysis algorithm, can realize high-precision VCA detection and real-time alarm. It is applied to perimeter defense and fire-prevention purposes in critical infrastructures such as community, villa, construction site, factory, 4S stores, and so on.

  • Page 10: Device Activation And Accessing

    2.1 Activate the Device via IP-Finder Search and activate the online devices via IP-Finder tool. Before You Start Get the IP-Finder tool from the official website www.grundig-security.com to install. Steps 1. Connect the device to network using the network cable.

  • Page 11: Login

    Note The default IP address of the device is 192.168.1.64. You can set the IP address of the PC from 192.168.1.2 to 192.168.1.253 (except 192.168.1.64). For example, you can set the IP address of the PC to 192.168.1.100. 3. Input 192.168.1.64 in the browser. 4.

  • Page 12: Illegal Login Lock

    Operating System Web Browser Operation required. Display and operation of certain functions are restricted. For example, Playback and Picture are not available. For detailed restricted function, refer to the actual device. Plug-in installation is not required. Go to Configuration → Network →...

  • Page 13: Temperature Measurement

    3 Temperature Measurement When you enable this function, the device measures the actual temperature of the scene. It alarms when temperature exceeds the temperature threshold value. 3.1 Notice This part introduces the notices of configuring temperature measurement function. ● The target surface should be as vertical to the optical axis as possible. It is recommended that the angle of oblique image plane should be less than 45°.

  • Page 14: Thermography Configuration Flow Chart

    3.2 Thermography Configuration Flow Chart This part introduces the process of configuring temperature measurement. Figure 3-1 Thermography Configuration Flow Chart...

  • Page 15: Automatic Thermography

    Note Please refer to the Quick Start Guide for detailed information of Installation part in the flow chart. 3.3 Automatic Thermography Configure the temperature measurement parameters and temperature measurement rules. The device can measure the actual temperature and output alarms when temperature exceeds the alarm threshold value.

  • Page 16: Set Normal Mode

    Check to add data on alarm triggered capture of thermal channel. Add Original Data on Stream Check to add original data on thermal view. Data Refresh Interval It means the refresh interval of temperature information. Unit Display temperature with Degree Celsius (°C)/Degree Fahrenheit (°F)/Degree Kelvin (K). Temperature Range Select the temperature measurement range.

  • Page 17: Set Expert Mode

    Distance The distance between the target and the device. Pre-Alarm Threshold When the temperature of target exceeds the pre-alarm threshold, and this status keeps more than Filtering Time, it triggers pre-alarm. Alarm Threshold When the temperature of target exceeds the alarm threshold, and this status keeps more than Filtering Time, it triggers alarm.

  • Page 18: Set Thermography Rule

    7. Click Save. The maximum temperature and thermography rules will be displayed on the live view. Note Go to Image → VCA Rules Display to adjust the fonts size and the temperature color of normal, alarm and pre-alarm. 8. Optional: Call the preset and check if the rules are efficient. 9.

  • Page 19: Point Thermography

    temperature/alarm temperature. Tolerance Temperature Set the tolerance temperature to prevent the constant temperature change to affect the alarm. E.g., set tolerance temperature as 3°C, set alarm temperature as 55°C, and set pre- alarm temperature as 50°C. The device sends pre-alarm when its temperature reaches 50°C and it alarms when its temperature reaches 55°C and only when the device temperature is lower than 52°C will the alarm be cancelled.

  • Page 20: Area Thermography

    3.3.7 Area Thermography Configure the temperature measurement rule and monitor the maximum temperature of the area. Steps 1. Click and drag the mouse in the live view to draw the area and right click to finish drawing. 2. Click and move the area to adjust the position. 3.

  • Page 21: Fire Source Detection

    4 Fire Source Detection The device will trigger and upload alarm when detect the fire source or smoking. Fire source detection includes fire source detection and smoking detection. It is applied to fire- prevention purposes in scenic region, forest, tunnel and so on. Note Not all models support the configurations below, take the actual product for reference.
  • Page 22 Fire Source Detection Mode Smoking Mode Detect smoking behavior in the scene. Dynamic Fire Detect the fire source in the scene. Sensitivity The sensitivity of fire detection. The bigger the value is, more easily the fire source can be detected, and the false rate is higher. Note When VCA Resource Type is selected as Temperature Measurement+Behavior Analysis, only smoking detection is supported.

  • Page 23: Behavior Analysis

    5 Behavior Analysis The behavior analysis function is used to detect whether there is any target break the VCA rules. The optical camera will track the target or the device will alarm when the VCA rule is triggered. 5.1 Flow Chart of Behavior Analysis The process of configuring the behavior analysis function is described below.

  • Page 24: Set Vca Parameters

    5.2 Set VCA Parameters Steps 1. Go to Configuration → VCA → Basic Settings. Display VCA Info. on Stream Select to display target info and rule on stream, the information will be added to the video stream, and the overlay will be displayed if you get live view or play back by the VS Player. Display Trajectory The target's moving path will be shown in live view.

  • Page 25: Calibrate Manually

    Note You can set a maximum of two decimal places. 4. Click to start calibration. Caution ● The auto calibration starts when the person is totally seen in live view, and ends when the person is in the endpoint. ● The endpoint-to-camera distance (m) equals 4 times the lens focal length (mm). E.g, for 7mm lens, the recommended endpoint is 28m (7*4).

  • Page 26: Verify The Calibration Result

    7. Click Save. Caution ● Separate 4 vertical lines in the optical-axis direction at the close site, middle and far site respectively. ● Separate 4 vertical lines at the left, middle and right of the image respectively. ● If manual calibration's result is incorrect, select another target to recalibrate. ●...
  • Page 27 If any target intrudes into the pre-defined region longer than the set duration, the alarm will be triggered. Region Entrance If any target enters the pre-defined region, the alarm will be triggered. Region Exiting If any target exits the pre-defined region, the alarm will be triggered. 4.

  • Page 28: Advanced Configuration

    Note The parameter is available in optical channel. Target Size Filter Settings a suitable target size filter helps to increase detection accuracy. There are two ways to set the filter: ● If your device is successfully calibrated, select Filter by Actual Size and the device will filter targets according to the calibration automatically.
  • Page 29 Restart VCA Click Restart to restart the VCA function.

  • Page 30: Event And Alarm

    6 Event and Alarm This part introduces the configuration of events. The device takes certain response to triggered alarm. Certain events may not be supported by certain device models. 6.1 Set Motion Detection It helps to detect the moving objects in the detection region and trigger the linkage actions. Steps 1.

  • Page 31: Expert Mode

    Figure 6-1 Set Rules Stop Drawing Stop drawing one area. Clear All Clear all the areas. 4. Optional: You can set the parameters of multiple areas by repeating the above steps. 6.1.2 Expert Mode You can configure the motion detection parameters of day/night switch according to the actual needs.

  • Page 32: Set Video Tampering Alarm

    3. Select an Area and click Draw Area. Click and drag the mouse on the live video, then release the mouse to finish drawing one area. Figure 6-2 Set Rules Stop Drawing Finish drawing one area. Clear All Delete all the areas. 4.

  • Page 33: Set Alarm Input

    Figure 6-3 Set Video Tampering Area 6. Refer to Set Arming Schedule for setting scheduled time. Refer to Linkage Method Settings for setting linkage method. 7. Click Save. 6.3 Set Alarm Input Alarm signal from the external device triggers the corresponding actions of the current device. Before You Start Make sure the external alarm device is connected.

  • Page 34: Set Exception Alarm

    6.4 Set Exception Alarm Exception such as network disconnection can trigger the device to take corresponding action. Steps 1. Go to Configuration → Event → Basic Event → Exception. 2. Select Exception Type. HDD Full The HDD storage is full. HDD Error Error occurs in HDD.
  • Page 35 Sudden Decrease of Sound Intensity Detection Detect sudden decrease of sound intensity. Sensitivity is configurable. 3. Refer to Set Arming Schedule for setting scheduled time. Refer to Linkage Method Settings for setting linkage methods. 4. Click Save. Note The function varies according to different models.

  • Page 36: Arming Schedule And Alarm Linkage

    7 Arming Schedule and Alarm Linkage Arming schedule is a customized time period in which the device performs certain tasks. Alarm linkage is the response to the detected certain incident or target during the scheduled time. 7.1 Set Arming Schedule Set the valid time of the device tasks.

  • Page 37: Ftp/Nas/Memory Card Uploading

    Manual Alarm You can trigger an alarm output manually. Steps 1. Set the manual alarm parameters. Alarm Output No. Select the alarm output No. according to the alarm interface connected to the external alarm device. Alarm Name Custom a name for the alarm output. Delay Select Manual.

  • Page 38: Send Email

    Refer to Set Memory Card for memory card storage configuration. 7.2.3 Send Email Check Send Email, and the device sends an email to the designated addresses with alarm information when an alarm event is detected. For email settings, refer to Set Email. Set Email When the email is configured and Send Email is enabled as a linkage method, the device sends an email notification to all designated receivers if an alarm event is detected.

  • Page 39: Notify Surveillance Center

    well as the image captured when the alarm is triggered. Video Select the video channel and video duration as required. ● 0 s: It will not upload the video of the selected channel. ● 3 s: Upload the video that is recorded about 1 s before and 2 s after the alarm is triggered.

  • Page 40: Set Flashing Alarm Light Output

    Note The function is only supported by certain device models. 7.2.7 Set Flashing Alarm Light Output Steps 1. Go to Configuration → Event → Basic Event → Flashing Alarm Light Output. 2. Select a White Light Mode. Mode Description Flashing Alarm triggers the light to flash for a certain duration.

  • Page 41: Live View

    8 Live View It introduces the live view parameters, function icons and transmission parameters settings. 8.1 Live View Parameters The supported functions vary depending on the model. Note For multichannel devices, select the desired channel first before live view settings. 8.1.1 Window Division ●...

  • Page 42: Full Screen

    live view among multiple channels. Click to switch live view among multiple channels. 8.1.6 Full Screen This function is used to view the image in full screen mode. Click to start full screen mode and press ESC button to exit. 8.1.7 Light Click to turn on or turn off the illuminator.

  • Page 43: Lens Parameters Adjustment

    Note The function is only supported by certain models. 8.1.12 Lens Parameters Adjustment It is used to adjust the lens focus, zoom and iris. Zoom ● Click , and the lens zooms in. ● Click , and the lens zooms out. Focus ●...
  • Page 44 HTTP HTTP is suitable for the situation that the third-party needs to get the stream from the device. Play Performance Shortest Delay The device takes the real-time video image as the priority over the video fluency. Balanced The device ensures both the real-time video image and the fluency. Fluent The device takes the video fluency as the priority over teal-time.

  • Page 45: Video And Audio

    9 Video and Audio This part introduces the configuration of video and audio related parameters. 9.1 Video Settings This part introduces the settings of video parameters, such as, stream type, video encoding, and resolution. Go to setting page: Configuration → Video/Audio → Video. Note For device with multiple camera channels, select a channel before other settings.

  • Page 46: Bitrate Type And Max. Bitrate

    and storage. 9.1.4 Bitrate Type and Max. Bitrate Constant Bitrate It means that the stream is compressed and transmitted at a comparatively fixed bitrate. The compression speed is fast, but mosaic may occur on the image. Variable Bitrate It means that the device automatically adjust the bitrate under the set Max. Bitrate. The compression speed is slower than that of the constant bitrate.

  • Page 47: Smoothing

    standard. In comparison to H.264, it offers better video compression at the same resolution, frame rate and image quality. MJPEG Motion JPEG (M-JPEG or MJPEG) is a video compression format in which intraframe coding technology is used. Images in a MJPEG format is compressed as individual JPEG images. Profile This function means that under the same bitrate, the more complex the profile is, the higher the quality of the image is, and the requirement for network bandwidth is also higher.

  • Page 48: Audio Settings

    Player means the VCA info can be displayed by the dedicated player provided by the manufacturer. Video Video means the VCA info can be displayed by any general video player. 9.1.10 Audio Settings It is a function to set audio parameters such as audio encoding, environment noise filtering. Go to the audio settings page: Configuration →...

  • Page 49: Set Roi

    ● If the device has built-in microphone and speaker, two-way audio function can be enabled directly. Steps 1. Click Live View. 2. Click on the toolbar to enable two-way audio function of the camera. 3. Click and select , move the slider to adjust the volume. 4.

  • Page 50: Display Settings

    9.2 Display Settings It offers the parameter settings to adjust image features. Go to Configuration → Image → Display Settings. For device that supports multiple channels, display settings of each channel is required. The settings for different channels may be different. This part introduces all possible parameters among the channels.

  • Page 51: Set Supplement Light

    the night mode. Switch mode is configurable. The image is always in color. Night The image is always black/white Auto The camera switches between the day mode and the night mode according to the illumination automatically. Scheduled-Switch Set the Start Time and the End Time to define the duration for day mode. Note Day/Night Switch function varies according to models.

  • Page 52: Wdr

    mode is set as Custom, you can draw a red rectangle on the live view image as the BLC area. 9.2.7 WDR The WDR (Wide Dynamic Range) function helps the camera provide clear images in environment with strong illumination differences. When there are both very bright and very dark areas simultaneously in the field of view, you can enable the WDR function and set the level.

  • Page 53: Set Palette

    9.2.12 Set Palette You can select the palette mode to display the thermal grayscale image to colored image. Steps 1. Go to Configuration → Image → Display Settings. 2. Select the thermal channel. 3. Select a palette mode in Image Enhancement according to your need. Result The live view displays the image with palette.

  • Page 54: Brightness Sudden Change

    shows, but the higher the noise is. 9.2.15 Brightness Sudden Change When the brightness of target and the background is hugely different (the temperature difference of target and background is huge), the system reduces the difference for viewing. 9.2.16 Enhance Regional Image You can select the desired area of image to improve the coding quality.

  • Page 55: Osd

    Select a scene according to the actual installation environment to speed up the display settings. 9.3 OSD You can customize OSD (On-screen Display) information such as device name, time/date, font, color, and text overlay displayed on video stream. Go to OSD setting page: Configuration → Image → OSD Settings. Set the corresponding parameters, and click Save to take effect.

  • Page 56: Overlay Picture

    Note Up to 4 areas are supported for setting. 9.5 Overlay Picture Overlay a customized picture on live view. Before You Start The picture to overlay has to be in BMP format with 24-bit, and the maximum picture size is 128 × 128 pixel.

  • Page 57: Set Picture In Picture

    9.7 Set Picture in Picture You can overlay the images of two channels and view the image of two channels at the same time. Steps 1. Select a channel number. 2. Select the picture in picture mode. Overlap Mode Partial image of thermal channel is displayed on the full screen of optical channel.

  • Page 58: Video Recording And Picture Capture

    10 Video Recording and Picture Capture This part introduces the operations of capturing video clips and snapshots, playback, and downloading captured files. 10.1 Storage Settings This part introduces the configuration of several common storage paths. 10.1.1 Set Memory Card If you choose to store the files to memory card, make sure you insert and format the memory card in advance.

  • Page 59: Set Ftp

    The saving path of network disk files. Mounting Type Select file system protocol according to the operation system. Enter user name and password of the net HDD to guarantee the security if SMB/CIFS is selected. 3. Click Test to check whether the network disk is available. 4.

  • Page 60: Set Cloud Storage

    10.1.4 Set Cloud Storage It helps to upload the captured pictures and data to the cloud. The platform requests picture directly from the cloud for picture and analysis. The function is only supported by certain models. Steps Caution If cloud storage is enabled, the pictures are stored in the cloud storage server preferentially. 1.
  • Page 61 Steps Note The function varies according to different models. 1. Go to Configuration → Storage → Schedule Settings → Record Schedule. 2. Select channel No. 3. Check Enable. 4. Select a record type. Note The record type is vary according to different models. Continuous The video will be recorded continuously according to the schedule.

  • Page 62: Record Manually

    The time period you set to stop recording after the scheduled time. Stream Type Select the stream type for recording. Note When you select the stream type with higher bitrate, the actual time of the pre-record and post-record may be less than the set value. Recording Expiration The recordings are deleted when they exceed the expired time.

  • Page 63: Capture Configuration

    Note Go to Configuration → Local, click Save downloaded files to to change the saving path of downloaded video files. 10.3 Capture Configuration The device can capture the pictures manually or automatically and save them in configured saving path. You can view and download the snapshots. 10.3.1 Capture Automatically This function can capture pictures automatically during configured time periods.

  • Page 64: View And Download Picture

    4. Click near the live view or play back window to capture a picture manually. 10.3.3 View and Download Picture You can search, view and download the pictures stored in the local storage or network storage. Steps 1. Click Picture. 2.

  • Page 65: Network Settings

    11 Network Settings 11.1 TCP/IP TCP/IP settings must be properly configured before you operate the device over network. IPv4 and IPv6 are both supported. Both versions can be configured simultaneously without conflicting to each other. Go to Configuration → Basic Configuration → Network → TCP/IP for parameter settings. NIC Type Select a NIC (Network Interface Card) type according to your network condition.

  • Page 66: Multicast Discovery

    Input IPv6 Address, IPv6 Subnet, IPv6 Default Gateway. Consult the network administrator for required information. It stands for maximum transmission unit. It is the size of the largest protocol data unit that can be communicated in a single network layer transaction. The valid value range of MTU is 1280 to 1500.

  • Page 67: Port Mapping

    to ensure the secure access. WebSocket Port TCP-based full-duplex communication protocol port for plug-in free preview. WebSockets Port TCP-based full-duplex communication protocol port for plug-in free preview. Certificate verification is required to ensure the secure access. Note ● Enhanced SDK Service Port, WebSocket Port, and WebSockets Port are only supported by certain models.

  • Page 68: Set Manual Port Mapping

    11.3.2 Set Manual Port Mapping Steps 1. Check Enable UPnP™, and choose a friendly name for the device, or you can use the default name. 2. Select the port mapping mode to Manual, and set the external port to be the same as the internal port.

  • Page 69: Access To Device Via Domain Name

    Note The SNMP version you select should be the same as that of the SNMP software. And you also need to use the different version according to the security level required. SNMP v1 is not secure and SNMP v2 requires password for access. And SNMP v3 provides encryption and if you use the third version, HTTPS protocol must be enabled.

  • Page 70: Enable Scms Service On Camera

    the device. Steps 1. Go to Configuration → Network → Basic Settings → PPPoE. 2. Check Enable PPPoE. 3. Set the PPPoE parameters. Dynamic IP After successful dial-up, the dynamic IP address of the WAN is displayed. User Name User name for dial-up network access. Password Password for dial-up network access.

  • Page 71: Access Camera Via Scms

    Steps 1. Access the camera via web browser. 2. Enter platform access configuration interface. Configuration → Network → Advanced Settings → Platform Access 3. Select SCMS as the Platform Access Mode. 4. Check Enable. 5. Click and read "Terms of Service" and "Privacy Policy" in pop-up window. 6.

  • Page 72: Set Open Network Video Interface

    Register status turns to Online when the function is correctly set. 11.10 Set Open Network Video Interface If you need to access the device through Open Network Video Interface protocol, you can configure the user settings to enhance the network security. Steps 1.

  • Page 73: Set Network Service

    4. Click Test to check if the IP or host is available. 5. Click Save. 11.13 Set Network Service You can control the ON/OFF status of certain protocol as desired. Steps Note This function varies according to different models. 1. Go to Configuration → Network → Advanced Settings → Network Service. 2.

  • Page 74: System And Security

    12 System and Security It introduces system maintenance, system settings and security management, and explains how to configure relevant parameters. 12.1 View Device Information You can view device information, such as Device No., Model, Serial No. and Firmware Version. Enter Configuration → System → System Settings → Basic Information to view the device information.

  • Page 75: Export Diagnose Information

    12.4 Export Diagnose Information Diagnose information includes running log, system information, hardware information. Go to Configuration → System → Maintenance → Upgrade & Maintenance, and click Diagnose Information to export diagnose information of the device. 12.5 Reboot You can reboot the device via browser. Go to Configuration →...

  • Page 76: View Open Source Software License

    Firmware Locate the exact path of the upgrade file. Firmware Directory Locate the directory which the upgrade file belongs to. 3. Click Browse to select the upgrade file. 4. Click Upgrade. 12.8 View Open Source Software License Go to Configuration → System → System Settings → About Device, and click View Licenses. 12.9 Time and Date You can configure time and date of the device by configuring time zone, time synchronization and Daylight Saving Time (DST).

  • Page 77: Set Dst

    Note Server Address is NTP server IP address. 5. Click Test to test server connection. 6. Click Save. 12.9.3 Set DST If the region where the device is located adopts Daylight Saving Time (DST), you can set this function. Steps 1.

  • Page 78: Set Same Unit

    Note You should keep the parameters of the device and the computer or terminal all the same. 3. Click Save. 12.12 Set Same Unit Set the same temperature unit and distance unit. When you enable this function, the unit cannot be configured separately in other setting pages Steps 1.

  • Page 79: Security Audit Log

    12.13.2 Security Audit Log The security audit logs refer to the security operation logs. You can search and analyze the security log files of the device so as to find out the illegal intrusion and troubleshoot the security events. Security audit logs can be saved on device internal storage. The log will be saved every half hour after device booting.

  • Page 80: Set Ssh

    12.13.4 Set SSH SSH is a protocol to ensure security of remote login. This setting is reserved for professional maintenance personnel only. Steps 1. Go to Configuration → System → Security → Security Service. 2. Check Enable SSH. 3. Click Save. 12.13.5 Set HTTPS HTTPS is a network protocol that enables encrypted transmission and identity authentication, which improves the security of remote access.

  • Page 81: Set Qos

    via HTTPS protocol to ensure the data transmission security. Steps 1. Select Create certificate request first and continue the installation. 2. Click Create. 3. Follow the prompt to input Country/Region, Hostname/IP, Validity and other parameters. 4. Click Download to download the certificate request and submit it to the trusted authority for signature.

  • Page 82: User And Account

    12.14 User and Account 12.14.1 Set User Account and Permission The administrator can add, modify, or delete other accounts, and grant different permission to different user levels. Caution To increase security of using the device on the network, please change the password of your account regularly.

  • Page 83: Appendix

    13 Appendix 13.1 Common Material Emissivity Reference Material Emissivity Human Skin 0.98 Printed Curcuit Board 0.91 Concrete 0.95 Ceramic 0.92 Rubber 0.95 Paint 0.93 Wood 0.85 Pitch 0.96 Brick 0.95 Sand 0.90 Soil 0.92 Cloth 0.98 Hard Paperboard 0.90 White Paper 0.90 Water 0.96...

This manual is also suitable for:

Gd-ti-ap1614vGd-ti-bp1606tGd-ti-bp1603vGd-ti-bp1610t
