Sumake DT-6604 Manual

Digital tire inflater

Advertisement

DT-6604

Features:

Reinforced plastic gun body. Slip proof handle grip; shock resistant gauge protector. Backlit screen; auto turn itself
off after 80 seconds for power saving.
Operation pressure up to 100 PSI
Fast inflation, air flow delivered: 1.28 CFM

Function:

Fill air (inflation)
Release air (deflating)
Gauge pressure (measuring)

Specifications:

2" Gauge 360 Degree Swivel Function.
Measure Range: 0 - 100 PSI , 0 - 7.0 BAR , 0 - 0.7 Mpa
Pressure Increments: 0.2 PSI ; 0.02 Bar ; 0.002 Mpa
Measuring Range form 0 - 100 PSI (+/- 2%,@25℃)
Supply Voltage: two 1.5 V DC Battery. Battery Life: 1,500 hrs.(continue working)
User Interface: ON/OFF
Function – 0 – User Zero
1/4" Rubber Hose & Dual Chuck 6" Steel, Hose 33CM <W.P. W/200PS1>
WARNING: USE ONLY WITH REGULATED AIR SYSTEMS. Do not exceed 120 PSI maximum.
Check tire pressure often while inflation. Inflate to tire manufacturer's recommended pressure only. Over-inflation and
under-inflation of fire both create potentially hazardous driving conditions.
Wearing impact-resistant protective eyewear while inflation tires is recommended.
Always check and set pressure when the tire is cold.
DIGITAL TIRE INFLATER
– 1 – Auto - off Time Selectable
– 2 – 3 Units Selectable
DT-6604-I-1409B-LM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DT-6604 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sumake DT-6604

  • Page 1 DT-6604 DIGITAL TIRE INFLATER Features: Reinforced plastic gun body. Slip proof handle grip; shock resistant gauge protector. Backlit screen; auto turn itself off after 80 seconds for power saving. Operation pressure up to 100 PSI Fast inflation, air flow delivered: 1.28 CFM...
  • Page 2 LCD GAUGE OPERATION GUIDE Operation mode: To switch on: When the gauge is off, press “On” button once then the gauge will be turned on. To switch off: When the gauge is on, press “On” button once turn off. Or, the gauge will be automatically off when it has been set in advance to be turned off under specific condition.
  • Page 3 EU Declaration of Conformity (DOC) SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment: DIGITAL TIRE INFLATER Model/ Serial No.: DT-6604 The object of the declaration described above is in conformity with the relevant union harmonization legislation: ...
  • Page 4 DT-6604 DIGITAL TIRE INFLATER W/33CM RUBBER HOSE & DUAL CHCUK 6" STEEL PARTS LIST Parts No. Description Q'ty DT6604-01 Body DT6604-02 Connector DT6604-03 Digital Gauge DT6604-04 Air Hose With Fitting DT6604-05 Dual Chuck DT6604-06 Fixed Guide DT6604-07 O-Ring DT6604-08 O-Ring...
