Sumake ST-55591A Quick Start Manual

Sumake ST-55591A Quick Start Manual

Air ratchet wrench

Advertisement

Quick Links

SUMAKE
Specification:
Free Speed
Bolt Size Capacity
Max. Torque
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
Air Ratchet Wrench
ST-55591A, ST-55591AS
180 r/min
6mm, 7mm, 8mm, 9mm,
10mm, 11mm, 12mm,
1/4", 5/16", 3/8", 7/16"
7.38 ft-lb (10 N-m)
14 CFM (400 L/min)
11-2/9" (285 mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
2.82 lbs (1.28 kg)
Noise and Vibration:
Vibration
EN ISO 28927-2
Sound Pressure Level
Load:
2.5 m/s²
Uncertainty
K= 1.5 m/s
²
Noise
EN ISO 15744
No load: 70 dB(A)
Please always
Sound power level
environment
No load: 81 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
K= 3dB
ST-55591A(AS)-S-2305B-OPF
Remark
wear ear
protector at
hearing!

Advertisement

loading
Need help?

Need help?

Do you have a question about the ST-55591A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sumake ST-55591A

  • Page 1 Air Hose (I.D.) 3/8” (10 mm) risk of impaired Uncertainty Uncertainty hearing! Air Pressure 90 psi (6.3 bar) K= 1.5 m/s K= 3dB ² Net Weight 2.82 lbs (1.28 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-55591A(AS)-S-2305B-OPF...
  • Page 2: Ec Declaration Of Conformity

    DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment: AIR RATCHET WRENCH Model/ Serial No.:ST-55591A, ST-55591AS to which this declaration applies, complies with these normative documents: ...
  • Page 3 So, install an air filter and on oiler between the 3.2 Torque Adjuster compressor and the tool. Use a 3 HP or larger You can adjust the torque by rotating the knob compressor for each sander. ST-55591A(AS)-I-2212A-OP...
  • Page 4 ST-55591A AIR RATCHET WRENCH ST-55591AS AIR RATCHET WRENCH WITH HOSEM PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty 55591-01 Screw 19-1 55591-19-1 Stopping Wheel 55591-03 Rear Cap 55591-20 Ball Bearing (6000) 55591-04 Operating Rod 55591-21 Ball Bearing (1024)
  • Page 5 RATCHET WRENCH Original instructions SUMAKE Industrial Co. Ltd.
  • Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
  • Page 7 stiffness, these warning signs should not be ignored. The operator should tell the employer and consult a qualified health professional. Safety precautions for accessory hazards Disconnect the assembly power tool for threaded fasteners from the energy supply before changing the inserted tool or accessory. Do not touch sockets or accessories during impacting, as this increases the risk of cuts, burns or vibration injuries.
  • Page 8 shall indicate the nature of the hazard, the risk of injury and the avoidance action to take. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet. Also, every 3 to 4 hours of operation, oiling is necessary. Twist Teflon thread tape to ensure a proper seal air inlet.

This manual is also suitable for:

St-55591as
