- Page 1 System 3000 Operating instructions Motion detector top unit 1.10 m Standard Order no. 5373 .. Motion detector top unit 1.10 m Standard Order no. 5379 .. Motion detector top unit 2.20 m Standard Order no. 5375 ..
-
Page 2: Table Of Contents
Motion detector top unit Standard Table of contents Safety instructions ...................... 3 Intended use ........................ 3 Operation .......................... 4 Information for electrically skilled persons ................ 5 Mounting and electrical connection................ 6 Commissioning .................... 11 Technical data ........................ 12 Troubleshooting ...................... 13 Warranty ......................... -
Page 3: Safety Instructions
Motion detector top unit Standard Safety instructions Electrical devices may be mounted and connected only by electrically skilled persons. Serious injuries, fire or property damage are possible. Please read and follow the manual fully. Danger of electric shock. Always disconnect before carrying out work on the device or load. -
Page 4: Operation
Motion detector top unit Standard Motion detector 1.10 m – Screen for limiting the detection area Automatic operation The device detects heat motions of people, animals and objects. – The light is switched on if a person enters the detection field and the bright- ness threshold is below the set brightness threshold. -
Page 5: Information For Electrically Skilled Persons
Motion detector top unit Standard ￭ Press the push-button cover at the top or bottom or the push-button for longer than 0.4 seconds. Light becomes brighter or dimmer as far as the respective limit value. Push-button: The dimming direction is changed with each new long actuation. Saving the switch-on brightness Only in combination with a main device with a dimming insert. -
Page 6: Mounting And Electrical Connection
Motion detector top unit Standard Mounting and electrical connection Motion detection The detection of heat sources through a motion detector and thus the extent of the detection field is influenced by the following criteria: Geometry of the detection field, assembly height and set sensitivity (see figure 1) up to (see figure 10) Direction of movement : Passing the motion detector tangentially results in a heat signal which can be evaluated well. - Page 7 Motion detector top unit Standard 50% sensitivity 75% sensitivity 100% sensitivity Image 3: Range with radial direction of motion for motion detector cover 5373 .. 25% sensitivity 50% sensitivity 75% sensitivity 100% sensitivity Image 4: Range with tangential direction of motion for motion detector cover 5379 .. 32599612 10870634 19.07.2023...
- Page 8 Motion detector top unit Standard Image 5: Range with radial direction of motion for motion detector cover 5379 .. Motion detector cover 2.20 m detection field and range Image 6: Motion detector cover 2.20 m detection field and installation height Image 7: Range with tangential direction of motion for motion detector cover 2.20 m, mounting height 2.20 m 25% sensitivity 50% sensitivity...
- Page 9 Motion detector top unit Standard Image 8: Range with radial direction of motion for motion detector cover 2.20 m, mounting height 2.20 m 25% sensitivity 50% sensitivity 75% sensitivity 100% sensitivity Image 9: Range with tangential direction of motion for motion detector cover 2.20 m, mounting height 1.10 m 25% sensitivity 50% sensitivity...
- Page 10 Motion detector top unit Standard Image 10: Range with radial direction of motion for motion detector cover 2.20 m, mounting height 1.10 m 25% sensitivity 50% sensitivity 75% sensitivity 100% sensitivity Selecting installation location ￭ Select a vibration-free installation location. Vibrations can lead to unwanted switching.
-
Page 11: Commissioning
Motion detector top unit Standard Image 11: Limiting the detection field motion detector cover 1.10 m Image 12: Mounting cover panel 90° Commissioning Make settings Image 13: Adjuster motion detector order no. 5373 .., 5375 .. Image 14: Adjuster motion detector order no. 5379 .. 32599612 10870634 19.07.2023... -
Page 12: Technical Data
1 second when motion is detected. The sensitivity setting re- mains intact. Technical data Ambient temperature -20 ... +45°C Storage/transport temperature -25 ... +70°C Degree of protection System 55, Gira E22, Flächenschalter (F100) IP20 TX44 IP44 Brightness setting Approx. 5 ... 1000 lx and day operation Sensitivity Order no. -
Page 13: Troubleshooting
Please submit or send faulty devices postage paid together with a fault de- scription to your responsible salesperson (specialist trade / installation company / electrical specialist trade). They will forward the devices to the Gira Service Center. Gira Giersiepen GmbH & Co. KG... - Page 14 Motion detector top unit Standard Deutschland Tel +49(0)21 95 - 602-0 Fax +49(0)21 95 - 602-191 www.gira.de info@gira.de 32599612 10870634 19.07.2023 14 / 14...
