Description
† Main Components
The main components of the SmartDate X65 are:
Printer body
1
Containing the drive system
and thermal transfer
printhead
† Optional Components
Your SmartDate X65 may have been supplied with optional components, the most common of
which are:
Encoder: For tracking the speed of
the film in continuous applications
2
IP45 Kit: For protection against
water ingress
10
Controller
3
Containing the main operation
PCBs and capacitive
touchscreen user interface
Ribbon cassette
Containing ribbon supply and
waste take up spools
Beacon Tower: To monitor the
operational state of the printer
