Dover markem-imaje 18 Series Maintenance Manual
  1. Manuals
  2. Brands
  3. Dover Manuals
  4. Printer
  5. markem-imaje 18 Series
  6. Maintenance manual
Dover markem-imaje 18 Series Maintenance Manual

Dover markem-imaje 18 Series Maintenance Manual

Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the markem-imaje 18 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Dover markem-imaje 18 Series

Summary of Contents for Dover markem-imaje 18 Series

  • Page 3: Table Of Contents

    TABLE OF CONTENTS General Information Uptime™ Total Services Setup and Timing Issues Introduction Setup Issues 2.2.1 Print Anvil 2.2.2 Printhead Gap 2.2.3 Ribbons Important Printer Settings Print Darkness 2.4.1 Print Speed Print Signal Issues 2.5.1 Debounce Time 2.5.2 Print Delay Moving the Printed Image 2.6.1 Registration...
  • Page 4 TABLE OF CONTENTS Technical Information Introduction The 8018 Thermal Transfer Printer Printer Components 4.3.1 Intermittent Drive System - Model 8018i Printer 4.3.2 Continuous Drive System - Model 8018c Printer 4.3.3 Ribbon Drive System The Printhead Module 4.4.1 The Print Mechanism Components 4.4.2 Printhead Mechanism Operation Printhead Assembly...
  • Page 5 TABLE OF CONTENTS Troubleshooting Introduction Fault and Warning Messages 5.2.1 Fault Messages 5.2.2 Warning Messages Common Issues 5-11 5.3.1 No Power to the Printer 5-11 5.3.2 Printhead Cables 5-11 5.3.3 Encoder 5-11 No Information Is Printed 5-11 The Printhead Does Not Move Out 5-11 Drive System Issues 5-12...
  • Page 6 TABLE OF CONTENTS 8018 06/08...

  • Page 7: General Information

    SECTION 1 GENERAL INFORMATION 8018 Thermal Transfer Printer Maintenance Manual...

  • Page 9: Section 1 - General Information

    SECTION 1 - GENERAL INFORMATION General Information This manual is designed to assist with keeping your 8018 Thermal Transfer Printer in good working order. Topics covered in the following sections include: • General maintenance and cleaning. • Technical information about the 8018. •...

  • Page 10: Uptime™ Total Services

    SECTION 1 - GENERAL INFORMATION Uptime™ Total Services • Application Specialists • Installation • myMARKEM • Repair Centre • Training As part of the Markem.Imaje continuous commitment to helping customers succeed, Markem.Imaje has introduced the Uptime Total Solutions Program, a comprehensive array of services to maximize uptime, productivity and customer satisfaction.

  • Page 11: Setup And Timing Issues

    SECTION 2 SETUP AND TIMING ISSUES 8018 Thermal Transfer Printer Operation Manual...

  • Page 13: Section 2 - Setup And Timing Issues

    SECTION 2 - SETUP AND TIMING ISSUES Setup and Timing Issues Introduction The following section provides general advice for ensuring that your 8018 Thermal Transfer Printer is working at its most efficient. Topics covered in this section include: • Printhead Gap •...

  • Page 14: Setup Issues

    SECTION 2 - SETUP AND TIMING ISSUES Setup Issues 2.2.1 Print Anvil The print roller for Model 8018c and print anvil for Model 8018i are wear parts, and should be checked regularly for damage. If the print roller has become damaged this will cause print quality problems. For example a flat spot on the Model 8018c roller rubber will appear as a repeated blank area on the Test pattern.

  • Page 15: Important Printer Settings

    SECTION 2 - SETUP AND TIMING ISSUES Important Printer Settings Various Printer Settings will affect the performance of the 8018 printers. The initial setup of the machine would normally be performed by a qualified Markem.Imaje trained technician, but if not the following information should prove helpful.

  • Page 16: Print Speed

    SECTION 2 - SETUP AND TIMING ISSUES 2.4.1 Print Speed The speed that Printhead moves along the linear slide (Model 8018i). The speed the ribbon moves on the print part of the cycle. (Model 8018c) With Intermittent printers the speed is determined by the dwell time when the substrate has stopped moving.

  • Page 17: Moving The Printed Image

    SECTION 2 - SETUP AND TIMING ISSUES Moving the Printed Image The position of print within the printing area can be changed. Altering the Registration and Offset values moves the printed information in the head feeding direction and up and down the Printhead. On intermittent printers, when the Registration is altered the printhead will move to its new datum position immediately and will use this new datum until the Registration is altered again.

  • Page 18: Timing Issues

    SECTION 2 - SETUP AND TIMING ISSUES Timing issues Many timing issues (speeding up the line/host machine) can arise when setting up a new application, or when changing the way an existing application works. Timing issues can be common to the Model 8018i and Model 8018c. Since the machines work differently, it is likely that timing issues will vary with the machine type.

  • Page 19: Maintenance

    SECTION 3 MAINTENANCE 8018 Thermal Transfer Printer Operation Manual...

  • Page 21: Section 3 - Maintenance

    SECTION 3 - MAINTENANCE Maintenance Introduction The 8018 series of Thermal Transfer Printers are extremely successful, however as with any machine, if it is not set up and maintained correctly, problems can occur. This section is designed to provide information about how to keep your 8018 Thermal Transfer Printer in good working order.

  • Page 22: Cleaning And Care

    SECTION 3 - MAINTENANCE Cleaning and Care To ensure that your 8018 Thermal Transfer Printer operates correctly, the entire unit should be cleaned on a regular basis. Particular attention should be given to the printer, especially if food products are able to fall into the unit.

  • Page 23: Care Of The Printhead

    SECTION 3 - MAINTENANCE Care of the Printhead Although purpose-built for its application, the printhead is still subject to wear and tear. Careful consideration at the time of installation and regular preventative maintenance can significantly help to maximise printhead life. The most frequent cause of printhead damage is abrasion - either from ingress of airborne particles or from an abrasive substrate surface.

  • Page 24: Replacing The Printhead

    SECTION 3 - MAINTENANCE Replacing the Printhead Turn off the power to the printer. Always ensure anti static precautions are used when handling new printheads. 3.5.1 Removing the damaged printhead 1. Remove the four retaining screws 2. Lift the clamp off and place to one from the Printhead cable clamp.

  • Page 25: Setting The Correct Printhead Resistance

    SECTION 3 - MAINTENANCE 3.5.2 Setting the correct Printhead Resistance Note the resistance value printed on the PCB side of the new Printhead. This value must be entered into the User Interface menu structure. The processor will then adjust the voltage level to suit the particular printhead resistance level.
  • Page 26 SECTION 3 - MAINTENANCE Press the right button to Select the menu. 3. Pressure 4. TPH Resistance 5. Print Speed Back Select The TPH Resistance menu screen is displayed. TPH Resistance Current: 1125 New: 1085 Cancel Accept Enter the new value by using the numeric keypad or use the top and bottom Quad buttons to change the value.

  • Page 27: Replacing The Peel Roller

    SECTION 3 - MAINTENANCE Replacing the Peel Roller The Peel Roller body is a wear part and should be checked for damage and changed if necessary. 1. Remove the retaining screw from 2. Carefully remove the peel roller the end of peel roller. ensuring not to drop any components.

  • Page 28: Replacing The Ribbon Guide Rollers

    SECTION 3 - MAINTENANCE Replacing the Ribbon Guide Rollers The ribbon guide rollers are vulnerable to damage through misuse and may have to be changed if they become bent or damaged. The procedure is as follows: 2. Carefully remove the ribbon guide 1.

  • Page 29: Replacing The Ribbon Movement Roller

    SECTION 3 - MAINTENANCE Replacing the Ribbon Movement Roller If any parts of the movement roller has been damaged, the assembly will have to be replaced. The procedure is as follows: Switch off and disconnect the power to the machine. 1.Release the ribbon supply reel securing clasp by applying pressure with a screwdriver or Allen key.

  • Page 30: Replacing The Ribbon Movement Sensor

    SECTION 3 - MAINTENANCE 3.8.1 Replacing the Ribbon Movement Sensor If the sensor has to be replaced, the procedure should be as follows: Switch off and disconnect the power to the machine. Remove the Ribbon Movement roller as previously described. 1.

  • Page 31: Replacing The Ribbon Tension Roller

    SECTION 3 - MAINTENANCE Replacing the Ribbon Tension Roller If the tension roller becomes damaged the whole assembly may require changing. The procedure is as follows: Switch off and disconnect the power to the machine. 2. Lift the assembly off the shaft. 1.

  • Page 32: Replacing The Ribbon Tension Sensor

    SECTION 3 - MAINTENANCE 3.10 Replacing the Ribbon Tension Sensor If the tension sensor has to be replaced, the procedure should be as follows: Switch off and disconnect the power to the machine. 1. Undo the six retaining screws and 2.

  • Page 33: Sensor Calibration

    SECTION 3 - MAINTENANCE 3.11 Sensor Calibration The tension sensor will require re-calibrating once it has been fitted. When you replace the Main PCB, Tension Sensor PBC, or Tension Sensor Assembly, you will need to calibrate the tension sensor. This is achieved by standing the printer on it’s side, and using the Local User Interface menu…...
  • Page 34 SECTION 3 - MAINTENANCE 3-14 8018 06/08...

  • Page 35: Calibration Procedure

    SECTION 3 - MAINTENANCE 3.11.1 Calibration procedure Place the 8018 Thermal Transfer Printer on its side and power up. (1) Remove the ribbon after the initial calibration process has finished. (2) From the Local User Interface select 7 (Engineering), 3 (Manual Control), 3 (Tension Setup) Tension Setup Remove System Tension...
  • Page 36 SECTION 3 - MAINTENANCE 11. The LUI displays “Distance per ADC” Tension Setup Target Tension 68 Dist per ADC 0.37 Back Confirm 12. Press “Confirm” Note: The figures shown are examples and will not necessarily reflect the figures displayed for individual printers. 3-16 8018 06/08...

  • Page 37: Replacing The Solenoid

    SECTION 3 - MAINTENANCE 3.12 Replacing the Solenoid If the solenoid has to be replaced, the procedure should be as follows: Switch off and disconnect the power to the machine. 1. Undo the six retaining screws and 2. Undo the eight retaining screws and remove the cover from the printer remove the printer PCB.

  • Page 38: Replacing The Drive Belt - Intermittent

    SECTION 3 - MAINTENANCE 3.13 Replacing the Drive Belt - Intermittent The Model 8018i Intermittent printer drive belt can become worn or damaged after long periods of running. The belt should be checked at regular intervals for wear or damage. If the belt has to be replaced, the procedure is as follows: 1.

  • Page 39: Replacing The Printer Pcbs

    SECTION 3 - MAINTENANCE 3.14 Replacing the Printer PCBs If the printer PCB has to be replaced the procedure should be as follows: Switch off and disconnect the power to the printer. 2. Disconnect the connectors from the 1. Undo the six retaining screws and printer PCB.
  • Page 40 SECTION 3 - MAINTENANCE 3-20 8018 06/08...

  • Page 41: Technical Information

    SECTION 4 TECHNICAL INFORMATION 8018 Thermal Transfer Printer Operation Manual...

  • Page 43: Section 4 - Technical Information

    SECTION 4 - TECHNICAL INFORMATION Technical Information Introduction This section is designed to provide quick access to Technical information about the 8018 Thermal Transfer Printer. Topics covered in this section include: • Printer Components • Printhead Module • Printer Orientation •...
  • Page 44 SECTION 4 - TECHNICAL INFORMATION The 8018 Thermal Transfer Printer The 8018 Thermal Transfer Printer is the unit that contains all the printer mechanics together with the control electronics. Two distinct versions of the printer are available: Model 8018i - Intermittent Printer Model 8018c - Continuous Printer The Continuous model is available in left or right hand versions.
  • Page 45 SECTION 4 - TECHNICAL INFORMATION Printer Components The image below shows the main components of the printers: Ribbon supply reel Ribbon take up reel Printhead module Thermal Transfer Printhead Actuator mechanism Ribbon tension roller Ribbon movement roller Ribbon guide rollers Intermittent linear slide / Continuous print module mounting plate Figure 4–3: Intermittent Printer Components Figure 4–4: Continuous Printer Components...

  • Page 46: Intermittent Drive System - Model 8018I Printer

    SECTION 4 - TECHNICAL INFORMATION 4.3.1 Intermittent Drive System - Model 8018i Printer The intermittent version of this printer requires the printhead to move over the substrate while printing occurs. The printhead module (A) is driven backward and forward along a linear slide (C) by means of a printhead carriage (B) that is connected to the drive belt.

  • Page 47: Continuous Drive System - Model 8018C Printer

    SECTION 4 - TECHNICAL INFORMATION 4.3.2 Continuous Drive System - Model 8018c Printer The Continuous version of this printer does not require the printhead to move over the substrate while printing occurs. The print module (A) is mounted onto the print carriage (B) the same way as for the Intermittent version of this printer, but this is then fixed onto a rigid mounting block (C).

  • Page 48: Ribbon Drive System

    SECTION 4 - TECHNICAL INFORMATION 4.3.3 Ribbon Drive System The ribbon drive system is responsible for control of the ribbon tension, ribbon movement and ribbon operating speed. (A) Ribbon Take up Reel (B) Ribbon Supply Reel (C) Ribbon Movement Roller (D) Ribbon Tension Roller The ribbon drive is a direct drive system and does not require the use of a clutch.

  • Page 49: The Printhead Module

    SECTION 4 - TECHNICAL INFORMATION The Printhead Module The 8018 print module is designed to be used on all versions of the 8018 printers. The modular design means that it can be used for both Intermittent and Continuous versions of the printer. The module can also be easily changed from a left hand to a right hand version.

  • Page 50: The Print Mechanism Components

    SECTION 4 - TECHNICAL INFORMATION 4.4.1 The Print Mechanism Components The print mechanism consists of a 24V solenoid (A), an actuator mechanism (B), a print module housing (C) containing a gimballed printhead assembly (D) with thermal transfer printhead (E). The Peel Roller (F) is used to separate the Ink ribbon from the substrate after printing.

  • Page 51: Printhead Mechanism Operation

    SECTION 4 - TECHNICAL INFORMATION 4.4.2 Printhead Mechanism Operation When the Solenoid (A) is activated (1) the actuator mechanism (B) is rotated to its down position.(2) This in turn moves the printhead assembly (D) into contact with the substrate ready to print. (3) 8018 06/08...
  • Page 52 SECTION 4 - TECHNICAL INFORMATION The Model 8018i Intermittent printer also has a linear motion when printing. The distance travelled is dependant on the size of the print. The following example shows the start position (A) and end position (B) of the printhead during the printing process.

  • Page 53: Printhead Assembly

    SECTION 4 - TECHNICAL INFORMATION Printhead Assembly The printhead assembly is designed for easy removal and replacement. The assembly plate is attached to the printhead by two 3 mm dowel pins and two 3 mm cap head screws. The complete assembly can be detached from the print module easily by undoing the quarter turn spring loaded screw mechanism behind the printhead.

  • Page 54: Printer Orientation

    SECTION 4 - TECHNICAL INFORMATION Printer Orientation It is critical to the success of the printer that all parties understand the orientation of the printer. With Model 8018i printers, the substrate is stationary when being printed onto and the only issue here is access to the printer. Intermittent printers are therefore Left Hand only.
  • Page 55 SECTION 4 - TECHNICAL INFORMATION Left Hand Printer showing: Right Hand Printer showing: Angle of the Printhead. Angle of the Printhead. Direction of the Substrate travel. Direction of the Substrate travel. If the Model 8018c is to print from the underside of the substrate, and access to the printer is to face in the same direction, the opposite hand would be required.

  • Page 56: Printer Calibration

    SECTION 4 - TECHNICAL INFORMATION Printer Calibration The Model 8018i printer calibrates on power up or if the ribbon has been removed and replaced. This is done to check the diameter of the ribbon and the ribbon tension. Figure 4–10: Model 8018iIntermittent Printer Figure 4–11: Model 8018c Continuous Printer (A) Ribbon movement roller (B) Ribbon tension roller...

  • Page 57: Ribbon Movement Calibration

    SECTION 4 - TECHNICAL INFORMATION 4.7.1 Ribbon Movement Calibration Both Intermittent and Continuous versions of the 8018 Thermal Transfer Printer require the ribbon drive to be calibrated. Ribbon calibration is performed by running the two ribbon drive stepper motors. This in turn drives the ribbon round a movement roller which has a 2 pole magnet on the end of it.

  • Page 58: Ribbon Movement Roller

    SECTION 4 - TECHNICAL INFORMATION 4.7.2 Ribbon Movement Roller The ribbon movement roller (A) has a high friction coating and has a 2 pole magnet (B) on the end. The roller is fitted with bearings (C) and mounted into a housing unit (D).

  • Page 59: Printer Electrical Components

    SECTION 4 - TECHNICAL INFORMATION Printer Electrical Components The image below show the main electrical components of the printers: Ribbon Tension Sensor. Ribbon Movement Sensor. USB Port. Printhead Power/Logic Ribbon. Carriage Stepper Motor. Ribbon Stepper Motor. Ribbon Stepper Motor. Solenoid. 4-17 8018 06/08...

  • Page 60: Stepper Motors

    SECTION 4 - TECHNICAL INFORMATION 4.8.1 Stepper Motors The 8018 Thermal Transfer Printers use three stepper motors, one to drive the carriage for the printhead module and two for control of the ribbon. The 18i uses three stepper motors and the 18c two stepper motors. The position of the stepper motors is the same for all models of the 8018.

  • Page 61: Power Configuration

    SECTION 4 - TECHNICAL INFORMATION Power Configuration Connect the required power (90 - 260 V AC 50 - 60 Hz) to the power supply unit using the IEC lead provided. A 10 A fuse is used in the mains plug connector, or a 10 A MCB is recommended to protect the supply cable at source.

  • Page 62: Power Connections

    SECTION 4 - TECHNICAL INFORMATION 4.10.1 Power Connections The Interface between the Power supply and Printer is a single multi-core cable. Connection is via a six way removable screw terminal (X14) on the rear of the printer. Table 4– 1: Power Connection (X14) Pin No.

  • Page 63: Substrate Encoder Connection

    SECTION 4 - TECHNICAL INFORMATION 4.10.3 Substrate Encoder Connection The Interface between the printer and the Substrate Encoder is a single multi core cable. Connection is via a five way removable screw terminal (X12) on the rear of the printer. Table 4–...

  • Page 64: Printer Pcb

    SECTION 4 - TECHNICAL INFORMATION 4.10.5 Printer PCB The 8018 Thermal Transfer Printer printer PCB is located in the printer unit. The printer PCB controls the printhead signals, motor movement and solenoid actuation inputs and outputs. The Continuous version of the printer interfaces with a speed encoder for matching of print speed.

  • Page 65: Printer Pcb Connectors

    SECTION 4 - TECHNICAL INFORMATION 4.10.8 Printer PCB Connectors The printer PCB connectors are listed below: Table 4– 5: Printer PCB Connectors Number Connector Function Programming Header (not fitted) 24-way Ribbon Printhead Power/Logic 26-way IDC BDM Header (not fitted) Removable screw terminal Expansion 1 (not fitted) Expansion 2 (not fitted)
  • Page 66 SECTION 4 - TECHNICAL INFORMATION 4-24 8018 06/08...

  • Page 67: Troubleshooting

    SECTION 5 TROUBLESHOOTING 8018 Thermal Transfer Printer Operation Manual...

  • Page 69: Section 5 - Troubleshooting

    SECTION 5 - TROUBLESHOOTING Troubleshooting Introduction This section is designed to provide information that will help you quickly solve problems which may stop your 8018 Thermal Transfer Printer working efficiently. Topics covered in this section include: • Fault messages • Warning messages •...
  • Page 70 SECTION 5 - TROUBLESHOOTING Fault and Warning Messages The messages are listed below along with potential causes and remedial actions. 5.2.1 Fault Messages In the event of a fault, a message is displayed on the Home screen or Menu screen being accessed at the time. Some fault messages can be temporarily hidden by pressing the “Hide”...
  • Page 71 SECTION 5 - TROUBLESHOOTING Table 5– 1: Fault Messages Fault Message 1006 - Software Assert Possible The software has experienced an error condition. Causes Remedial Re-power the printer. Action Fault Message 1007 - Printhead Resistance Not Set Possible A new printer PCB has been fitted. Causes Remedial Set the printhead resistance level.
  • Page 72 SECTION 5 - TROUBLESHOOTING Table 5– 1: Fault Messages Fault Message 1104 - Calibration Failed initial Tension No ribbon fitted. The ribbon is not webbed up correctly. Possible Wrong ribbon width selected. Causes The supply spool is slipping. The take up spool is slipping. The printer is set to the wrong printer type.
  • Page 73 SECTION 5 - TROUBLESHOOTING Table 5– 1: Fault Messages Fault Message 1201- Ribbon Fault The ribbon has broken during calibration. Possible The ribbon has broken during printing. Causes The ribbon tension sensor is faulty. Re- web the ribbon. Remedial Use the diagnostic screen to check the ribbon tension Action sensor input signal.
  • Page 74 SECTION 5 - TROUBLESHOOTING Table 5– 1: Fault Messages Fault Message 1400- Corrupt File system Possible The database has become corrupted. Causes Remedial Use the “Restore to Factory” defaults function and re- Action download the Image. Fault Message 1401 - Failed to Restore Image Possible Image / Font file missing Causes...
  • Page 75 SECTION 5 - TROUBLESHOOTING 5.2.2 Warning Messages In the event of a warning, a message is displayed on the Home screen or Menu screen being accessed at the time. Home screen warnings can be hidden by pressing the “Hide” option button. If the same warning re-occurs the message will be displayed again.
  • Page 76 SECTION 5 - TROUBLESHOOTING Warning Message 2105 - Discarded Print Possible The printer has auto-aborted a print in Low speed reprint Causes mode. Remedial Increase the substrate speed. Action Warning Message 2107 - Substrate Over speed Possible The substrate is travelling faster than the maximum print Causes speed of the 8018 Thermal Transfer Printer.
  • Page 77 SECTION 5 - TROUBLESHOOTING Warning Message 2201 - Settings Corrupt Possible The printer settings have become corrupted. Causes Remedial By clearing this message the settings will be set to default Action values. Warning Message 2207 - File System Nearly Full Possible The File system is almost full.
  • Page 78 SECTION 5 - TROUBLESHOOTING Warning Message 2300 - Printer High Temperature Possible The printer temperature is reaching an unacceptable level. Causes Remedial Turn off the power to the 8018 Thermal Transfer Printer and Action allow the printer to cool down. Warning Message 2302 - Printhead Under Temperature Possible The printhead temperature has not yet reached an acceptable...

  • Page 79: No Power To The Printer

    SECTION 5 - TROUBLESHOOTING Common Issues Listed below are a number of possible faults and suggestions for possible corrective actions. 5.3.1 No Power to the Printer • Power switch must be in the ON position. This switch is located at the rear of the power supply •...

  • Page 80: Drive System Issues

    SECTION 5 - TROUBLESHOOTING Drive System Issues 5.6.1 Ribbon is not driving • Check that the ribbon cores on the supply and take up spools are not slipping. You can see this by taking the ribbon core off and looking on the inside. •...

  • Page 81: Ribbon Coning (Continuous Printers)

    SECTION 5 - TROUBLESHOOTING 5.6.5 Ribbon Coning (Continuous Printers) If there is a problem with the waste ribbon coning on the take up reel, check the following: • Ensure that the printhead is aligned correctly with the print roller. (See Installation) If incorrectly aligned this will cause tracking problems.

  • Page 82: Printhead Module Carriage Drive Problems

    SECTION 5 - TROUBLESHOOTING Printhead Module Carriage Drive Problems A stepper motor, drive belt and linear slide are used to move the Printhead module carriage. The carriage drive may stall when the 8018 Thermal Transfer Printer is under excessive load. If the carriage does not drive, check the following: •...

  • Page 83: Print Quality Problems

    SECTION 5 - TROUBLESHOOTING Print Quality Problems The most common causes of poor print quality are: • Dirty printhead: Clean the printhead with the Markem.Imaje Isopropanol wipes and try again. Take care not to damage the printhead during cleaning. Always allow the printhead to cool prior to cleaning.

  • Page 84: Faded On One Side

    SECTION 5 - TROUBLESHOOTING 5.9.2 Faded on one side This is generally due to a misalignment of the printer to the platen roller/ pad. The printhead will move down to print on the substrate, and will hit one side of the roller/ pad first.

  • Page 85: Elongated Or Compressed Print

    SECTION 5 - TROUBLESHOOTING 5.9.6 Elongated or compressed print (Intermittent printers) The printhead is printing on the substrate when it is still moving. Modify the Print Delay Parameter. Depending on whether the application is printing in the same direction of the substrate or against the direction of substrate movement depends on whether you will need to increase the Print Delay or reduce it.

  • Page 86: Image Selection Problems

    SECTION 5 - TROUBLESHOOTING 5.10 Image Selection Problems 5.10.1 Selecting an Image A valid Image or test pattern must be present in the printer memory for 8018 Thermal Transfer Printer to able to print something. This can be done by selecting a test pattern in Engineer mode.

  • Page 87: Spares And Replacement Parts

    SECTION 6 SPARES AND REPLACEMENT PARTS 8018 Thermal Transfer Printer Operation Manual...

  • Page 89: Consumables

    SECTION 6 - SPARES AND REPLACEMENT PARTS Spares and Replacement Parts Note: Fasteners may be sold in economic pre-packed quantities. Consumables Table 6– 1: Consumables Part Number Description Quantity 10018596 Thermal transfer printhead assembly 10018602 Platen Anvil rubber B03285AA Head cleaning kit B03286AA Cleaning kit top up 5824648...
  • Page 90 SECTION 6 - SPARES AND REPLACEMENT PARTS Table 6– 3: Replacement Parts (Mechanical) Part Number Description Quantity 10018720 Passive guide roller assembly 10018836 Peel roller assembly 10018607 Movement roller assembly 10018608 Tension roller assembly 10018609 Passive dancing arm assembly 10018598 Toothed drive belt 10018599 Ribbon hub assembly...
  • Page 91 SECTION 6 - SPARES AND REPLACEMENT PARTS Table 6– 4: Replacement Parts (Electrical) Part Number Description Quantity 10018779 Complete Local User Interface 10018780 Complete Power supply unit 10018781 Power supply module 10018604 Printer PCB 10018719 Printhead Interface PCB 10018696 Power cable assembly 10018613 24V I/O cable assembly 10018612...
  • Page 92 SECTION 6 - SPARES AND REPLACEMENT PARTS Printhead Assembly Printhead Interface PCB Part No. 10018596 Part No. 10018719 Printhead Carriage Assembly Printhead Advance Assembly Part No. 10018706 Part No. 10018707 Printhead Cover Assembly Carriage Adapter Plate Part No. 10018605 Part No. 10018597 18c Printhead Carriage Adapter Plate 18i Printhead Carriage Slide Part No.
  • Page 93 SECTION 6 - SPARES AND REPLACEMENT PARTS Passive Roller Assembly Peel Roller Assembly Part No. 10018720 Part no. 10018836 Passive Dancing Arm Assembly Tension Roller Assembly Part No. 10018609 Part No. 10018608 Movement Roller Assembly Drive Belt Idler Assembly Part No. 10018607 Part No.
  • Page 94 SECTION 6 - SPARES AND REPLACEMENT PARTS Roller Hub Assembly Hub Spacer Disc Part No. 10018599 Part no. 10018600 Rear Cover Assembly Dust Cover Clear Part No. 10018705 Part No. 10018601 PCB mounting Pillar PCB Heatsink Bracket Assembly Part No. 10018711 Part No.
  • Page 95 SECTION 6 - SPARES AND REPLACEMENT PARTS Ribbon Motor Assembly Carriage Motor Assembly Part No. 10018709 Part no. 10018724 Main PCB Assembly Solenoid Assembly Part No. 10018604 Part No. 10018708 Tension Sensor PCB Assembly Ribbon Movement PCB Assembly Part No. 10018712 Part No.
  • Page 96 SECTION 6 - SPARES AND REPLACEMENT PARTS Local User Interface Local User Interface Cradle Part No. 10018779 Part no. 10018701 LUI Cable Assembly 24V Cable Assembly Part No. 10018612 Part No. 10018613 Power Supply Part No. 10018780 Bracket Roller Assembly Part No.
