- Page 1 ORDINARY MAINTENANCE FLAKERS SPN | SPR | SNM | SMI...
- Page 2 Dear Customer, this manual contains all the information necessary for the use and routine maintenance of the product. We therefore recommend that you read it carefully before use and keep it carefully for future reference. If any step is not understood well, the Manufacturer remains available to provide any information.
-
Page 3: Table Of Contents
Safety page 4 Knowing the appliance page 8 Using the appliance page 11 Cleaning and maintenance of the appliance page 13 Service page 16 For any information, always state: • product model • serial number • data in the purchase invoice... -
Page 4: Safety
OPERATING LIMITS SAFETY Minimum Maximum Pictogram explanation Ambient working temperature 10°C 43°C Water temperature 5°C 38°C Indicates that caution is required when 0.1 MPa 0.5 Mpa performing an operation described in a Water pressure 1 Bar 5 Bar paragraph that bears this symbol. The symbol also indicates that maximum Voltage tolerance with operator awareness is required in order to... - Page 5 If the power cable is damaged, have it To ensure the best conditions of use and replaced ONLY by QUALIFIED safety of the appliance, once or twice a PERSONNEL in order to prevent any risks. year (or according to the provisions of the Before carrying out any routine cleaning national regulations in force) contact the or extraordinary maintenance, it is...
- Page 6 INSTALLATION INSTRUCTIONS REFRIGERANT GAS SAFETY WARNINGS Installation must be performed by Propane is a highly flammable gas. authorized technicians. The appliance contains fluorinated When installing the appliance, replace greenhouse gases governed by the the existing water supply tubes with the Kyoto protocol, in the quantities indicated on new ones supplied with it.
-
Page 8: Knowing The Appliance
("model" field). SNM | SPN series models should be installed on top of a separate ice bin; an outlet kit is available as an option to be able to unload onto a conveyor belt or a low container on wheels placed on the side or rear. - Page 9 Type for instance 2103 21: year | 2021 Coolant data 03: month | March Certifications SNM | SPN series SMI | SPR series Granular ice maker Granular ice maker without built-in ice container with built-in ice container A Ice container door...
- Page 10 KNOWING THE BUTTONS AND LIGHTS Indicator lights “B” give useful information on the status of the machine. Powered appliance warning light If on, it indicates that the appliance is electrically powered (plug inserted and the main switch of the room system in the ON position).
-
Page 11: Using The Appliance
USING THE APPLIANCE This appliance can be used by children aged 8 and over and by people with reduced physical, sensory or mental abilities or with a lack of experience and knowledge only if they have been adequately instructed and supervised in the safe use of the appliance and have learned the possible dangers derived from its use. - Page 12 After a few minutes the first ice will be released which can then be removed from the container using the scoop provided. Then, more ice will be released, until the container is filled, without the need to press any button. To avoid overfilling the built-in container and possible leakage of the ice, inside the container there is a sensor that stops production if the maximum capacity level is exceeded;...
-
Page 13: Cleaning And Maintenance Of The Appliance
CLEANING AND MAINTENANCE OF THE APPLIANCE Ordinary cleaning DAILY Clean the ice scoop with the manufacturer’s Before carrying out any ordinary or disinfectant mixed with warm water (1 ml in 1 litre of extraordinary maintenance, it is water, the dilution percentages are also indicated on necessary to disconnect the appliance from the rear label of the product). - Page 14 Clean the front or side “C” air vents with a EVERY 6 MONTHS / 1 YEAR soft bristle brush or vacuum cleaner. Contact the official local Dealer/Distributor for washing, descaling and sanitizing the water circuit. Clean the control panel and the door with a soft cloth EVERY YEAR slightly moistened with a neutral detergent suitable for delicate surfaces.
- Page 15 Problems and solutions PROBLEM SOLUTION • Check that there is no black-out, that the main switch of the dedicated panel has The appliance does not not blown and that the plug is correctly inserted in the socket. switch on If none of these solutions solves the problem, contact Technical Assistance. •...
-
Page 16: Service
SERVICE Your appliance is reliable and sturdy but sometimes Manufacturer: small problems may arise that, thanks to our service centres, are quickly resolved. Before contacting them: • try and refer to the following tables; • get the model and serial number of the appliance, both of which can be found on the serial number plate on the back of the appliance (see page 9) - Page 17 Any unauthorized reproduction, even partial, of the content of these instructions is expressly prohibited. These instructions and all accompanying documentation have been checked prior to sale. If errors or inaccuracies are found, please inform the Manufacturer. The manufacturer reserves the right to make improvements to the appliance or accessories at any time, without notice. Measurements are purely indicative and not binding.
