Programming Instructions - Valcom V-2006A User Manual

PROGRAMMING FEATURE CHART
LED FEATURES
D1 Handsfree (with V-2006AHF only)
D2 Background Music
D3 Night Ring
D4 Clock Tones
D5 Included in Group #1
D6 Included in Group #2
D7 Included in Group #3
D8 Included in All Call
PROGRAM EXAMPLE:
Zone 6 Programmed for One-Way Paging, Background Music, Night Ring, Clock Tones, Not in Group 1-2 or 3 and All Call.

PROGRAMMING INSTRUCTIONS

System programming is non-volatile and is not affected by power outages .
1. Complete Programming Feature Chart.
2. Connect a single line tone dial phone or butt set to the RJ11 jack J6 (Program Jack).
3. Go OFF HOOK, all LEDs illuminate for 1 second and then extinguish. Program tone will be heard.
4. Press # key (program tone breaks).
5. Dial the number of the zone to be programmed. Program ready tone (3 short bursts will be heard and the
first LED will flash).
6. Enter "1" to Enable or "0" to Disable each of 8 features listed in chart above. As each entry is made, the next
LED will begin flashing.
PROGRAM TESTING INSTRUCTIONS
1. Connect a single line tone dial phone or butt set to the RJ11 jack J6 (Program Jack).
2. Go OFF HOOK, all LEDs illuminate for 1 second and then extinguish. Program tone will be
heard.
3. Press * key (program tone breaks). Dial the number of the zone to be checked.
4. Illuminated LEDs represent enabled features.
5. LEDs extinguish after 5 seconds and program tone returns.
6. Repeat the procedure for each zone.
NOTES:
1. If the telephone is unplugged from the program jack while programming a zone, the existing
program for that zone will not be affected.
2. The control unit cannot be used for paging while a telephone is plugged into the program jack and
receiving the "PROGRAM TONE."
3. If numbers other than 1-6 are dialed after dialing "#" or "*", a re-order tone will be heard.
Programming must be initiated again, starting with going off hook.
4. If numbers other than "1" or "0" are dialed after dialing "#" and a valid zone number, the re-order
tone will be heard. Programming must be started over beginning with going off hook.
5. Tone Definitions:
• Program Tone/Dial Tone-Continuous Tone - (20Hz, square wave).
• Program Ready Tone/Override Busy Tone - Three short bursts of tone; 1/4 second on, 1/4
second off (40 Hz, square wave).
• Re-Order Tone - Interrupted tone; 1/2 second on, 1/2 second off (400Hz, square wave).
ZONES
1 2 3 4 5
6
To Program Each
PROGRAM
*
EXAMPLE
Zone
6 6 Press: #
0 Dial: Zone Number
1 Enter: "1" to Enable
1 Or
1
0
0
0
1
"0" to Disable
For each of
the 8 features
