Y O U R M A C H I N E ( E X P L O D E D V I E W ) - ChocoVision Revolating Delta Owner's Manual

Y O U R M A C H I N E
22
20
19
18
17
14
13
12
7
6
4
1
-3-
2
1. MAIN CASE
2. BOWL COUPLER
3. HEAT OUTLET
21
4. EXHAUST FAN
5. INTAKE FAN
6. PROBE CONTACTS
(CASE)
7. BAFFLE MOUNTS (2)
8. POWER SWITCH
9. KEYPAD
10. DISPLAY WINDOW
11. BOWL LOCATORS
16
12. BOWL RING
15 13. BOWL
14. SCRAPER
15. BAFFLE
16. BAFFLE CLIP
17. PROBE
18. PROBE CONTACTS
11
(BAFFLE)
19. BAFFLE KNOBS (2)
20. DUST COVER
5 8
3
21. DUST COVER LID
22. HOPPER
NOTE : When using HOPPE R ,
10
DUS T COVE R LID cannot be used.
9
