GC 365 R / SF
160272-05
5930221 OCT 2022 NI-0179-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GC 365 R / SF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GEZE GC 365 R / SF

Summary of Contents for GEZE GC 365 R / SF

  • Page 1 GC 365 R / SF 160272-05 5930221 OCT 2022 NI-0179-1...

  • Page 2: Table Of Contents

    GC 365 R / SF Translation of the original operating instructions for device version CC Contents Symbols and illustrations .................3 Abbreviations .......................3 Product liability ....................3 Safety ......................3 Intended use........................3 Safety notices ........................4 Safety-conscious working ....................5 Environmentally conscious working ................5 Description ....................5 Dimensions and overview .....................6...

  • Page 3: Symbols And Illustrations

    Intended use The combined detector GC 365 R / SF may only be used to activate and pro- tect automatic sliding doors and curved sliding doors with GEZE drives. The minimum object size corresponds to the reference object CA in accordance with DIN 18650 or DIN EN 16005 both upright and lying down.

  • Page 4: Safety Notices

    à Make sure that the cover of the drive is fitted correctly and earthed. à If unauthorised changes are made to the system, GEZE cannot be held liable in any way whatsoever for any resulting damage, and the approval for use on escape and rescue routes ceases.

  • Page 5: Safety-Conscious Working

    à When disposing of the sensor, separate the different materials and have them recycled. Description The combined detector GC 365 R / SF have a radar field for detecting move- ment and an infrared field for protection. It is not possible for several systems to influence each other and result in a hazard.

  • Page 6: Dimensions And Overview

    Description GC 365 R / SF 2. 1 Dimensions and overview Cover Adjustment screw for depth angle Suspension Width adjustment screws Adjustment tool AIR transmitter DIP switch AIR receiver Potentiometer for radar sensitivity LED display Function switch Connecting plug Radar module...

  • Page 7: Supplied By Geze

    GC 365 R / SF Work to be done before installation Supplied by GEZE Work to be done before installation 3. 1 Installing the drive Make sure that the cover of the drive is fitted correctly and earthed.

  • Page 8: Safety Sensor System

    Work to be done before installation GC 365 R / SF Safety sensor system One combined detector per passage direction is installed on automatic slid- ing doors. The safety sensor GC 341 may be required in addition for larger opening widths.

  • Page 9: Installation

    GC 365 R / SF Installation Installation 4. 1 Installation without accessories Avoid extreme vibrations. Do not cover the sensor. Keep away from fluorescent lamps. Keep away from moving objects. Avoid highly reflective objects in the infrared range. Keep a distance of at least 200 mm away from lights, signs or hot air curtains.

  • Page 10: Installation With Ceiling Installation Kit

    Installation GC 365 R / SF Installation with ceiling installation kit...
  • Page 11 GC 365 R / SF Installation click...

  • Page 12: Installation With Mounting Bracket

    Installation GC 365 R / SF Installation with mounting bracket M4 x 6...

  • Page 13: Installation With Weather Hood

    GC 365 R / SF Installation Installation with weather hood...

  • Page 14: Cabling

    Installation GC 365 R / SF Cabling Connect the cable to the door control. Heed wiring diagrams for the sliding door drives. GC 365 SF GC 365 R Connect the sensor to the power supply.

  • Page 15: Commissioning

    GC 365 R / SF Commissioning Commissioning 5. 1 Adjusting the radar sensor Adjust the detection area and sensitivity of the radar sensor as per AutSchR: à Detection area = opening width x 1.5 m à Movement speed from 10 cm/s must be detected.
  • Page 16 Commissioning GC 365 R / SF Replacing radar lenses (narrow and wide) Adjusting radar sensitivity Adjust the radar detection range using the potentiometer. Then press the function switch for 2 s. Installation height: 2.2 m Wide range Vertical adjustment: + 35°...

  • Page 17: Adjusting The Protection Area With Spot Finder

    GC 365 R / SF Commissioning Adjusting the protection area with spot finder The position of the AIR curtain in relation to the door can be checked us- ing a spot finder. max. 9 cm Near max. 20 cm...
  • Page 18 Commissioning GC 365 R / SF à Make sure that the whole width of the door is covered. à Test the width of the required area using a piece of paper (DIN A4), since the spot finder detects over the whole emission area.

  • Page 19: Adjusting The Protection Area Without Spot Finder

    GC 365 R / SF Commissioning Adjusting the protection area without spot finder Press the function switch for 5 s to activate service mode. The LED display starts to flash yellow/green. The max. AIR time is auto- matically set to 2 s.

  • Page 20: Dip Switch Settings

    Commissioning GC 365 R / SF DIP switch settings Only change the switch settings when the power supply is on. After changing the DIP switches, press the function switch for 2 s (until the LED goes out). The teach-in process starts automatically.
  • Page 21 GC 365 R / SF Commissioning...
  • Page 22 Commissioning GC 365 R / SF...
  • Page 23 GC 365 R / SF Commissioning...

  • Page 24: Last Installation Steps

    Last installation steps GC 365 R / SF Last installation steps Before completing the installation, check the sensor for correct function.

  • Page 25: Further Installation Situations

    GC 365 R / SF Further installation situations Further installation situations 7. 1 Single leaf installation Installation height Distance between Max. leaf width* Detection width (in mm) detector and main (in mm) DIN 18650/DIN EN closing edge (in mm) 16005 (in mm)

  • Page 26: Lintel Installation

    Maintenance GC 365 R / SF Lintel installation According to DIN 18650/DIN EN 16005, the distance between the inner light curtains must not exceed 200 mm. In the case of other dimensions, please contact the sales department first. Installation height a Max. reveal depth b...

  • Page 27: Fault Messages And Troubleshooting

    GC 365 R / SF Fault messages and troubleshooting Fault messages and troubleshooting 9. 1 Fault messages Effect Cause Elimination display Correct operation Flashes Signal saturation Remove strongly reflect- green (lookback) ing objects from the slowly. detection area. Reduce AIR: Filter.
  • Page 28 Fault messages and troubleshooting GC 365 R / SF Effect Cause Elimination display Door opens even Moving or light- Remove the objects. though there is steady emitting objects in no-one in the the detection area detection area The detection area Check DIP switches 5 (ghost effect).
  • Page 29 GC 365 R / SF Fault messages and troubleshooting Effect Cause Elimination display Door remains open. Correct Detection area sud- Check DIP switches 1 to 4. denly changed If the problem persists, reset the sensor com- pletely (switch the power off and on again).

  • Page 30: Led-Display Table

    Fault messages and troubleshooting GC 365 R / SF LED-display table 1000 ms 1000 ms Status LED display colour Set-up Flashes yellow Stand-by Yellow (installation mode) Stand-by Flashes yellow and (service mode) green Stand-by Green (operating mode) Lookback (1 row)

  • Page 31: Technical Data

    GC 365 R / SF Technical data Technical data Power supply: 12 – 24 V AC ± 10% (50/60 Hz) 12 – 30 V DC ± 10% (protected against reverse polarity) Power consump- < 2.5 W (< 4 VA with AC)

  • Page 32: Accessories/Spare Parts

    Accessories/spare parts GC 365 R / SF Accessories/spare parts Material no. Ceiling bracket 160286 Ceiling adapter 160288 Weather hood 160287 Spot finder 112321 GC 362/GC 363 to GC 365 204529 Retrofit Adaptor GC 365 8 pole to 10 pole 204530...
  • Page 33 GC 365 R / SF...
  • Page 34 GC 365 R / SF...
  • Page 35 GC 365 R / SF...
  • Page 36 Germany China Romania GEZE GmbH GEZE Industries (Tianjin) Co., Ltd. GEZE Romania S.R.L. E-Mail: office-romania@geze.com Niederlassung Süd-West E-Mail: chinasales@geze.com.cn Tel. +49 (0) 7152 203 594 www.geze.com.cn www.geze.ro E-Mail: leonberg.de@geze.com Russia GEZE Industries (Tianjin) Co., Ltd. GEZE GmbH Branch Office Shanghai OOO GEZE RUS Niederlassung Süd-Ost...
