GEZE GC 365 R Original Instructions

GC 365 R / GC 365 SF
MANUFACTURER'S STATEMENT
MANUFACTURER'S STATEMENT
Read this operation manual carefully before use to ensure proper operation of this product.
Failure to read this operation manual may cause improper operation and may result in serious injury or death of
a person.The meanings of the symbols are as follows.
Disregard of the warning symbol can cause improper operation which may cause death
WARNING
or serious injury.
Disregard of the caution symbol can cause improper operation which may cause injury of a
CAUTION
person or damage the object.
NOTE Special attention is required to the section of this symbol.
NOTE
1. This product is a non-contact switch intended for operator cover mount or wall mount for use on an
automatic sliding door. Do not use for any other applications.
2. When setting the sensor's detection area, make sure that there is no traffic around the installation site.
3. Before turning the power ON, check the wiring to prevent damage or malfunction of equipment connected to
the product.
4. Only use the product as specified in the operation manual provided.
5. Be sure to install and adjust the sensor in accordance with the local laws and standards of the country in which
the product is installed.
6. Before leaving the installation site make sure that the product is operating properly and instruct the building
owner/operator on proper operation of the door and the product.
7.The product settings can only be changed by an installer or service engineer. When changed, the
changed settings and the date shall be registered in the maintenance logbook accompanying the door.
WARNING
Do not wash, disassemble, rebuild or repair the sensor, otherwise
it may cause electric shock or breakdown of the equipment.
Danger of electric shock
NOTE
The following conditions are not suitable for sensor installation.
-Fog or exhaust emission around the door
-Wet floor
-Vibrating operator cover or mounting surface
-Moving objects, steel plate, emergency lights or illumination in the detection area or in vicinity
-Highly reflecting floor or highly reflecting objects around the door
- Make sure that the operator's hood has been earthed.
SPECIFICATIONS
Model : GC 365 R / GC 365 SF
Cover color : Black
Mounting height : 2.0 (6'7") to 3.5 m (11'6")
Detection area : See DETECTION AREA
Detection method : Active infrared reflection (*1)
Radar doppler effect
Depth angle : AIR area -6 to +6 °
adjustment
Radar area +25 to +45 °
Power supply (*2) : 12 to 24 VAC ±10 % (50 / 60 Hz)
12 to 30 VDC ±10 %
Power consumption : < 2.5 W (< 4 VA at AC)
Operation indicator : See Operation indicator table
Output hold time : <500 ms
Response time : <300 ms
Operating : -20 to +55 °C (-4 to 131 °F)
temperature
Relative air humidity : <80 %(non-condensing)
Noise level : <70 dBA
Table 1
GC 365 R
Cat.
2 (EN ISO13849-1 : 2008)
AIR
part
PL
d (EN ISO13849-1 : 2008)
Cat. 3 (EN ISO13849-1 : 2008)
Radar
part
PL d (EN ISO13849-1 : 2008)
Operation indicator table
Status Operation indicator color
Set-up Yellow Blinking
Installation mode
Operating mode
Lookback (1st row) detection(*4)
2nd row detection
3rd row detection
Radar detection
Adjustment confirmation required Red & Green Blinking
Signal saturation Slow Green Blinking
Sensor failure / sensitivity too low Fast Green Blinking
NOTE
The specifications herein are subject to change without prior notice due to improvements.
*1 : Active infrared reflection has a presence detection function.
*2 : The sensor has to be connected to a door system which has a SELV circuit.
*3 : Overcurrent protection with less than 2 A.
OUTER DIMENSIONS AND PART NAMES
267(10 1/2")
125(4 15/16")
36(1 7/16") 43(1 11/16")
(2)
(1)
(3) (4) (5) (6)
LOOKBACK AREA
When DIP-switch 15 is set to "ON", the lookback area, that provides extra safety over the threshold, is activated.
In case the lookback function is not required, set DIP-switch 15 to "OFF".
Do not set the 2nd row overlapping the threshold regardless of the setting of DIP-switch 15.
2nd row
Lookback
(1st row)
3rd row
ENGLISH
Radar output : See INSTALLATION 2
Test input : Opto coupler
Voltage 5 to 30 VDC
Current 6 mA Max. (30 VDC)
Safety output : Opto coupler (NPN)
Voltage 5 to 50 VDC
Current 100 mA Max.
Dark current 600 nA Max.
IP rate : IP54
Category : See Table 1
Performance level : See Table 1
ESPE : Type 2
Weight : 270 g (9.5 oz )
Accessories : 1 Operation manual
2 Mounting screws
1 Mounting template
1 Area adjustment tool
1 Cable 3 m (9'10")
( 8×0.22 mm² AWG24 ) (*3)
GC 365 SF
1000 ms
Yellow
Green
Blue
Red Blinking
Red
Orange
*4 : See LOOKBACK AREA
[mm (inch)]
38(1 1/2")
(1) Connector
(2) Mounting holes
(3) Operation indicator
(4) Width adjustment screws
(5) Depth angle adjustment screw
(10)
(6) Function switch
(7) Radar sensitivity potentiometer
(8) DIP-switches
(9) Detection window
(9) (10) Area adjustment tool
(7) (8)
Lookback
2nd row
(1st row)
3rd row
COMPLIED STANDARDS
AND EXTRACT FROM EC DECLARATION OF CONFORMITY
EMC Directive 2004/108/EC
EN 61496-3:2001 clause 4. 3. 5 and 5. 4. 7. 3
EN 61000-6-2:2005
EN 16005:2012
DIN 18650-1:2010
DETECTION AREA
A
Lookback (1st row)
2nd row
3rd row
1.0(3'3")
2.0(6'7")
2.0
(6'7")
AIR emitting area
The chart shows the values at depth angle +6 °
A 2.00 (6'7")
B 0.05(2")
C
0.07(3")
D 0.23 (9")
E 0.35 (1'2")
F 0.59 (1'11")
G 1.21 (3'12")
H 1.86 (6'1")
I 2.52(8'3")
AIR detection area
To comply with EN 16005 and DIN 18650, make sure that the detection area is within the values of the chart below.
A 2.00 (6'7")
X 0.23 (9")
G 1.02 (3'4")
I* 2.41 (7'11")
The values above are those of the AIR detection area when tested referring to the test conditions of
EN 16005 and DIN 18650. (The emitting area is as shown in AIR emitting area above.)
*: When installed at higher than 3.0 m(9'10"), EN 16005 and DIN 18650 requirements are fulfilled only within
the area width "I" of 3.6 m(11'10").
NOTE The actual detection area may become smaller depending on the ambient light, the color / material of
the object or the floor as well as the entry speed of the object.
The sensor may not be activated when the entering speed of the object or a person is slower than
50 mm / s or faster than 1500 mm / s
INSTALLATION
1
1. Affix the mounting template at the desired mounting position.
(Resistance load)
(When setting the detection area close to the door, mount the sensor according to the chart below.)
2. Drill two mounting holes of ø3.4 mm (ø1/8").
3. To pass the cable through the operator cover, drill a wiring hole of ø8 mm (ø5/16").
4. Remove the mounting template.
5. Remove the housing cover. Fix the sensor to the mounting surface with the two mounting screws.
Operator cover
Sensor
Y
X
H
Door
1000 ms
Floor
CAUTION
Risk of getting caught
2
1
Form A relay
2
50 V 0.3 A Max.
3
4
WARNING
Danger of electric shock
1.Plug the connector.
3
2.Supply power to the sensor. Adjust the detection area and set the DIP-switches.
(See ADJUSTMENTS 4. DIP-switch settings)
Make sure to connect the cable correctly to the door controller before turning the power ON.
NOTE
When turning the power ON or after adjusting the settings, do not enter the detection area for more
than 10 seconds in order to enable the presence detection.
Do not touch the DIP-switches before turning the power ON, otherwise an error occurs.
After changing the DIP-switch and/or potentiometer settings, make sure to push the function switch
for 2 seconds.
Place the housing cover.
4
If wiring is to be exposed, break the knockout.
WARNING
Danger of electric shock
EN 12978:2003 +A1:2009
EN ISO 13849-1:2008
AutSchR
[m(feet,inch)]
B
C
G
H
I
1.0 0 1.0 2.0
(3'3") (3'3") (6'7")
2.20 (7'3") 2.50 (8'2") 2.70 (8'10") 3.00 (9'10")
0.06 (2") 0.07 (3") 0.074(3") 0.08 (3")
0.08 (3") 0.09 (4") 0.10 (4") 0.11 (4")
0.25 (10") 0.28 (11") 0.31 (1') 0.34 (1'1")
0.39 (1'3") 0.44 (1'5") 0.48(1'7") 0.53 (1'9")
0.65 (2'2") 0.74 (2'5") 0.80 (2'7") 0.89 (2'11")
1.33 (4'4") 1.51(4'11") 1.63 (5'4") 1.81 (5'11")
2.05 (6'9") 2.32 (7'7") 2.51 (8'3") 2.79 (9'2")
2.78 (9'1") 3.15 (10'4") 3.40 (11'2") 3.79 (12'5")
Test conditions required by EN 16005 and DIN 18650
2.20 (7'3") 3.00 (9'10")
Floor :Grey paper
0.25 (10") 0.34 (1'1")
Detection object : EN 16005 and DIN 18650 CA reference body
1.12 (3'8") 1.53 (5')
Sensitivity : Middle
2.65 (8'8") 3.60 (11'10")
Speed of detection object : 50 mm / s
H : Height from the floor to the bottom of the operator cover.
(The mounting height is "H + Y".)
Y : Distance between the bottom of the operator cover and the sensor
X : Distance between the door and the mounting surface
Maximum mounting distance (Y)
H
X 2.00 (6'7") 2.30 (7'7") 2.50 (8'2")
No limit
0
0.05 (2") 0.13 (5") 0.13 (5") 0.13 (5")
0.12 (5") 0.12 (5")
0.10 (4") 0.11 (4")
0.10 (4") 0.11 (4")
0.15 (6") 0.10 (4")
0.09 (4") 0.10 (4")
0.20 (8") -
- - 0.09 (4")
0.25 (10")
- -
0.30 (12") -
NOTE Make sure not to mount the sensor lower than the bottom of operator cover.
Make sure to affix the mounting template as described in the above chart,
otherwise it can be dangerous since there may be no detection area around
the threshold. Install the sensor as low as possible on the operator cover.
GC 365 R
SIS1
SIS2
KI
KA
RBM
GND GND
12 to 24 VAC±10 % / 12 to 30 VDC±10 %
Opto coupler(NPN) / Voltage: 5 to 50 VDC
Opto coupler / Voltage: 5 to 30 VDC
Before starting the procedure, make sure that the power is turned OFF.
When passing the cable through the hole, do not tear the shield
otherwise it may cause electric shock or breakdown of the sensor.
Do not use the sensor without the cover.
When using the cable knockout, install the sensor indoors or use the rain cover
(Separately available) otherwise electric shock or breakdown of
the sensor may occur.
Machinery Directive 2006/42/EC
EN ISO 13849-2:2012
R & TTE Directive
EN 61000-6-3:2007 +A1:2011
AIR
Mounting height : 2.2 m(7'3")
Angle adjustment : +6 °
Sensitivity : Middle
Mounting : IR spots
surface
: IR spots
D
(can be turned off)
E
: Detection area
X F
Radar
Mounting height : 2.2 m(7'3")
Vertical adjustment : +35 °
Sensitivity : High
Area width : wide
Speed of detection object
: 50 mm / s
: Detection area
[m(feet,inch)]
3.50 (11'6")
0.09 (4")
0.12 (5")
0.39 (1'3")
0.61 (2')
1.03(3'5")
2.11 (6'11")
3.25 (10'8")
4.42 (14'6")
[m (feet,inch)]
2.80 (9'2") 3.00 (9'10") 3.50 (11'6")
0.14 (6") 0.14 (6") 0
0.12 (5") 0.12 (5") 0
0.11 (4") 0
0.11 (4")
0.10 (4") 0.10 (4") 0
0.09 (4") 0.09 (4") 0
- 0
-
GC 365 SF
GR
KI KA
+UB
YE GND GND
24V 24V
KI KA
Frequency output
100 Hz±10 %
