Hold-open system
EN
Wiring diagram
FA GC 150
Instructions for installation, commis-
sioning, operation and maintenance
RSZ 6, RSZ 7,
TS 4000 R, TS 4000 RFS, TS 4000 R-IS,
TS 5000 R, TS 5000 RFS, TS 5000 RFS
KB,
TS 5000 R-ISM /G/S/0, TS 5000 R-ISM
EFS,
Slimdrive EMD F/R*, Slimdrive EMD
F/R-IS*,
Powerturn F/R*, Powerturn F/R-IS*,
Powerturn F/R-IS/TS*
141512_07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FA GC 150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GEZE FA GC 150

Summary of Contents for GEZE FA GC 150

  • Page 1 Hold-open system Wiring diagram FA GC 150 Instructions for installation, commis- sioning, operation and maintenance RSZ 6, RSZ 7, TS 4000 R, TS 4000 RFS, TS 4000 R-IS, TS 5000 R, TS 5000 RFS, TS 5000 RFS TS 5000 R-ISM /G/S/0, TS 5000 R-ISM...

  • Page 2: Table Of Contents

    GEZE hold-open system FA GC 150 Contents Symbols and illustrations ............................4 Notes ....................................4 Installation and electrical connection of the hold-open system ....................4 Installation of the lintel-mounted smoke switch ..........................5 Protecting a smoke switch from contamination ..........................5 Disposal ..........................................5 Hold-open system FA GC 150 ..........................6 Function ..........................................6...
  • Page 3 GEZE hold-open system FA GC 150 5.4.3 Wireless ceiling-mounted detector wired – wireless input modules GC 175 ................. 37 Wireless input module GC 175 .................................. 37 5.5.1 Manual trigger switch UTA ..................................38 5.5.2 Contact to the fire alarm system ................................38 5.5.3...

  • Page 4: Symbols And Illustrations

    Symbols and illustrations GEZE hold-open system FA GC 150 Symbols and illustrations Warning notices In these instructions, warning notices are used to warn against material damage and injuries. Always read and observe these warning notices. Observe all measures marked with the warning symbol and warning word.

  • Page 5: Installation Of The Lintel-Mounted Smoke Switch

    Batteries obtained from us can be returned to us by mail. The address is: GEZE GmbH, Incoming Goods, Reinhold-Vöster-Str. 21-29, 71229 Leonberg/Germany. Batteries which con- tain harmful substances are identified by a symbol of a crossed-out rubbish bin.

  • Page 6: Hold-Open System Fa Gc 150

    Hold-open system FA GC 150 GEZE hold-open system FA GC 150 Hold-open system FA GC 150 3. 1 Function Directly after a fire or smoke protection door has been opened, it is closed again by the fitted door closer. This self-closing characteristic is cancelled in a controlled way by the hold-open system, so that a fire or smoke protec- tion door can remain open permanently.

  • Page 7: Hold-Open System With Separate Smoke Control Unit Rsz 6, Rsz 7

    GEZE hold-open system FA GC 150 Hold-open system FA GC 150 Hold-open system with separate smoke control unit RSZ 6, RSZ 7 The hold-open system RSZ 6, RSZ 7 comprising: ú Power supply (1) ú Power supply RSZ 6, RSZ 7 ú...

  • Page 8: Integrated Hold-Open Systems

    Hold-open system FA GC 150 GEZE hold-open system FA GC 150 Automatic drives ú TSA 160 NT F* hydraulic swing door drive ú TSA 160 NT F-IS* hydraulic swing door drive, 2-leaf with integrated mechanical closing sequence ú Slimdrive EMD-F* electromechanical swing door drive ú...

  • Page 9: Classification In Accordance With En 14637

    GEZE hold-open system FA GC 150 Hold-open system FA GC 150 Classification in accordance with EN 14637 Hold-open system No. 1 Class 3 Application class Frequent use by the general public and other persons with little incentive to take care No.

  • Page 10: Number And Installation Of Fire Detectors

    Hold-open system FA GC 150 GEZE hold-open system FA GC 150 3.5.2 Number and installation of fire detectors Distance between lower edge of the lintel and ceiling or false ceiling (where a larger concentration of smoke is to be expected first in the event of a fire).

  • Page 11: Manual Trigger Switch

    GEZE hold-open system FA GC 150 Hold-open system FA GC 150 3.5.3 Manual trigger switch Optional manual trigger switch: The hold-open devices ú TS 4000 E, TS 4000 E-IS ú E guide rail, E-ISM guide rail, E-ISM/G guide rail, E-ISM/S guide rail ú...

  • Page 12: Technical Data

    Technical data GEZE hold-open system FA GC 150 Technical data 4. 1 Hold-open system FA GC 150 Protection rating (according to DIN EN 61140) TS 4000 R, TS 4000 RFS RSZ 6, RSZ 7 (if automatic swing TS 4000 R-IS, TS 5000 RFS KB...

  • Page 13: Lintel-Mounted Smoke Switch Gc 151

    GEZE hold-open system FA GC 150 Technical data Lintel-mounted smoke switch GC 151 Lintel-mounted smoke switch GC 151 ID 142250 Functional principle Scatter light, adaption of the alarm threshold, no alarm saving (self- resetting as soon as there is no longer any smoke in the measuring...

  • Page 14: Wireless Module Gc 171

    Technical data GEZE hold-open system FA GC 150 State / fault Alarm output Hold-open output KL1: 3-4 / KL3: 1-2 Voltage-free AL_NC AL_COM AL_NO Normal operation Green 24 V Contamination (warning) 24 V The lintel-mounted smoke switch should be Green replaced.
  • Page 15 GEZE hold-open system FA GC 150 Technical data Signal transfer period 60 s Antenna integrated Frequency range 868.15 MHz to 869.85 MHz Range 10 m (100 m in space) Number of frequency channels Modulation technique FSK (frequency shift keying) Radiated power...

  • Page 16: Operating" Mode

    Technical data GEZE hold-open system FA GC 150 4.5. 1 “Operating” mode After the supply voltage has been switched on, the wireless module GC 171 is in “operating” mode. LED displays In “operating” mode the GC 171 monitors the set-up wireless connections and signals faults and alarms to the lintel-mounted smoke switch.
  • Page 17 GEZE hold-open system FA GC 150 Technical data Connection quality If the wireless device switch is in the OFF position during “operating” mode, the corresponding wireless device LED indicates the connection quality to the corresponding wireless device: - LED is Off...

  • Page 18: Set Up Wireless Connection" Mode

    Technical data GEZE hold-open system FA GC 150 4.5.2 “Set up wireless connection” mode In the “set up wireless connection” mode, new wireless connections can be set up to new wireless devices GC 172, GC 173 or GC 175. A maximum of 6 wireless connections can be set up.
  • Page 19 GEZE hold-open system FA GC 150 Technical data Wireless ceiling-mounted detector GC 172 or GC 173: The LED of the new wireless ceiling-mounted detector flashes green twice first, then lights up yellow for one red four times. As soon as the second and then flashes LED goes out after that, the connection can be set up.
  • Page 20 Technical data GEZE hold-open system FA GC 150 Delete all wireless connections All wireless connections already set up can be deleted in the “set up wireless connection” mode. After the supply voltage has been switched on, the wireless module GC 171 is in “operating” mode. All the wireless device SW1x switches SW1x are in the OFF position.

  • Page 21: Ceiling-Mounted Smoke Detector Gc 152

    24 V DC / maximum 1 A Detector test Alarm triggering with test magnet near the magnetic sensor (GEZE logo) ú with test aerosol The detector test using a test magnet tests the electrical compo-...

  • Page 22: Ceiling-Mounted Thermal Detector Gc 153

    (see chap. 6.3). Signalling Relay output Voltage-free ASout ASin Normal operation Alarm ASout ASin Fig. 4.7.2 Tab. 4.7.1 GC 150 B Fig. 4.7.3 LED for displaying state Breaking point (see chap. 5.2) Magnetic sensor for testing (behind the GEZE logo)

  • Page 23: Ceiling-Mounted Smoke Detector Ors 142

    GEZE hold-open system FA GC 150 Technical data Ceiling-mounted smoke detector ORS 142 Ceiling-mounted smoke detector kit ORS ID 141715 142 with 2 × smoke detector ORS 142 ú 2 × base ORS 143 A ú 1 × magnetic holder ú...

  • Page 24: Wireless Ceiling-Mounted Smoke Detector Gc 172

    Move the test magnet near to the magnetic sensor (GEZE logo). The LED flashes green. Alarm triggering: Move the test magnet near to the magnetic sensor (GEZE logo) again. Trigger the alarm using the test aerosol. The detector test using a test magnet tests the electrical compo- German nents.

  • Page 25: Signalling

    Move the test magnet near to the magnetic sensor (GEZE logo). The LED flashes green. Alarm triggering: Move the test magnet near to the magnetic sensor (GEZE logo) again. Trigger the alarm using the heat detector testing device. The detector test using a test magnet tests the electrical components.

  • Page 26: Signalling

    10 m (100 m in space) Number of frequency channels Modulation technique FSK (frequency shift keying) Radiated power 10 dBm / 10 mW Magnetic sensor for testing (behind the GEZE logo) Battery compartment Sabotage contact LED for displaying state Batteries Base...

  • Page 27: Manual Trigger Switch Uta

    GEZE hold-open system FA GC 150 Technical data 4. 1 1 Manual trigger switch UTA Type UTA, AS500 Manual trigger switch ID 116266 Surface-mounted box ID 120503 Spare resistor 43 kΩ ID 157093 Type of switching Changer Switching voltage Maximum 250 V...

  • Page 28: Signalling

    Technical data GEZE hold-open system FA GC 150 CR123A CR2032 Fig. 4.12.1 Housing LED for displaying state Antenna Main battery Antenna socket Slave battery Set-up switch Housing tab CAUTION! Component at risk from electrostatic charge Do not touch the antenna! 4.

  • Page 29: Wiring Diagram

    ú The cables must be sufficiently mechanically protected and attached. ú Insulate wires that are not used. 5. 1 Mains connection ú The GEZE hold-open systems are devices of protection rating I or protection rating II in accordance with DIN EN61140.

  • Page 30: Mains Connection For Protection Rating Ii

    Wiring diagram GEZE hold-open system FA GC 150 5. 1 .2 Mains connection for protection rating II Power supply for smoke control unit RSZ 6, RSZ 7 TS 5000 R, TS 5000 RFS, TS 5000 R-ISM /G/S/0, TS 5000 R-ISM-EFS 085391 no.
  • Page 31 GEZE hold-open system FA GC 150 Wiring diagram Ceiling-mounted detectors GC 152 and GC 153 with line monitoring German institute for The general construction technique permit requires the cable to the ceiling-mounted detectors to be moni- construction technology tored. Line monitoring is active if: ú...
  • Page 32 Wiring diagram GEZE hold-open system FA GC 150 Connection of a ceiling-mounted thermal detector GC 153 as a lintel-mounted detector and two further ceiling-mounted detectors PLEASE NOTE When two floor springs TS 550 E are used, no more than two ceiling-mounted detectors may be connected.

  • Page 33: Ceiling-Mounted Smoke Detector Ors 142

    GEZE hold-open system FA GC 150 Wiring diagram 5.2.2 Ceiling-mounted smoke detector ORS 142 The ceiling-mounted detector ORS 142 is made up of the smoke detector ORS 142 and the base ORS 143 A. Ceiling-mounted smoke detector kit ORS 142 with ID 141715 ú...

  • Page 34: Manual Trigger Switch Or Contact Of The Fire Alarm System

    Wiring diagram GEZE hold-open system FA GC 150 Manual trigger switch or contact of the fire alarm system ú Spare resistor 43 kΩ, ID 157093 5.3. 1 Manual trigger switch UTA ú Manual trigger switch UTA, AS500, ID 116266 Surface mounting cap, single, AS500, ID 120503 ú...

  • Page 35: Contact To The Fire Alarm System

    GEZE hold-open system FA GC 150 Wiring diagram 5.3.2 Contact to the fire alarm system When a potential-free contact of the fire alarm system is connected, remove jumper J1 from the lintel-mounted smoke switch. Line monitoring is active if: ú jumper J3 of the lintel-mounted smoke switch to the measuring chamber is set (2-3, see chap. 4.4).

  • Page 36: Wireless Module Gc 171

    Wiring diagram GEZE hold-open system FA GC 150 Wireless module GC 171 ú Wireless module GC 171, ID 163051 Wireless ceiling-mounted smoke detector GC 172 - ID 195522 Wireless ceiling-mounted thermal detector GC 173 - ID 195523 Wireless input module GC 175, ID 163068 Battery set GC 17x, ID 183282 Spare resistor 2.2 kΩ, ID 163229...

  • Page 37: Wireless Ceiling-Mounted Detector Gc 172 Or Gc 173 - Manual Trigger Switch Or Fire Detector Contact Wired

    GEZE hold-open system FA GC 150 Wiring diagram 5.4.2 Wireless ceiling-mounted detector GC 172 or GC 173 – manual trigger switch or fire detector contact wired ú Manual trigger switch or fire alarm contact are connected as described in chap. 5.3.

  • Page 38: Manual Trigger Switch Uta

    Wiring diagram GEZE hold-open system FA GC 150 5.5. 1 Manual trigger switch UTA ú Manual trigger switch UTA, AS500, ID 116266 Surface mounting cap, single, AS500, ID 120503 ú Note the requirements on the installation of manual trigger switch in chap. 3.5.

  • Page 39: Contact Of The Fire Alarm System And Manual Trigger Switch Uta

    GEZE hold-open system FA GC 150 Wiring diagram 5.5.3 Contact of the fire alarm system and manual trigger switch UTA German The general construction technique permit requires line monitoring to the potential-free contact of the fire institute for construction alarm system and to the manual trigger switch.

  • Page 40: Hold-Open Device

    Wiring diagram GEZE hold-open system FA GC 150 Fig. 5.7.1 Hold-open device ú External hold-open devices are connected to KL1 of the lintel-mounted smoke switch (screw-push-terminal). Internal hold-open devices are connected to KL3 of the lintel-mounted smoke switch (system plug-type con- nection).
  • Page 41 GEZE hold-open system FA GC 150 Wiring diagram Door closer TS 4000 E-IS Door leaf installation ú Connector box with plug-in drip loop, ID 052105 GC 151 Connector box TS 4000 E-IS Door Active leaf transmission Switch closed if active leaf open I=42 mA 24 VDC±15%...
  • Page 42 Wiring diagram GEZE hold-open system FA GC 150 E-ISM guide rail, E-ISM guide rail Boxer (E-ISM/G no hold-open function in the passive leaf, E-ISM/S no hold-open function in the active leaf) Connection board E hold-open device active leaf active leaf 24 VDC±15%...
  • Page 43 GEZE hold-open system FA GC 150 Wiring diagram Transom installation 24 VDC±15% Rem. w <20% I=42 mA Fig. 5.8.1.9 Integrated door closer Boxer EFS Boxer EFS 24 VDC±15% Restw. <20% I=80 mA Fig. 5.8.1.10 Floor spring TS 550 NV-E 24 VDC±15% Rem.
  • Page 44 Wiring diagram GEZE hold-open system FA GC 150 Floor spring TS 550 E-IS ú Connection PCB, ID 001102 ú Terminal box on site Active leaf Passive leaf 24 VDC±1 % 24 VDC±1 % Rem. w <20% Rem. w <20% I=100 mA...
  • Page 45 GEZE hold-open system FA GC 150 Wiring diagram Hydraulic swing door drive TSA 160 NT F*, TSA 160 NT F EN7* Accessories TSA 160 NT F, ID 019654 Follow the wiring diagram for the TSA 160 NT swing door drive.
  • Page 46 Wiring diagram GEZE hold-open system FA GC 150 Electromechanical swing door drive Slimdrive EMD F* Follow wiring diagram for the Slimdrive EMD swing door drive. Latching Reset action button Fig. 5.8.1.17 Electromechanical swing door drive Slimdrive EMD F-IS* Follow wiring diagram for the Slimdrive EMD swing door drive.
  • Page 47 GEZE hold-open system FA GC 150 Wiring diagram Electromechanical swing door drive Powerturn F* Follow wiring diagram for the Powerturn swing door drive. Powerturn F DCU8 DCU801 DCU802 DCU800 Latching Reset action button Fig. 5.8.1.19 Electromechanical swing door drive Powerturn F-IS* Follow wiring diagram for the Powerturn swing door drive.

  • Page 48: Hold-Open System Ts 4000 R, Ts 4000 Rfs

    Wiring diagram GEZE hold-open system FA GC 150 Electromechanical swing door drive Powerturn F-IS/TS* Follow wiring diagram for the Powerturn swing door drive. Door closer Hold-open magnet Reed switch Reed switch closed if passive leaf is closed Latching action Reset button Fig.

  • Page 49: Hold-Open System Ts 5000 R

    GEZE hold-open system FA GC 150 Wiring diagram 5.8.4 Hold-open system TS 5000 R Fig. 5.8.4.1 5.8.5 Hold-open system TS 5000 R-ISM /G/S/0 TS 5000 R-ISM/G - no hold-open function in the passive leaf TS 5000 R-ISM/S - no hold-open function in the active leaf...

  • Page 50: Hold-Open System Ts 5000 R- Ism-Efs/ Ts Ts 5000 R-Ism/ 0 With Free Swing Door Closer

    Wiring diagram GEZE hold-open system FA GC 150 5.8.6 Hold-open system TS 5000 R- ISM-EFS/ TS TS 5000 R-ISM/ 0 with free swing door closer ú No hold-open device for the passive leaf ú Connector box with plug-in drip loop, ID 052105...

  • Page 51: Hold-Open System Slimdrive Emd F/R

    GEZE hold-open system FA GC 150 Wiring diagram 5.8.9 Hold-open system Slimdrive EMD F/R Follow wiring diagram for the Slimdrive EMD swing door drive. 24 V Latching Reset action button Fig. 5.8.9.1...

  • Page 52: Hold-Open System Slimdrive Emd F/R-Is

    Wiring diagram GEZE hold-open system FA GC 150 5.8. 1 0 Hold-open system Slimdrive EMD F/R-IS* Follow wiring diagram for the Slimdrive EMD swing door drive. 24 V Latching action Reset button Fig. 5.8.10.1 5.8. 1 1 Hold-open system Powerturn F/R* Follow wiring diagram for the Powerturn swing door drive.

  • Page 53: Hold-Open System Powerturn F/R-Is

    GEZE hold-open system FA GC 150 Wiring diagram 5.8. 1 2 Hold-open system Powerturn F/R-IS* Follow wiring diagram for the Powerturn swing door drive. 24 V Powerturn F GF Powerturn F SF DCU8 DCU8 DCU801 DCU801 DCU802 DCU800 DCU802 DCU800...

  • Page 54: Hold-Open System Powerturn F/R-Is/Ts

    Wiring diagram GEZE hold-open system FA GC 150 5.8. 1 3 Hold-open system Powerturn F/R-IS/TS* Follow wiring diagram for the Powerturn swing door drive. 24 V Door closer Powerturn F GF DCU8 GND 24 V 55 56 63 mA Hold-open magnet...

  • Page 55: Commissioning

    GEZE hold-open system FA GC 150 Commissioning Commissioning Switch on the mains voltage. The state display of the lintel-mounted smoke switch lights up green. Remove the dust protection film or dust protection cap from the housing of the hold-open system so that the smoke openings are clear.

  • Page 56: Confirmation Of Conformity For The Installation Of The Hold-Open System

    After the official acceptance test has taken place, the operator must attach a sign (set 10 pcs. ID 79142) in the size 105 mm × 52 mm, which is provided by GEZE, in the direct vicinity of the closer stating the following: ú...

  • Page 57: Maintenance

    An empty battery is indicated as a warning at the status LED of the wireless module GC 171 (see chap. 4.5.1) Scope, result and time of the functional test must be documented in the GEZE log book for hold-open systems and made available to the operator.
  • Page 58 GEZE hold-open system FA GC 150...
