DA-680 Series
Quick Installation Guide
Version 1.1, August 2023
Technical Support Contact Information
www.moxa.com/support
 2023 Moxa Inc. All rights reserved.
P/N: 1802006800002
*1802006800002*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DA-680 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Moxa Technologies DA-680 Series

  • Page 1 DA-680 Series Quick Installation Guide Version 1.1, August 2023 Technical Support Contact Information www.moxa.com/support  2023 Moxa Inc. All rights reserved. P/N: 1802006800002 *1802006800002*...
  • Page 2: Package Checklist

    Overview The DA-680 computer is built around an Intel® Core™ i3 processor and comes with 8 Gigabit Ethernet ports, 1 VGA port, 8/16 isolated RS-485 serial ports, and 5 USB ports. Additionally, one 2.5” HDD/SSD slot and one mSATA slot are included to enable storage expansion for industrial applications that require large storage space for edge data acquisition.
  • Page 3: Led Indicators

    LED Indicators The following table describes the function of the LED indicators located on the front panel of the DA-680: LED Name Status Description Green Power is on Power No power input or power error exists Blinking: Data is being written to or read Yellow from the storage unit Storage...
  • Page 4: Connecting The Power

    Connecting the Power The DA-680 provides single power (SP model) and dual power (DPP model) inputs. Use a screwdriver to remove the terminal clamp screws. Connect the power cord to the screws, and then fasten the screws to the unit. Refer to the following figure for detailed information. NOTE 1.
  • Page 5 When finished, press the Power Switch button on the rear panel to start the system. It will take about 30 to 60 seconds to boot up, depending on your operating system. ATTENTION 1. Disconnect all power sources before you connect the power wires.
  • Page 6: Reset Button

    ATTENTION IEC-60417-6172 (2012-09) 1. This product may create a shock hazard. Disconnect all power sources before connecting wires or servicing the product. 2. This equipment is intended for installation in a restricted access area. Reset Button Pressing the Reset button initiates a warm reboot. The button plays the same role as a desktop PC’s reset button.
  • Page 7: Ethernet Ports

    Ethernet Ports The DA-680 has 8 10/100/1000 Mbps RJ45 Ethernet ports on the rear panel. Refer to the following table for the pin assignments: 10/100 Mbps 1000 Mbps TRD(0)+ TRD(0)- TRD(1)+ – TRD(2)+ – TRD(2)- TRD(1)- – TRD(3)+ – TRD(3)- Digital Outputs The DA-680 comes with two digital outputs in a terminal block.
  • Page 8 IRIG-B The DA-680 has one physical interface with INPUT signal capability. Refer to the following table for information on the IRIG-B interface. IRIG-B IN Description Input Signal Differential signal D+ - D- > 0.2V, RXD is High, Input Signal Level D+ - D- <...
  • Page 9 ATTENTION The relay output is only suitable for connecting to a circuit in compliance with PS2 or LPS according to IEC 62368-1 rated 30 VDC, maximum 2 A. Installing a Storage Drive The DA-680 is provided with a storage slot for storage expansion using a SATA drive.
  • Page 10 2. Remove the screws and install 3 copper pillars as indicated. 3. Place the SATA drive on a tray, ensure that the SATA disk aligns with the screws on the storage tray, and fasten the screws. 4. Connect the cables to the SATA drive as indicated below. 5.
