Plugging in power and a telephone line

Be sure to pull the plastic tab out of the battery compartment on
the bottom of the Supercom 4400 before you plug in the AC
adapter.
Caution! Do not plug the Supercom 4400 into any line other than a
standard analog telephone line. If you do, you may damage your
telephone system or Supercom 4400, and you will void your
Plug the other end
of the tele-phone
line into a
telephone wall
outlet.
warranty.
The picture above shows how to set up for direct connect use. Direct
connect means that the telephone line is plugged directly into the
Supercom 4400. You do not need a telephone. When you use direct
connect, you can dial directly from the keyboard and use auto-
answer.
1 0 • S E T U P
Plug the AC
adapter into an
electrical outlet.
Plug the AC adapter
cord into the jack on
the back of the
Supercom 4400.
Plug one end of
the telephone line
into either tele-
phone jack on the
Supercom 4400.
