●[F 2] Setting of OUT1
Item
Either hysteresis mode, window comparator mode, error output or
Output mode
switch output OFF can be selected.
Reversed output Selects which type of switch output is used, normal or reversed.
Pressure setting Sets the ON and OFF point of the switch output.
Appropriate setting of the hysteresis will prevent the switch output
Hysteresis
from chattering.
Delay time Delay time of the switch output can be selected.
Display colour Select the display colour.
●Other parameter settings
Item
[F 3] Digital filter setting
[F 4] Auto-preset
[F 6] Fine adjustment of display value
[F10] Sub display setting
[F11] Display resolution setting
[F14] Zero cut-off setting
[F80] Power saving mode
[F81] Security code
[F90] Setting of all functions
[F96] Number of pressurizing errors
[F98] Output check
[F99] Reset to default settings
Page 32
Explanation
Page
Page 34
Page 35
Page 37
Page 38
Page 44
Page 45
Page 46
Page 47
Page 49
Page 51
Page 52
Page 54
-26-
Default setting
0.00 ms
OFF
0.0%
std (Standard)
1000-split
0.0
OFF
OFF
OFF
―
N/A (normal output)
OFF
Default setting
Hysteresis mode
Normal output
ISE70: 0.500 MPa
ISE71: 0.800 MPa
ISE70: 0.050 MPa
ISE71: 0.080 MPa
0.00 sec.
Output ON: Green
Output OFF: Red
(Linked to OUT1)
