How to capture remote Tacho log from FM
device?
Main Page > Frequently Asked Questions - FAQ
Contents
1 Supported devices
2 How does it work?
3 Steps to collect log file
4 How the received tacho log should look like
Supported devices
Solution applies for these devices:
FM6300/FMB630/FM6320
FMB640
FMC640
FMM640
FMB641
FMC650
FMM650
How does it work?
Fleet management devices Tacho log capturing is initiated using the command log2srv and by
setting the right configuration. The device establishes a GPRS connection and activates the link to
the computer, log starts to stream to the computer until the set time is elapsed. To stop streaming
log immediately log2srvstop is used.
Steps to collect log file
Here are steps on how to capture a Tacho online log from FM series devices:
1. Make sure you have external IP address with opened TCP port. This could be checked here.
2. Download "Hercules" program from
Go to (1) TCP Server → (2) Enter your
opened TCP port → (3) Press Listen then
click right mouse button over Received or
Sent data window → (4) Go to Special
Chars → (5) Set ASCII Names.
> How to capture remote Tacho log from FM device?
www.hw-group.com
Click right mouse button over Received or
Sent data window → (1) Go to Log to File →
(2) Set file name and directory where
captured log will be saved → (3) Press Log
Enable.
and start it.
