USER
MANUAL
BA-2601 M3
BA-2601
ATX Intel ® 8th Gen. Core
i7/i5/i3/ Pentium ® /
Celeron ® / Xeon ® 2100G
Processor
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BA-2601 and is the answer not in the manual?

Questions and answers

Related Manuals for protech BA-2601

Summary of Contents for protech BA-2601

  • Page 1 USER MANUAL BA-2601 ATX Intel ® 8th Gen. Core i7/i5/i3/ Pentium ® / Celeron ® / Xeon ® 2100G Processor BA-2601 M3...
  • Page 2 BA-2601 ® ATX Intel 8th Gen. Core i7/i5/i3/ ® ® ® Pentium / Celeron / Xeon 2100G Processor COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Nov. 2019. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Safety Precautions ..............2-6 Hardware Configuration ..............3-1 JUMPER & CONNECTOR QUICK REFERENCE TABLE ..3-2 COMPONENT LOCATIONS ............. 3-4 3.2.1 BA-2601 Top View ............. 3-4 3.2.2 BA-2601 Jumper Setting ........... 3-5 3.2.3 BA-2601 I/O View .............. 3-6 HOW TO SET JUMPERS ............3-7 Setting Connectors and Jumpers ..........
  • Page 5 3.4.10 LINE IN, LINE OUT, MIC IN PORT ......... 3-20 3.4.11 EMBEDDED DISPLAY PORT (EDP) CONNECTOR ..3-21 3.4.12 FRONT PANEL AUDIO CONNECTOR ......3-22 3.4.13 HARDWARE POWER FAILURE SELECTION ....3-23 3.4.14 FLASH DESCRIPTOR OVERRIDE SELECTION ... 3-24 3.4.15 MINI PCIE and MSATA SELECTION (For C246/Q370 SKU Only) ................
  • Page 6 Installing Graphics Driver Utility ..........4-4 Installing LAN Driver Utility ............4-5 Installing Sound Driver Utility ............ 4-6 ® Intel Management Engine Components Installer Installation .. 4-7 Installing RAID Utility (Only for C246/Q370, Optional) ....4-8 ® Installing Intel Serial I/O Driver Utility ........4-13 BIOS SETUP ..................
  • Page 7 PCH-IO Configuration – PCI Express Configuration – SATA Configuration (For C246/Q370 SKU Only) ........5-37 Security ................... 5-39 Boot ..................5-41 Save & Exit ................5-42 Appendix A Technical Summary ..........A-1 BA-2601 Block Diagram ................A-2 Interrupt Map ....................A-3 I/O MAP ....................A-16 Memory Map ...................A-18...
  • Page 8 Configuring WatchDog Timer ..............A-20 Flash BIOS Update .................A-22...
  • Page 9 Revision History The revision history of BA-2601 User Manual is described below: Version No. Revision History Date 2018/07 Initial Release 2019/11/11 The pin assignment of PCI1 ~ PCI5 has been updated. Adjusted the arrangement of PCI1~PCI5 pin 2019/11/25 assignment table.

  • Page 10: Introduction

    Introduction This chapter provides the introduction for the BA-2601 system as well as the framework of the user manual. The following topic is included: • About This Manual BA-2601 SERIES USER MANUAL Page: 1-1...

  • Page 11: About This Manual

    It is not intended for general users. The following section outlines the structure of this user manual. Chapter 1 Introduction This chapter provides the introduction for the BA-2601 system as well as the framework of the user manual. Chapter 2 Getting Started This chapter describes the package contents and outlines BA-2601 specifications.

  • Page 12: Getting Started

    Getting Started This chapter provides the information for the BA-2601 system. It describes the package contents and outlines the BA-2601 specifications. The following topics are included: • Package List • BA-2601 Specification • Safety Precautions Experienced users can go to Chapter 3 Hardware Configuration on page 3-1 for a quick start.

  • Page 13: Packing List

    If you discover any of the items listed below are damaged or lost, please contact your local distributor immediately. Item Q’ty BA-2601 Quick Reference Guide Manual / Driver DVD Mini Jumper (2.0 mm) SATA Cable (500mm) I/O Shield BA-2601 SERIES USER MANUAL Page: 2-2...

  • Page 14: Ba-2601 Specifications

     C246 and Q370 SKU: 6 x SATA III (6.0Gb/s) with RAID SATA Interface 0,1,5,10  H310 SKU: 4 x SATA III (6.0Gb/s) without RAID 10 x USB ports for C246/Q370 SKU:  4 x USB 3.1 (rear I/O) BA-2601 SERIES USER MANUAL Page: 2-3...
  • Page 15  1 x LPC pin header Display  Standard SKU: 1 x VGA, 1 x DVI-D, 1 x eDP Flexible Display  Customized SKU: 1 x DP, 1 x eDP (no compatible I/O Shield) BA-2601 SERIES USER MANUAL Page: 2-4...
  • Page 16 Vibration  Non-operation: 2G, 5-200Hz, X, Y, Z axis Environment Operating Temp.  0°C ~ 60°C (32°F ~ 140°F) Storage Temp.  -40°C ~ 85°C (-40°F ~ 185°F) Operation Humidity  20%~ 90% (non-condensing) BA-2601 SERIES USER MANUAL Page: 2-5...

  • Page 17: Safety Precautions

    Always disconnect power when the system is not in use. Disconnect power source when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. BA-2601 SERIES USER MANUAL Page: 2-6...

  • Page 18: Hardware Configuration

    This chapter contains helpful information about the jumper & connector settings, and component locations. The following sections are included: • Jumper & Connector Quick Reference Table • Component Locations • Configuration and Jumper Settings • Connector Pin Assignments BA-2601 SERIES USER MANUAL Page: 3-1...

  • Page 19: Jumper & Connector Quick Reference Table

    Programmable GPIO Pin Header JDIO1 LPC Connector JLPC1 Speaker Connector JSPK1 Keyboard / Mouse Connector KB_MS1 LAN + USB Connectors LAN_USB1, LAN_USB2 Mini PCI Express Slot M_PCIE1 (For C246/Q370 SKU Only) PCI Express Slots PCI_E1, PCI_E2 BA-2601 SERIES USER MANUAL Page: 3-2...
  • Page 20 Universal Serial Bus 3.0 Connector USB1 Universal Serial Bus 2.0 Connector USB2, USB3 VGA Port CN14 Parallel Port (LPT) Connector LPT1 (For C246/Q370 SKU Only) Front Panel Audio Connector JAUDIO1 I2C Wafer JI2C1 Case Open Connector BA-2601 SERIES USER MANUAL Page: 3-3...

  • Page 21: Component Locations

    Make sure both the system and peripheral devices are turned OFF as sudden surge of power could damage sensitive components. Make sure BA-2601 is properly grounded. CAUTION: Observe precautions while handling electrostatic sensitive components. Make sure to ground yourself to prevent static charge while you are working on the connectors and jumpers.

  • Page 22: Ba-2601 Jumper Setting

    SATA5 SATA3 SATA1 customized BOM option. COM5 COM4 JPCOM4 JPCOM3 (default) Note: C246/Q370 SKU supports M_PCIE1, SATA1~6, DIMM1~4, PCI_E1~2. LPT1 is only available for C246/Q370 SKU. H310 SKU only supports SATA1~4, DIMM1/3, PCI_E1~2 available. BA-2601 SERIES USER MANUAL Page: 3-5...

  • Page 23: Ba-2601 I/O View

    Chapter 3 Hardware Configuration 3.2.3 BA-2601 I/O View BA-2601 SERIES USER MANUAL Page: 3-6...

  • Page 24: How To Set Jumpers

    PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. BA-2601 SERIES USER MANUAL Page: 3-7...
  • Page 25 Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this BA-2601 SERIES USER MANUAL Page: 3-8...

  • Page 26: Setting Connectors And Jumpers

    RS-485 DCD# RS-485- RS-485+ DTR# DSR# RTS# CTS# Notes: COM2 is selectable as RS232, RS422, RS485 by BIOS setting. Default setting is RS232. Please see Chapter 5 “Advanced – Super IO Configuration” for details. BA-2601 SERIES USER MANUAL Page: 3-9...

  • Page 27: Com3, Com4, Com5, Com6 Connector

    COM3, COM4: Pin 9 is selectable for RI, +5V or +12V by jumper setting. Default setting is RI. Please see “COM3 and COM4 PIN9 Definition Selection Guide” for details. COM5 and COM6 are available for C246 SKU only. BA-2601 SERIES USER MANUAL Page: 3-10...

  • Page 28: Com3 And Com4 Pin9 Definition Selection Guide

    Chapter 3 Hardware Configuration 3.4.3 COM3 and COM4 PIN9 DEFINITION SELECTION GUIDE Jumper Location: JPCOM3 / JPCOM4 Description: COM3 and COM4 RI & Voltage Selection Jumper Setting Selection Jumper Illustration (Pin Closed) (Default Setting) JPCOM3/JPCOM4 JPCOM3/JPCOM4 JPCOM3/JPCOM4 BA-2601 SERIES USER MANUAL Page: 3-11...

  • Page 29: Programmable Gpio Pin Header

    Programmable GPIO PIN HEADER 3.4.4 Connector Location: JDIO1 Description: General Purpose Input / Output Pin Header ASSIGNMENT ASSIGNMENT VCC5 VCC12 DIN0 DOUT0 DIN1 DOUT1 DIN2 DOUT2 JDIO1 DIN3 DOUT3 DIN4 DOUT4 DIN5 DOUT5 DIN6 DOUT6 DIN7 DOUT7 BA-2601 SERIES USER MANUAL Page: 3-12...

  • Page 30: Keyboard & Mouse Port

    Chapter 3 Hardware Configuration 3.4.5 KEYBOARD & MOUSE PORT Port Location: KB_MS1 Description: PS/2 Keyboard & Mouse Port Mouse: ASSIGNMENT ASSIGNMENT MSCLK VCC5 MSDATA Keyboard: ASSIGNMENT ASSIGNMENT KBCLK VCC5 KBDATA KB_MS1 BA-2601 SERIES USER MANUAL Page: 3-13...

  • Page 31: Dvi (Digital Video Interface) Port

    TMDS_D3- A DVI-D connector transfer only digital signals, providing faster transfer rates and better quality than their predecessor, the VGA cable. It is most commonly used to connect computer video cards to LCD monitors. BA-2601 SERIES USER MANUAL Page: 3-14...

  • Page 32: Vga Port

    Chapter 3 Hardware Configuration 3.4.7 VGA PORT Port Location: CN14 (VGA) Description: VGA (Video Graphics Array) Connector ASSIGNMENT CRT_RED CRT_GREEN CRT_BLUE CN14 (VGA) CRT_VCC CRT_SDA CRT_HSYNC CRT_VSYNC CRT_SCL BA-2601 SERIES USER MANUAL Page: 3-15...

  • Page 33: Front Panel Connector

    ASSIGNMENT SETTINGS ILLUSTRATION 1. HDD_LED+ HDD LED JFP1 3. HDD_LED- 2. PWR_LED+ Power LED JFP1 4. PWR_LED- 5. GND Reset Button JFP1 7. RST_BTN 6. PWR_BTN Power Button JFP1 8. GND 9. VCC5 JFP1 BA-2601 SERIES USER MANUAL Page: 3-16...

  • Page 34: Lan & Usb Port

    Orange Color On Giga LAN Speed Indicator No LAN Switch/HUB connected Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active USB 3.1 signals: ASSIGNMENT ASSIGNMENT USB3_TX_P1 USB_N1 USB3_TX_N1 USB_P1 USB3_RX_P1 USB3_RX_N1 BA-2601 SERIES USER MANUAL Page: 3-17...
  • Page 35 Orange Color On Giga LAN Speed Indicator No LAN Switch/HUB connected Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active USB 3.1 signals: ASSIGNMENT ASSIGNMENT USB3_TX_P5 USB_N5 USB3_TX_N5 USB_P5 USB3_RX_P5 USB3_RX_N5 BA-2601 SERIES USER MANUAL Page: 3-18...
  • Page 36 Chapter 3 Hardware Configuration ASSIGNMENT ASSIGNMENT USB3_TX_P6 USB_N6 USB3_TX_N6 USB_P6 USB3_RX_P6 USB3_RX_N6 BA-2601 SERIES USER MANUAL Page: 3-19...

  • Page 37: Line In, Line Out, Mic In Port

    LINE IN, LINE OUT, MIC IN PORT Connector Location: AUDIO1 Description: Line In, Line Out & Microphone The connector can also support only Microphone. Line In: ASSIGNMENT HD_LINE-IN-L HD_LINE-IN-R Line Out: ASSIGNMENT LINE-OUT-L LINE-OUT-R AUDIO1 Mic In: ASSIGNMENT HD_MIC1-L_L HD_MIC1-R_L BA-2601 SERIES USER MANUAL Page: 3-20...

  • Page 38: Embedded Display Port (Edp) Connector

    It has advanced power-saving features including seamless refresh rate switching. It has become the new mainstream display panel interface for LCD panels with the realized higher resolution. BA-2601 SERIES USER MANUAL Page: 3-21...

  • Page 39: Front Panel Audio Connector

    Chapter 3 Hardware Configuration 3.4.12 FRONT PANEL AUDIO CONNECTOR Connector Location: JAUDIO1 Description: Front Panel Audio Connector ASSIGNMENT ASSIGNMENT MIC1-L MIC1-R LINE-IN-L LINE-IN-R LINE-OUT-L LINE-OUT-R JAUDIO1 BA-2601 SERIES USER MANUAL Page: 3-22...

  • Page 40: Hardware Power Failure Selection

    Chapter 3 Hardware Configuration 3.4.13 HARDWARE POWER FAILURE SELECTION Jumper Location: JP_AT1 Hardware Power Failure Selection Description: Jumper Setting Selection Jumper Illustration (Pin Closed) Enable JP_AT1 Open Disable (Default Setting) JP_AT1 BA-2601 SERIES USER MANUAL Page: 3-23...

  • Page 41: Flash Descriptor Override Selection

    Chapter 3 Hardware Configuration 3.4.14 FLASH DESCRIPTOR OVERRIDE SELECTION Jumper Location: JP3 Description: Flash Descriptor Override Selection Jumper Setting Selection Jumper Illustration (Pin Closed) Enable Open Disable (Default Setting) BA-2601 SERIES USER MANUAL Page: 3-24...

  • Page 42: Mini Pcie And Msata Selection

    Jumper Illustration (Pin Closed) *mSATA / NA JP_SW1 Mini PCIe* (Default Setting) JP_SW1 Note 1: mSATA function is for customized BOM option. Note 2: Mini PCIe function is only supported in C246/Q370 SKU only. BA-2601 SERIES USER MANUAL Page: 3-25...

  • Page 43: Vccio Voltage Selection

    Chapter 3 Hardware Configuration 3.4.16 VCCIO VOLTAGE SELECTION Jumper Location: JP6 Description: VCCIO Voltage Selection Jumper Setting Selection Jumper Illustration (Pin Closed) 1.0V 0.95V (Default Setting) BA-2601 SERIES USER MANUAL Page: 3-26...

  • Page 44: Pch Configuration / Recovery Selection

    Chapter 3 Hardware Configuration 3.4.17 PCH CONFIGURATION / RECOVERY SELECTION Jumper Location: JP2 Description: PCH Configuration / Recovery Selection Jumper Setting Selection Jumper Illustration (Pin Closed) Normal (Default Setting) Configure Recovery Open BA-2601 SERIES USER MANUAL Page: 3-27...

  • Page 45: Parallel Port (Lpt) Connector (For C246/Q370

    PARALLEL PORT (LPT) CONNECTOR (For C246/Q370 SKU Only) Connector Location: LPT1 Description: Parallel Port Connector LPT1 ASSIGNMENT ASSIGNMENT PRN_STRBJ_R PRN_AFD PRN_R_D0 PRN_ERRJ PRN_R_D1 PRN_INIT PRN_R_D2 PRN_SLIN PRN_R_D3 PRN_R_D4 PRN_R_D5 PRN_R_D6 PRN_R_D7 PRN_ACKJ PRN_BUSY PRN_PE PRN_SLCT BA-2601 SERIES USER MANUAL Page: 3-28...

  • Page 46: I2C Wafer

    Chapter 3 Hardware Configuration 3.4.19 I2C WAFER Connector Location: JI2C1 Description: I2C Wafer ASSIGNMENT 3.3V I2C_SCL I2C_SDA JI2C1 3.4.20 Case Open Connector Connector Location: JP5 Case Open Description: Connector ASSIGNMENT COPENJ BA-2601 SERIES USER MANUAL Page: 3-29...

  • Page 47: Mini Pci Express Slot (For C246/Q370 Only)

    MINI PCI EXPRESS SLOT (For C246/Q370 Only) Connector Location: M_PCIE1 Description: Mini-PCI Express Slot ASSIGNMENT ASSIGNMENT WAKE_N 3.3V_SB 1.5V CLKREQ# REFCLK+ REFCLK- PERST# PE_RX_N 3.3V_SB PE_RX_P 1.5V SMB_CLK PE_TX_N SMB_DATA PE_TX_P USB_N M_PCIE1 USB_P 3.3V_SB 3.3V_SB 1.5V 3.3V_SB BA-2601 SERIES USER MANUAL Page: 3-30...

  • Page 48: Pcie Bus

    PRSNT#2 HSIN3 HSOP4 RSVD RSVD HSON4 HSIP4 HSOP5 HSIN4 HSON5 HSIP5 HSOP6 HSIN5 HSON6 HSIP6 HSOP7 HSIN6 HSON7 HSIP7 PRSNT#2 HSIN7 HSOP8 HSON8 RSVD HSIP8 HSIN8 HSOP9 HSON9 HSIP9 HSIN9 HSOP10 HSON10 HSIP10 HSIN10 BA-2601 SERIES USER MANUAL Page: 3-31...
  • Page 49 Chapter 3 Hardware Configuration ASSIGNMENT ASSIGNMENT ASSIGNMENT ASSIGNMENT HSOP11 HSON11 HSIP11 HSIN11 HSOP12 HSON12 HSIP12 HSIN12 HSOP13 HSON13 HSIP13 HSIN13 HSOP14 HSIN14 HSIP14 HSIN14 HSIP15 HSIN15 PRSNT#2 HSIP15 HSIN15 RSVD BA-2601 SERIES USER MANUAL Page: 3-32...
  • Page 50 Chapter 3 Hardware Configuration Connector Location: PCI_E2 (x4) Description: PCIE Bus (x4) You will find the PCI_E2 connector with 64 pins on BA-2601. PCI_E2 ASSIGNMENT ASSIGNMENT ASSIGNMENT ASSIGNMENT +12V +12V +12V PRSNT#1 +12V +12V SMB_DATA SMB_CLK +3.3V +3.3V_AUX +3.3V +3.3V...

  • Page 51: Pci Bus Connector

    TRDY# DEVSEL# STOP# PERR# LOCK# +3.3V SDONE SERR# +3.3V SB0# C/BE1# +3.3V AD15 AD14 +3.3V AD13 AD10 AD12 AD11 AD09 AD08 C/BE0# +3.3V AD07 +3.3V AD06 AD03 AD05 AD04 AD01 AD02 AD00 ACK64# REQ64# BA-2601 SERIES USER MANUAL Page: 3-34...

  • Page 52: Cpu / System Fan Connector

    CPU / SYSTEM FAN CONNECTOR Connector Location: CPU_FAN1, SYS_FAN1 Description: CPU Fan Connector (CPU_FAN1), System Fan Connector 1 (SYS_FAN1) ASSIGNMENT CPU_FAN1 VCC12 CPU_FANTAC CPU_FANCTRL SYS_FAN1 Connector Location: SYS_FAN2 Description: System Fan Connector 2 ASSIGNMENT VCC12 SYS_FAN2 BA-2601 SERIES USER MANUAL Page: 3-35...

  • Page 53: Serial Ata (Sata) Connector

    Connector Location: SATA1, SATA2, SATA3, SATA4, SATA5, SATA6 Description: SATA Connectors SATA1 Pin Assignment: ASSIGNMENT SATA_TXP0 SATA_TXN0 SATA1/ SATA_RXN0 SATA3/ SATA_RXP0 SATA5 SATA2 Pin Assignment: ASSIGNMENT SATA_TXP1 SATA_TXN1 SATA_RXN1 SATA2/ SATA_RXP1 SATA4/ SATA6 SATA3 Pin Assignment: ASSIGNMENT SATA_TXP2 SATA_TXN2 SATA_RXN2 SATA_RXP2 BA-2601 SERIES USER MANUAL Page: 3-36...
  • Page 54 ASSIGNMENT SATA_TXP3 SATA_TXN3 SATA_RXN3 SATA_RXP3 SATA5 Pin Assignment: ASSIGNMENT SATA_TXP4 SATA_TXN4 SATA_RXN4 SATA_RXP4 SATA6 Pin Assignment: ASSIGNMENT SATA_TXP5 SATA_TXN5 SATA_RXN5 SATA_RXP5 Notes: C246 SKU supports SATA1~SATA6. Q370 SKU supports SATA1~SATA4. H310 SKU supports SATA1~SATA4. BA-2601 SERIES USER MANUAL Page: 3-37...

  • Page 55: Internal Usb 3.0 Connector

    Chapter 3 Hardware Configuration 3.4.26 INTERNAL USB 3.0 CONNECTOR Connector Location: USB1 Description: Internal USB 3.0 Connector ASSIGNMENT ASSIGNMENT VCC5 USB2_P USB3_RX_N USB2_N USB3_RX_P USB3_TX_P USB3_TX_N USB3_TX_N USB3_TX_P USB3_RX_P USB1 USB2_N USB3_RX_N USB2_P VCC5 BA-2601 SERIES USER MANUAL Page: 3-38...

  • Page 56: Internal Usb 2.0 Connector

    Chapter 3 Hardware Configuration 3.4.27 INTERNAL USB 2.0 CONNECTOR Connector Location: USB2, USB3 Description: Internal USB 2.0 Connector ASSIGNMENT ASSIGNMENT VCC5 VCC5 USB2_N USB2_N USB2_P USB2_P USB2/ USB3 BA-2601 SERIES USER MANUAL Page: 3-39...

  • Page 57: Displayport Connector (Option)

    Chapter 3 Hardware Configuration 3.4.28 DISPLAYPORT CONNECTOR (OPTION) Connector Location: DP1 Description: DisplayPort Connector ASSIGNMENT ASSIGNMENT DATA0+ DATA0- DATA1+ DATA1- DATA2+ DATA2- DATA3+ DATA3- AUX_EN# AUX+ AUX- 3.3V BA-2601 SERIES USER MANUAL Page: 3-40...

  • Page 58: Speaker Connector

    Chapter 3 Hardware Configuration 3.4.29 SPEAKER CONNECTOR Connector Location: JSPK1 Description: Speaker Connector ASSIGNMENT JSPK1 SPKR_VCC SPKR_SIGNAL SPKR_SIGNAL SPKR_SIGNAL BA-2601 SERIES USER MANUAL Page: 3-41...

  • Page 59: Power Input Connector

    Chapter 3 Hardware Configuration 3.4.30 POWER INPUT CONNECTOR Connector Location: ATX_PWR1 Description: ATX Connector ASSIGNMENT ASSIGNMENT +3.3V +3.3V +3.3V -12V PSON ATX_PWR1 +5V_SB +12V +12V +12V Connector Location: ATX_PWR2 Description: Power Connector ASSIGNMENT ASSIGNMENT +12V +12V ATX_PWR2 BA-2601 SERIES USER MANUAL Page: 3-42...

  • Page 60: Lpc Connector

    Chapter 3 Hardware Configuration 3.4.31 LPC CONNECTOR Connector Location: JLPC1 Description: LPC Connector ASSIGNMENT ASSIGNMENT FRAME RESET VCC5 LAD3 LAD2 VCC3 LAD1 JLPC1 LAD0 SMBCLK SMBDATA 3VSB SERIRQ CLK RUN SUS_TAT DREQ0 BA-2601 SERIES USER MANUAL Page: 3-43...

  • Page 61: Clear Cmos Data Selection

    Step 4. Power on the PC and the PC will then auto-reboot for once in order to set SoC’s register. Step 5. Done! Jumper Setting Selection Jumper Illustration (Pin Closed) Open Normal (Default Setting) JCMOS1 Clear CMOS JCMOS1 BA-2601 SERIES USER MANUAL Page: 3-44...

  • Page 62: Software Utilities

    • Installing Graphics Driver Utility • Installing LAN Driver Utility • Installing Sound Driver Utility ® • Installing Intel Management Engine Components Installer • Installing Intel Rapid Storage Utility ® • Installing Intel Serial I/O Driver Utility ® BA-2601 SERIES USER MANUAL Page: 4-1...
  • Page 63 Chapter 4 Software Utilities Introduction Enclosed with the BA-2601 Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: Filename (Assume that DVD-ROM drive is Purpose ® D:\BA-2601_V1.0\Platform\ Intel Chipset Device Software installer 1_Main Chip\Win10(64Bit) D:\BA-2601_V1.0\Platform\...
  • Page 64 The utility pack is to be installed only for Windows 10 (64-bit), and it should be installed immediately after the OS installation is finished. Please follow the steps below: Connect the USB DVD-ROM device to BA-2601 and insert the driver disk. Enter the Main Chip folder where the Chipset driver is located (depending on your OS platform).

  • Page 65: Installing Graphics Driver Utility

    VGA, DVI, DP (option) and eDP (option) interfaces and make the system work simultaneously. To install the Graphics driver utility, follow the steps below: Connect the USB DVD-ROM device to BA-2601 and insert the driver disk. Enter the Graphics folder where the driver is located (depending on your OS platform).

  • Page 66: Installing Lan Driver Utility

    Enhanced with LAN function, BA-2601 supports various network adapters. To install the LAN Driver, follow the steps below: Connect the USB DVD-ROM device to BA-2601 and insert the driver disk. Enter the LAN folder where the driver is located (depending on your OS platform).

  • Page 67: Installing Sound Driver Utility

    Chapter 4 Software Utilities Installing Sound Driver Utility To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to BA-2601 and insert the driver disk. Open the Sound folder where the driver is located (depending on your OS platform).

  • Page 68: Intel ® Management Engine Components Installer Installation

    ® Installation Instructions for Intel Management Engine Components Installer Connect the USB DVD-ROM device to BA-2601 and insert the driver disk. Enter the ME folder where the driver is located. Select Windows 10 (64-bit) for your OS platform. Click Setup.exe file for ME driver installation.

  • Page 69: Installing Raid Utility (Only For C246/Q370, Optional)

    Press <Del> to access the BIOS Setup Utility program when prompted during the Power-On Self-Test (POST). Enter Chipset > PCH-IO Configuration > SATA Configuration menu screen and select “RAID” option for SATA Controller(s) option item. See the picture below: BA-2601 SERIES USER MANUAL Page: 4-8...
  • Page 70 Press F4 to save and validate the changed BIOS configuration and reset the system. Press <Del> to enter the BIOS Setup Utility program again and the Intel(R) Rapid Storage Technology option item will display under the Advanced menu screen as below: BA-2601 SERIES USER MANUAL Page: 4-9...
  • Page 71 Chapter 4 Software Utilities Select the Intel(R) Rapid Storage Technology option item and press <Enter>, and the following screen will display. Select a RAID level that you want to enter and press <Enter>. BA-2601 SERIES USER MANUAL Page: 4-10...
  • Page 72 The hard drive(s) and hard drive information of the RAID level you selected in the previous step will display: Heed that in the user interface, the hard drive(s) and hard drive information listed for your system will differ from the example above. BA-2601 SERIES USER MANUAL Page: 4-11...
  • Page 73 RST) utility supports RAID 0, 1, 5, 10 in C246/Q370 SKU. To install the RAID utility, follow the steps below: Connect the USB DVD-ROM device to BA-2601 and insert the driver disk. Enter the RAID folder where the utility is located.

  • Page 74: Installing Intel ® Serial I/O Driver Utility

    Installing Intel Serial I/O Driver Utility To install the Serial I/O Driver, follow the steps below: Connect the USB DVD-ROM device to BA-2601 and insert the driver disk. Open the Serial I/O folder where the driver is located. Select Windows 10 (64-bit) for your OS platform.

  • Page 75: Bios Setup

    Setup information is retained when the system is powered off. The BIOS Setup Utilities consist of the following menu items: Main Menu • Advanced Menu • Chipset Menu • Security Menu • Boot Menu • Save & Exit Menu • BA-2601 SERIES USER MANUAL Page: 5-1...

  • Page 76: Introduction

    Chapter 5 BIOS Setup Introduction The BA-2601 main board uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the built-in BIOS setup program, Power-On Self-Test (POST), PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.

  • Page 77: Accessing Setup Utility

    POST message will be displayed: Figure 5-2. POST Screen with AMI Logo Press <Del> or <Esc> to access the Setup Utility program and the Main menu of the Aptio Setup Utility will appear on the screen as below: BA-2601 SERIES USER MANUAL Page: 5-3...
  • Page 78 English. You may use <↑> or <↓> key to select among the items and press <Enter> to confirm and enter the sub-menu. The following table provides the list of the navigation keys that you can use while operating the BIOS setup menu. BA-2601 SERIES USER MANUAL Page: 5-4...
  • Page 79 Load the previous configuration values. <F3> Load the default configuration values. <F4> Save the current values and exit the BIOS setup menu. <Esc> Close the sub-menu. Trigger the confirmation to exit BIOS setup menu. BA-2601 SERIES USER MANUAL Page: 5-5...

  • Page 80: Main

    Name No changeable options Displays the name of the PCH. PCH SKU No changeable options Displays the SKU for the PCH. Stepping No changeable options Displays the stepping of the PCH. BA-2601 SERIES USER MANUAL Page: 5-6...
  • Page 81 The “Day” is automatically changed. System Time Hour, minute, second Sets the system time. The format is [Hour: Minute: Second]. Users can directly enter values or use <+> or <-> arrow keys to increase/decrease it. BA-2601 SERIES USER MANUAL Page: 5-7...

  • Page 82: Advanced

    Super I/O Watchdog Parameters. S5 RTC Wake Settings Sub-Menu S5 RTC Wake Parameters. Super IO Configuration Sub-Menu System Super I/O Chip Parameters USB Configuration Sub-Menu USB Configuration Parameters. Network Stack Configuration Sub-Menu Network Stack Settings. BA-2601 SERIES USER MANUAL Page: 5-8...

  • Page 83: Advanced - Cpu Configuration

    SMX (Secure Mode No changeable options Secure Mode extensions support. Extensions) / TXT When enabled, VMM can utilize the Intel Virtualization - Disabled additional hardware capabilities Technology - Enabled provided by Vanderpool Technology. BA-2601 SERIES USER MANUAL Page: 5-9...

  • Page 84: Advanced - Pch-Fw Configuration

    Description/Purpose ME Firmware Version No changeable options Displays the ME Firmware Version. ME Firmware Mode No changeable options Displays the ME Firmware Mode. ME Firmware SKU No changeable options Displays the ME Firmware SKU. BA-2601 SERIES USER MANUAL Page: 5-10...

  • Page 85: Advanced - Trusted Computing

    BIOS Setting Options Description/Purpose Security Device - Disable Enables or Disables BIOS support for Support - Enable security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. BA-2601 SERIES USER MANUAL Page: 5-11...

  • Page 86: Advanced - Acpi Settings

    SUSPEND button RAM) is pressed. Lock Legacy - Disabled Enables or Disables Lock of Legacy Resources - Enabled Resources. S3 Video Repost - Disabled Enables or Disables S3 Video Repost. - Enabled BA-2601 SERIES USER MANUAL Page: 5-12...

  • Page 87: Advanced - Hardware Monitor

    Displays the voltage level of VCORE VCORE No changeable options in supply. Displays the voltage level of VCC5V VCC5V No changeable options in supply. Displays the voltage level of VCC12 VCC12 No changeable options in supply. BA-2601 SERIES USER MANUAL Page: 5-13...

  • Page 88: Smart Fan Mode Configuration

    CPU Fan Smart Fan Control - Auto Duty-Cycle Fan. Mode Manual mode fan control. Users can Manual Duty Mode Numeric (from 1 to 100) write expected duty cycle (PWM fan type) from 1 to 100. BA-2601 SERIES USER MANUAL Page: 5-14...

  • Page 89: Advanced - Super Io Watchdog

    Enables/Disables Super I/O Enable Watchdog - Disabled Watchdog timer settings. - 1s Watchdog timer unit Watchdog timer unit. - 60s Numeric Count for Timer (Seconds) The number of count for Timer. (from 10 to 255) BA-2601 SERIES USER MANUAL Page: 5-15...

  • Page 90: Advanced - S5 Rtc Wake Settings

    Enters 0-59 to set the wake-up Wake up second Numeric (from 0 to 59) second. Enters 1-5 to set the increased Wake up minute increase Numeric (from 1 to 5) minute(s) for dynamic wake-up time. BA-2601 SERIES USER MANUAL Page: 5-16...

  • Page 91: Advanced - Super Io Configuration

    Sets Parameters of Serial Port 4 (COMD). Serial Port 5 Configuration Sub-Menu Sets Parameters of Serial Port 5 (COME). Serial Port 6 Configuration Sub-Menu Sets Parameters of Serial Port 6 (COMF). Parallel Port Sub-Menu Sets Parameters of Parallel Port (LPT). BA-2601 SERIES USER MANUAL Page: 5-17...

  • Page 92: Super Io Configuration - Serial Port 1 Configuration

    No changeable options Serial Port 1. Possible - Auto Selects IRQ and I/O resource for the - IO=3F8h; IRQ=4; Serial Port 1. - IO=3F8h; IRQ=3,4,5,6,7,10,11; - IO=2F8h; IRQ=3,4,5,6,7,10,11; - IO=3E8h; IRQ=3,4,5,6,7,10,11; - IO=2E8h; IRQ=3,4,5,6,7,10,11; BA-2601 SERIES USER MANUAL Page: 5-18...

  • Page 93: Super Io Configuration - Serial Port 2 Configuration

    Selects IRQ and I/O resource for the - IO=2F8h; IRQ=3; Serial Port 2. - IO=3F8h; IRQ=3,4,5,6,7,10,11; - IO=2F8h; IRQ=3,4,5,6,7,10,11; - IO=3E8h; IRQ=3,4,5,6,7,10,11; - IO=2E8h; IRQ=3,4,5,6,7,10,11; Mode - RS-232 Selects COM2 mode. - RS-422 - RS-485 BA-2601 SERIES USER MANUAL Page: 5-19...

  • Page 94: Super Io Configuration - Serial Port 3 Configuration

    No changeable options Serial Port 3. Possible - Auto Selects IRQ and I/O resource for the - IO=3E8h; IRQ=7; Serial Port 3. - IO=3E8h; IRQ=3,4,5,6,7,10,11; - IO=2E8h; IRQ=3,4,5,6,7,10,11; - IO=2F0h; IRQ=3,4,5,6,7,10,11; - IO=2E0h; IRQ=3,4,5,6,7,10,11; BA-2601 SERIES USER MANUAL Page: 5-20...

  • Page 95: Super Io Configuration - Serial Port 4 Configuration

    No changeable options Serial Port 4. Possible - Auto Selects IRQ and I/O resource for the - IO=2E8h; IRQ=6; Serial Port 4. - IO=3E8h; IRQ=3,4,5,6,7,10,11; - IO=2E8h; IRQ=3,4,5,6,7,10,11; - IO=2F0h; IRQ=3,4,5,6,7,10,11; - IO=2E0h; IRQ=3,4,5,6,7,10,11; BA-2601 SERIES USER MANUAL Page: 5-21...

  • Page 96: Super Io Configuration - Serial Port 5 Configuration

    No changeable options Serial Port 5. Possible - Auto Selects IRQ and I/O resource for the - IO=2F0h; IRQ=10; Serial Port 5. - IO=3E8h; IRQ=3,4,5,6,7,10,11; - IO=2E8h; IRQ=3,4,5,6,7,10,11; - IO=2F0h; IRQ=3,4,5,6,7,10,11; - IO=2E0h; IRQ=3,4,5,6,7,10,11; BA-2601 SERIES USER MANUAL Page: 5-22...

  • Page 97: Super Io Configuration - Serial Port 6 Configuration

    No changeable options Serial Port 6. Possible - Auto Selects IRQ and I/O resource for the - IO=2E0h; IRQ=11; Serial Port 6. - IO=3E8h; IRQ=3,4,5,6,7,10,11; - IO=2E8h; IRQ=3,4,5,6,7,10,11; - IO=2F0h; IRQ=3,4,5,6,7,10,11; - IO=2E0h; IRQ=3,4,5,6,7,10,11; BA-2601 SERIES USER MANUAL Page: 5-23...

  • Page 98: Super Io Configuration - Parallel Port Configuration

    After the mode is changed, - EPP-1.7 and SPP Mode reset the system to reflect the actual - ECP Mode device settings. - ECP and EPP 1.9 Mode - ECP and EPP 1.7 Mode BA-2601 SERIES USER MANUAL Page: 5-24...

  • Page 99: Advanced - Usb Configuration

    The USB Configuration allows users to configure advanced USB settings such as USB mass storage driver support. USB Configuration Screen BIOS Setting Options Description/Purpose USB Mass Storage Driver - Disabled Enables/Disables USB Mass Storage Support - Enabled Driver Support. BA-2601 SERIES USER MANUAL Page: 5-25...

  • Page 100: Advanced - Network Stack Configuration

    Ipv4 PXE Support disabled, Ipv4 PXE boot option will - Enabled not be created. Enables Ipv6 PXE Boot Support. If - Disabled Ipv6 PXE Support disabled, Ipv6 PXE boot option will - Enabled not be created. BA-2601 SERIES USER MANUAL Page: 5-26...
  • Page 101 PXE boot wait time Numeric (from 0 to 5) boot to abort after the Esc key is pressed. Number of times that the media Media detect count Numeric (from 1 to 50) presence will be checked. BA-2601 SERIES USER MANUAL Page: 5-27...

  • Page 102: Chipset

    This menu allows users to configure advanced Chipset settings such as System Agent (SA) and PCH-IO configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose System Agent (SA) Parameters Sub-Menu System Agent (SA) Parameters. PCH-IO Configuration Sub-Menu PCH Parameters. BA-2601 SERIES USER MANUAL Page: 5-28...

  • Page 103: Chipset - System Agent (Sa) Configuration

    System Agent (SA) Configuration Screen BIOS Setting Options Description/Purpose Memory Configuration Sub-Menu Memory Configuration. Graphics Configuration Sub-Menu Graphics Configuration. PEG Port Configuration Sub-Menu PEG Port Configuration. - Disabled VT-d Enables or Disables VT-d function. - Enabled BA-2601 SERIES USER MANUAL Page: 5-29...

  • Page 104: System Agent (Sa) Configuration - Memory Configuration

    No changeable options Displays the size of DIMM2. (for H310 SKU only) DIMM3 No changeable options Displays the size of DIMM3. DIMM4 No changeable options Displays the size of DIMM4. (for H310 SKU only) BA-2601 SERIES USER MANUAL Page: 5-30...

  • Page 105: System Agent (Sa) Configuration - Graphics Configuration

    The Graphics Configuration allows users to configure the display settings for the LCD panel. Graphics Configuration Screen BIOS Setting Options Description/Purpose Primary Display - Auto Selects which Graphics device should - IGFX be Primary Display. BA-2601 SERIES USER MANUAL Page: 5-31...

  • Page 106: System Agent (Sa) Configuration - Peg Port Configuration

    No changeable options information. Enable Root Port - Disabled Enables or Disables the Root Port. - Enabled - Auto Max Link Speed - Auto Configures the maximum speed for - Gen1 PCI_E1. - Gen2 - Gen3 BA-2601 SERIES USER MANUAL Page: 5-32...

  • Page 107: Chipset - Pch Io Configuratioin

    State After G3 - Power On Specifies the Power On/Off state that - Power Off the system will go to when the power is re-applied following a power failure (G3 state). BA-2601 SERIES USER MANUAL Page: 5-33...

  • Page 108: Pch-Io Configuration - Pci Express Configuration

    PCIE Port assigned to LAN No changeable options assigned to LAN. PCI Express x4 Slot Sub-Menu PCI Express x4 slot settings. Mini PCI Express x1 Slot Sub-Menu Mini PCI Express Port settings. (For C246/Q370 SKU Only) BA-2601 SERIES USER MANUAL Page: 5-34...

  • Page 109: Pch-Io Configuration - Pci Express Configuration - Pci Express X4 Slot

    • Auto: BIOS auto configure. L1 Substates - Disabled PCI Express L1 Substates settings. - L1.1 - L1.1 & L1.2 Hot Plug - Disabled Enables or Disables PCI Express Hot - Enabled Plug support. BA-2601 SERIES USER MANUAL Page: 5-35...
  • Page 110 - L1 • L0s: Forces all links to L0s state. - L0sL1 • L1: Forces all links to L1 state. - Auto • L0sL1: Forces all links to L0sL1 state. • Auto: BIOS auto configure. BA-2601 SERIES USER MANUAL Page: 5-36...

  • Page 111: Pch-Io Configuration - Pci Express Configuration - Sata

    Configures PCIe Speed. - Gen1 - Gen2 - Gen3 PCH-IO Configuration – PCI Express Configuration – SATA Configuration (For C246/Q370 SKU Only) Chipset > PCH-IO Configuration > SATA Configuration Menu Path SATA Configuration Screen BA-2601 SERIES USER MANUAL Page: 5-37...
  • Page 112 No changeable options Displays the SATA device’s name. - Disabled Port 1 - 6 Enables or Disables SATA Port Device. - Enabled - Disabled Enables or Disables SATA Port Device HotPlug HotPlug - Enabled function. BA-2601 SERIES USER MANUAL Page: 5-38...

  • Page 113: Security

    Setup utility. Security Screen BIOS Setting Options Description/Purpose Administrator Password Password can be 3-20 Specifies the administrator alphanumeric characters. password. User Password Password can be 3-20 Specifies the user password. alphanumeric characters. BA-2601 SERIES USER MANUAL Page: 5-39...
  • Page 114 <Enter>, and the password dialog entry box appears. Select the configured Administrator Password or User Password that you want to delete. Leave the dialog box blank and press <Enter>. Press <Enter> again when the password confirmation box appears. BA-2601 SERIES USER MANUAL Page: 5-40...

  • Page 115: Boot

    Specifies the power-on state of the Bootup NumLock State - Off NumLock Key. - Disabled Enables or Disables Quiet Boot Quiet Boot - Enabled option. - [Drive(s)] Boot Option #1~#n Sets the system boot order. - Disabled BA-2601 SERIES USER MANUAL Page: 5-41...

  • Page 116: Save & Exit

    Discard Changes and Reset to discard any changes you have made and restore the factory BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Screen BA-2601 SERIES USER MANUAL Page: 5-42...
  • Page 117 Saves the changes done so far as User Save as User Defaults No changeable options Defaults. Restores the User Defaults to all the Restore User Defaults No changeable options setup options. Forces to boot from selected Boot Override - [Drive(s)] [drive(s)]. BA-2601 SERIES USER MANUAL Page: 5-43...

  • Page 118: Appendix A Technical Summary

    Appendix A Technical Summary This appendix will give you a brief introduction of the allocation maps for BA-2601 resources. The following topics are included: • BA-2601 Block Diagram • Interrupt Map • I/O Map • Memory Map • Configuring WatchDog Timer •...

  • Page 119: Ba-2601 Block Diagram

    LOW PIN COUNT COM1 RS232 LPC SLOT Connector (SLB9665TT2.0-5.63) COM 2 RS232/422/485 HW monitor FINTEK COM3 (5V/12V) RS232 LPC SIO PS/2 Keyboard COM4 F81866AD-I Mouse (5V/12V) RS232 COM5 LPT Port RS232 (wafer pitch2.0) COM6 RS232 BA-2601 SERIES USER MANUAL Page: A-2...

  • Page 120: Interrupt Map

    IRQ 64 Microsoft ACPI-Compliant System IRQ 65 Microsoft ACPI-Compliant System IRQ 66 Microsoft ACPI-Compliant System IRQ 67 Microsoft ACPI-Compliant System IRQ 68 Microsoft ACPI-Compliant System IRQ 69 Microsoft ACPI-Compliant System IRQ 70 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-3...
  • Page 121 IRQ 97 Microsoft ACPI-Compliant System IRQ 98 Microsoft ACPI-Compliant System IRQ 99 Microsoft ACPI-Compliant System IRQ 100 Microsoft ACPI-Compliant System IRQ 101 Microsoft ACPI-Compliant System IRQ 102 Microsoft ACPI-Compliant System IRQ 103 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-4...
  • Page 122 IRQ 132 Microsoft ACPI-Compliant System IRQ 133 Microsoft ACPI-Compliant System IRQ 134 Microsoft ACPI-Compliant System IRQ 135 Microsoft ACPI-Compliant System IRQ 136 Microsoft ACPI-Compliant System IRQ 137 Microsoft ACPI-Compliant System IRQ 138 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-5...
  • Page 123 IRQ 165 Microsoft ACPI-Compliant System IRQ 166 Microsoft ACPI-Compliant System IRQ 167 Microsoft ACPI-Compliant System IRQ 168 Microsoft ACPI-Compliant System IRQ 169 Microsoft ACPI-Compliant System IRQ 170 Microsoft ACPI-Compliant System IRQ 171 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-6...
  • Page 124 IRQ 200 Microsoft ACPI-Compliant System IRQ 201 Microsoft ACPI-Compliant System IRQ 202 Microsoft ACPI-Compliant System IRQ 203 Microsoft ACPI-Compliant System IRQ 204 Microsoft ACPI-Compliant System IRQ 256 Microsoft ACPI-Compliant System IRQ 257 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-7...
  • Page 125 IRQ 284 Microsoft ACPI-Compliant System IRQ 285 Microsoft ACPI-Compliant System IRQ 286 Microsoft ACPI-Compliant System IRQ 287 Microsoft ACPI-Compliant System IRQ 288 Microsoft ACPI-Compliant System IRQ 289 Microsoft ACPI-Compliant System IRQ 290 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-8...
  • Page 126 IRQ 319 Microsoft ACPI-Compliant System IRQ 320 Microsoft ACPI-Compliant System IRQ 321 Microsoft ACPI-Compliant System IRQ 322 Microsoft ACPI-Compliant System IRQ 323 Microsoft ACPI-Compliant System IRQ 324 Microsoft ACPI-Compliant System IRQ 325 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-9...
  • Page 127 IRQ 352 Microsoft ACPI-Compliant System IRQ 353 Microsoft ACPI-Compliant System IRQ 354 Microsoft ACPI-Compliant System IRQ 355 Microsoft ACPI-Compliant System IRQ 356 Microsoft ACPI-Compliant System IRQ 357 Microsoft ACPI-Compliant System IRQ 358 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-10...
  • Page 128 IRQ 387 Microsoft ACPI-Compliant System IRQ 388 Microsoft ACPI-Compliant System IRQ 389 Microsoft ACPI-Compliant System IRQ 390 Microsoft ACPI-Compliant System IRQ 391 Microsoft ACPI-Compliant System IRQ 392 Microsoft ACPI-Compliant System IRQ 393 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-11...
  • Page 129 IRQ 420 Microsoft ACPI-Compliant System IRQ 421 Microsoft ACPI-Compliant System IRQ 422 Microsoft ACPI-Compliant System IRQ 423 Microsoft ACPI-Compliant System IRQ 424 Microsoft ACPI-Compliant System IRQ 425 Microsoft ACPI-Compliant System IRQ 426 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-12...
  • Page 130 IRQ 455 Microsoft ACPI-Compliant System IRQ 456 Microsoft ACPI-Compliant System IRQ 457 Microsoft ACPI-Compliant System IRQ 458 Microsoft ACPI-Compliant System IRQ 459 Microsoft ACPI-Compliant System IRQ 460 Microsoft ACPI-Compliant System IRQ 461 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-13...
  • Page 131 IRQ 488 Microsoft ACPI-Compliant System IRQ 489 Microsoft ACPI-Compliant System IRQ 490 Microsoft ACPI-Compliant System IRQ 491 Microsoft ACPI-Compliant System IRQ 492 Microsoft ACPI-Compliant System IRQ 493 Microsoft ACPI-Compliant System IRQ 494 Microsoft ACPI-Compliant System BA-2601 SERIES USER MANUAL Page: A-14...
  • Page 132 Intel(R) I211 Gigabit Network Connection IRQ 4294967291 Intel(R) I211 Gigabit Network Connection IRQ 4294967292 Intel(R) USB 3.1 eXtensible Host Controller - 1.10 (Microsoft) IRQ 4294967293 Intel(R) UHD Graphics P630 IRQ 4294967294 Standard SATA AHCI Controller BA-2601 SERIES USER MANUAL Page: A-15...

  • Page 133: I/O Map

    Communications Port (COM4) 0x000002F0-0x000002F7 Communications Port (COM5) 0x000002E0-0x000002E7 Communications Port (COM6) 0x00001800-0x000018FE Motherboard resources 0x00000060-0x00000060 Standard PS/2 Keyboard 0x00000064-0x00000064 Standard PS/2 Keyboard 0x00000020-0x00000021 Programmable interrupt controller 0x00000024-0x00000025 Programmable interrupt controller 0x00000028-0x00000029 Programmable interrupt controller BA-2601 SERIES USER MANUAL Page: A-16...
  • Page 134 0x00004060-0x0000407F Standard SATA AHCI Controller 0x0000FFF8-0x0000FFFF Intel(R) Active Management Technology - SOL (COM7) 0x000000F0-0x000000F0 Numeric data processor 0x00002000-0x000020FE Motherboard resources 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer 0x00001854-0x00001857 Motherboard resources 0x0000EFA0-0x0000EFBF Intel(R) SMBus - A323 BA-2601 SERIES USER MANUAL Page: A-17...

  • Page 135: Memory Map

    PCI Express Root Complex 0xE4000-0xE7FFF PCI Express Root Complex 0xE8000-0xEBFFF PCI Express Root Complex 0xEC000-0xEFFFF PCI Express Root Complex 0xF0000-0xFFFFF PCI Express Root Complex 0xFC800000-0xFE7FFFFF PCI Express Root Complex 0xA1234000-0xA1235FFF Standard SATA AHCI Controller BA-2601 SERIES USER MANUAL Page: A-18...
  • Page 136 INT3450 0xFD6B0000-0xFD6BFFFF Intel(R) Serial IO GPIO Host Controller - INT3450 0xFD6A0000-0xFD6AFFFF Intel(R) Serial IO GPIO Host Controller - INT3450 0xFE1D8000-0xFE1DBFFF High Definition Audio Controller 0xFCF00000-0xFCFFFFFF High Definition Audio Controller 0xA1238000-0xA12380FF Intel(R) SMBus - A323 BA-2601 SERIES USER MANUAL Page: A-19...
  • Page 137 To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. BA-2601 SERIES USER MANUAL Page: A-20...
  • Page 138 ; ------------------------ Set timeout interval to 30 ------------------------------------------ 0F6h dx, al dx, al ;-------------------Set second as counting unit and start counting --------------------- 0F5h dx, al dx, al ;---------------------------------Exit the extended function mode ------------------------- 0AAh dx, al BA-2601 SERIES USER MANUAL Page: A-21...
  • Page 139 (3) The system will go into the BIOS setup menu. (4) Select [Boot] menu and set the USB storage device as the 1 boot device. (5) Press <F4> key to save the configuration and restart the system to boot into EFI Shell environment. BA-2601 SERIES USER MANUAL Page: A-22...
  • Page 140 /?” to view the definition of each control option. The recommended options for BIOS ROM update include the following parameters: Program main BIOS image. /B: Program Boot Block. /N: Program NVRAM. /X: Don’t check ROM ID. BA-2601 SERIES USER MANUAL Page: A-23...
  • Page 141 Erasing Main Block ..done Updating Main Block ..done Verifying Main Block ..done Erasing NVRAM Block ..done Updating NVRAM Block ..done Verifying NVRAM Block ..done Process completed. fs0:\afuefix64> _ BA-2601 SERIES USER MANUAL Page: A-24...
  • Page 142 Restart the system and boot up with the new BIOS configurations. The BIOS Update is completed after the system is restarted. Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. BA-2601 SERIES USER MANUAL Page: A-25...

Table of Contents
