protech BA-2602 User Manual

Atx intel 9th / 8th gen. core i7/i5/i3/ pentium / celeron / xeon e-2200 / 2100 cpu processor
Hide thumbs Also See for BA-2602:
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL
BA-2602 M2
BA-2602
®
ATX Intel
9th / 8th Gen. Core
i7/i5/i3/ Pentium
®
Xeon
E-2200 / 2100
CPU Processor
TM
®
®
/ Celeron
/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BA-2602 and is the answer not in the manual?

Questions and answers

Related Manuals for protech BA-2602

Summary of Contents for protech BA-2602

  • Page 1 USER MANUAL BA-2602 ® ATX Intel 9th / 8th Gen. Core ® ® i7/i5/i3/ Pentium / Celeron ® Xeon E-2200 / 2100 CPU Processor BA-2602 M2...
  • Page 2 BA-2602 ® ATX Intel 9th / 8th Gen. Core i7/i5/i3/ ® ® ® Pentium / Celeron / Xeon E-2200 / 2100 CPU Processor COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners.
  • Page 3 CAUTION: Always touch the board components by the edges. Never touch components such as a processor by its pins. Take special cares while you are holding electronic circuit boards by the edges only. Do not touch BA-2602 components. WARNING: Some internal parts of BA-2602 may have high electrical voltage.

  • Page 4: Table Of Contents

    BA-2602 Specifications ............. 2-3 Safety Precautions ..............2-7 Hardware Configuration ..............3-1 JUMPER & CONNECTOR QUICK REFERENCE TABLE ..3-2 COMPONENT LOCATIONS ............. 3-4 3.2.1 BA-2602 Top View ............. 3-4 3.2.2 BA-2602 Jumper Setting ........... 3-5 3.2.3 BA-2602 Bottom View ............3-6 3.2.4 BA-2602 I/O View ..............
  • Page 5 3.4.6 DISPLAYPORT (DP1, DP2) ..........3-15 3.4.7 VGA PORT (VGA1) ............3-16 3.4.8 FRONT PANEL CONNECTOR (JFP1) ......3-17 3.4.9 LAN & USB PORT (LAN1_USB1, LAN2_USB2) .... 3-18 3.4.10 LINE IN, LINE OUT, MIC IN PORT (AUDIO1) ....3-21 3.4.11 EMBEDDED DISPLAY PORT (EDP) CONNECTOR (EDP1) ..................
  • Page 6 ..................3-50 3.4.29 SPEAKER CONNECTOR (JSPK1) ......... 3-51 3.4.30 POWER INPUT CONNECTOR (ATX_PWR1, ATX_PWR2) ..................3-52 3.4.31 LOW PIN COUNT (LPC) CONNECTOR (JLPC1) ... 3-53 3.4.32 CLEAR CMOS DATA SELECTION (JCMOS1) ....3-54 3.4.33 NMI HEADER (JNMI1) ............ 3-54 3.4.34 FLASH BIOS HEADER (JSPI_1) ........
  • Page 7 5.4.2 Advanced – PCH-FW Configuration ........ 5-10 5.4.3 Advanced – Trusted Computing ........5-11 5.4.4 Advanced – ACPI Settings ..........5-12 5.4.5 Advanced – Hardware Monitor ........5-13 Smart Fan Mode Configuration ........... 5-14 5.4.6 Advanced – Super IO Watchdog ........5-15 5.4.7 Advanced –...
  • Page 8 Configuration ................5-42 Security ................... 5-44 Boot ..................5-46 Save & Exit ................5-47 Appendix A Technical Summary ..........A-1 BA-2602 Block Diagram ................A-2 Interrupt Map ....................A-3 I/O MAP ....................A-16 Memory Map ...................A-18 DMA Map ....................A-19 Configuring WatchDog Timer ..............A-20...

  • Page 9: Revision History

    Revision History The revision history of BA-2602 User Manual is described below: Version No. Revision History Date The pin assignment for Pin 12 of Power Input 2024/02/05 Connector (ATX_PWR1) has been revised to “+3.3V”. (Page 3-52) 2020/01/30 Initial Release...

  • Page 10: Introduction

    Introduction This chapter provides the introduction for the BA-2602 system as well as the framework of the user manual. The following topic is included: • About This Manual Page: 1-1 BA-2602 SERIES USER MANUAL...

  • Page 11: About This Manual

    It is not intended for general users. The following section outlines the structure of this user manual. Chapter 1 Introduction This chapter provides the introduction for the BA-2602 system as well as the framework of the user manual. Chapter 2 Getting Started This chapter describes the package contents and outlines BA-2602 specifications.

  • Page 12: Getting Started

    Getting Started This chapter provides the information for the BA-2602 system. It describes the package contents and outlines the BA-2602 specifications. The following topics are included: • Package List • BA-2602 Specification • Safety Precautions Experienced users can go to Chapter 3 Hardware Configuration on page 3-1 for a quick start.

  • Page 13: Package List

    If you discover any of the items listed below are damaged or lost, please contact your local distributor immediately. Item Q’ty BA-2602 Quick Reference Guide Manual / Driver DVD SATA Cable (500 mm) PS/2 Keyboard & Mouse Cable (L=250 mm) I/O Shield Page: 2-2 BA-2602 SERIES USER MANUAL...

  • Page 14: Ba-2602 Specifications

     +12V: 1.7A; -12V: 0.1A; +3.3V: 0.33A; +5V: 1.12A; Power Consumption 5Vsb: 0.1A  1 x internal buzzer Speaker  305 x 244mm (12” x 9.6”) Dimensions ®  Windows 10 IoT Enterprise O.S. Support  CE / FCC Certifications Page: 2-3 BA-2602 SERIES USER MANUAL...
  • Page 15 PHY 219LM (GbE) ®  LAN 2: Intel LAN 211AT (GbE)  Supports Wake-On-LAN & PXE  8bits GPIO programmable GPIO / DIO  1 x CPU fan, 2 x system fans (internal connector) Page: 2-4 BA-2602 SERIES USER MANUAL...
  • Page 16  2 x DP (rear I/O) up to 4096 x 2304 @60Hz (default)  1 x eDP (internal) up to 4096 x 2304 @60Hz (default) (C246/Q370) Others  2 x I C 4-pin wafer Page: 2-5 BA-2602 SERIES USER MANUAL...
  • Page 17  Non-operation: 2G, 5-200Hz, X, Y, Z axis Vibration Environment  0°C ~ 60°C (32°F ~ 140°F) Operating Temp.  -40°C ~ 85°C (-40°F ~ 185°F) Storage Temp.  20%~ 90% (non-condensing) Operating Humidity Page: 2-6 BA-2602 SERIES USER MANUAL...

  • Page 18: Safety Precautions

    Always disconnect power when the system is not in use. Disconnect power source when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. Page: 2-7 BA-2602 SERIES USER MANUAL...

  • Page 19: Hardware Configuration

    This chapter contains helpful information about the jumper & connector settings, and component locations. The following sections are included: • Jumper & Connector Quick Reference Table • Component Locations • Configuration and Jumper Settings • Connector Pin Assignments Page: 3-1 BA-2602 SERIES USER MANUAL...

  • Page 20: Jumper & Connector Quick Reference Table

    Low Pin Count (LPC) Header JLPC1 Speaker Header JSPK1 PS/2 + Dual USB 2.0 Ports KB_MS_USB (PS/2 Keyboard only) LAN + USB Connectors LAN1_USB1, LAN2_USB2 Mini PCI Express Slot M_PCIE1 (For C246/Q370 SKU Only) Page: 3-2 BA-2602 SERIES USER MANUAL...
  • Page 21 Front Audio Line In, Line Out JAUDIO1 and Mic In Connector Case Open Header I2C Wafers JI2C1, JI2C2 M.2 M-Key Slot M2_SSD NMI Header JNMI1 Flash BIOS Header JSPI_1 APS Header JAPS1 Micro SIM Card Socket SIM1 (rear side) Page: 3-3 BA-2602 SERIES USER MANUAL...

  • Page 22: Component Locations

    6 x SATA ATX Power Connector-1 WARNING: Always disconnect the power cord when you are working with connectors and jumpers on BA-2602. Make sure both the system and peripheral devices are turned OFF as sudden surge of power could damage sensitive components.

  • Page 23: Ba-2602 Jumper Setting

    Chapter 3 Hardware Configuration 3.2.2 BA-2602 Jumper Setting VGA1 COM2 DP1 / DP2 COM1 AUDIO1 KB_MS_USB Flash Descriptor Buzzer Override Selection SYS_FAN2 JSPI_1 JSPK1 PCI2 PCI1 JCMOS1 Clear CMOS Data PCI_E5 PCI_E4 PCI_E3 PCI_E2 PCI_E1 CPU_FAN1 (x4) (x1) (x4) (x4)

  • Page 24: Ba-2602 Bottom View

    Chapter 3 Hardware Configuration 3.2.3 BA-2602 Bottom View ATTEND SIM1 Page: 3-6 BA-2602 SERIES USER MANUAL...

  • Page 25: Ba-2602 I/O View

    Chapter 3 Hardware Configuration 3.2.4 BA-2602 I/O View PS/2 Keyboard COM2 LAN1 LAN2 Mouse Combo Audio USB 2.0 COM1 4 x USB 3.1 Port Connector Page: 3-7 BA-2602 SERIES USER MANUAL...

  • Page 26: How To Set Jumpers

    PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below illustrates what the jumper diagrams look and what they represent. Page: 3-8 BA-2602 SERIES USER MANUAL...
  • Page 27 Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this Page: 3-9 BA-2602 SERIES USER MANUAL...

  • Page 28: Setting Connectors And Jumpers

    RS-485 DCD# RS-485- RS-485+ DTR# DSR# RTS# CTS# Notes: COM2 is selectable as RS-232, RS-422, RS-485 under BIOS setting. Default setting is RS-232. Please see Chapter 5 “Advanced – Super IO Configuration” for details. Page: 3-10 BA-2602 SERIES USER MANUAL...

  • Page 29: Com3, Com4, Com5, Com6 Connector

    COM3, COM4: Pin 9 is selectable for RI, +5V or +12V by jumper setting. Default setting is RI. Please see “COM3 and COM4 PIN9 Definition Selection Guide” for details. COM5 and COM6 are available for C246/Q370 SKU only. Page: 3-11 BA-2602 SERIES USER MANUAL...

  • Page 30: Com3 And Com4 Pin9 Definition Selection Guide (Jpcom3, Jpcom4)

    3.4.3 COM3 and COM4 PIN9 DEFINITION SELECTION GUIDE (JPCOM3, JPCOM4) Jumper Location: JPCOM3, JPCOM4 Description: COM3 and COM4 RI & Voltage Selection Jumper Setting Selection Jumper Illustration (Pin Closed) (Default Setting) JPCOM3/JPCOM4 JPCOM3/JPCOM4 JPCOM3/JPCOM4 Page: 3-12 BA-2602 SERIES USER MANUAL...

  • Page 31: Programmable Gpio Pin Header (Jdio1)

    Programmable GPIO PIN HEADER (JDIO1) 3.4.4 Connector Location: JDIO1 Description: General Purpose Input / Output Pin Header ASSIGNMENT ASSIGNMENT VCC5 VCC12 DIN0 DOUT0 JDIO1 DIN1 DOUT1 DIN2 DOUT2 DIN3 DOUT3 DIN4 DOUT4 DIN5 DOUT5 DIN6 DOUT6 DIN7 DOUT7 Page: 3-13 BA-2602 SERIES USER MANUAL...

  • Page 32: Ps/2 Keyboard & Dual Usb 2.0 Port (Kb_Ms_Usb)

    Supports mouse function on PS/2 by Y-cable. PS/2 PS/2: ASSIGNMENT ASSIGNMENT KB DATA KB CLK MS DATA MS CLK Dual USB 2.0 Dual USB 2.0: ASSIGNMENT ASSIGNMENT USB D+ USB D+ USB D- USB D- KB_MS_USB Page: 3-14 BA-2602 SERIES USER MANUAL...

  • Page 33: Displayport (Dp1, Dp2)

    DP1 signals: ASSIGNMENT ASSIGNMENT DDP_B_P0 DDP_B_N0 DDP_B_P1 DDP_B_N1 DDP_B_P2 DDP_B_N2 DDP_B_P3 DDP_B_N3 DDP_B_AUX_ENJ DDP_B_AUX_P DDP_B_AUX_N DDP_B_HPD DP_PWR DP2 signals: ASSIGNMENT ASSIGNMENT DDP_C_P0 DDP_C_N0 DDP_C_P1 DDP_C_N1 DDP_C_P2 DDP_C_N2 DDP_C_P3 DDP_C_N3 DDP_C_AUX_ENJ DDP_C_AUX_P DDP_C_AUX_N DDP_C_HPD DP_PWR Page: 3-15 BA-2602 SERIES USER MANUAL...
  • Page 34 Chapter 3 Hardware Configuration 3.4.7 VGA (Video Graphics Array) PORT (VGA1) Port Location: VGA1 Description: VGA (Video Graphics Array) Port ASSIGNMENT CRT_RED CRT_GREEN CRT_BLUE VGA1 CRT_VCC CRT_SDA CRT_HSYNC CRT_VSYNC CRT_SCL Page: 3-16 BA-2602 SERIES USER MANUAL...

  • Page 35: Front Panel Connector (Jfp1)

    ASSIGNMENT SETTINGS ILLUSTRATION 1. HDD_LED+ HDD LED JFP1 3. HDD_LED- 2. PWR_LED+ Power LED JFP1 4. PWR_LED- 5. GND Reset Button JFP1 7. RST_BTN 6. PWR_BTN Power Button JFP1 8. GND 9. VCC5 JFP1 Page: 3-17 BA-2602 SERIES USER MANUAL...

  • Page 36: Lan & Usb Port (Lan1_Usb1, Lan2_Usb2)

    Giga LAN Speed Indicator No LAN Switch/HUB connected Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active USB 3.1 signals (Gen.2): ASSIGNMENT ASSIGNMENT USB_TX_P USB D- USB_TX_N USB D+ USB_RX_P USB_RX_N BA-2602 SERIES USER MANUAL Page: 3-18...
  • Page 37 Left Side LED Green Color On 10/100Mbps LAN Speed Indicator Orange Color On Giga LAN Speed Indicator No LAN Switch/HUB connected Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active BA-2602 SERIES USER MANUAL Page: 3-19...
  • Page 38 Chapter 3 Hardware Configuration USB 3.1 signals (Gen.1): ASSIGNMENT ASSIGNMENT USB_TX_P USB D- USB_TX_N USB D+ USB_RX_P USB_RX_N ASSIGNMENT ASSIGNMENT USB_TX_P USB D- USB_TX_N USB D+ USB_RX_P USB_RX_N Page: 3-20 BA-2602 SERIES USER MANUAL...

  • Page 39: Line In, Line Out, Mic In Port (Audio1)

    44 43 42 HD_LINE-IN-L 35 34 33 32 25 24 23 22 HD_LINE-IN-R 5 4 1 3 2 Line In Line Out: ASSIGNMENT Line Out LINE-OUT-L Mic In LINE-OUT-R AUDIO1 Mic In: ASSIGNMENT HD_MIC1-L_L HD_MIC1-R_L Page: 3-21 BA-2602 SERIES USER MANUAL...

  • Page 40: Embedded Display Port (Edp) Connector (Edp1)

    It has advanced power-saving features including seamless refresh rate switching. It has become the new mainstream display panel interface for LCD panels with the realized higher resolution. Page: 3-22 BA-2602 SERIES USER MANUAL...

  • Page 41: Front Panel Audio Connector (Jaudio1)

    Chapter 3 Hardware Configuration 3.4.12 FRONT PANEL AUDIO CONNECTOR (JAUDIO1) Connector Location: JAUDIO1 Description: Front Panel Audio Connector ASSIGNMENT ASSIGNMENT MIC1-L MIC1-R LINE-IN-L LINE-IN-R LINE-OUT-L LINE-OUT-R JAUDIO1 Page: 3-23 BA-2602 SERIES USER MANUAL...

  • Page 42: Hardware Power Failure Selection (Jp_At1)

    Chapter 3 Hardware Configuration 3.4.13 HARDWARE POWER FAILURE SELECTION (JP_AT1) Jumper Location: JP_AT1 Description: Hardware Power Failure Selection Jumper Setting Selection Jumper Illustration (Pin Closed) Enable JP_AT1 Open Disable JP_AT1 (Default Setting) Page: 3-24 BA-2602 SERIES USER MANUAL...

  • Page 43: Pch Configuration / Recovery Selection (Jp2)

    Chapter 3 Hardware Configuration 3.4.14 PCH CONFIGURATION / RECOVERY SELECTION (JP2) Jumper Location: JP2 Description: PCH Configuration / Recovery Selection Jumper Setting Selection Jumper Illustration (Pin Closed) Normal (Default Setting) Configure Recovery Open Page: 3-25 BA-2602 SERIES USER MANUAL...

  • Page 44: Flash Descriptor Override Selection (Jp3)

    Chapter 3 Hardware Configuration 3.4.15 FLASH DESCRIPTOR OVERRIDE SELECTION (JP3) Jumper Location: JP3 Description: Flash Descriptor Override Selection Jumper Setting Selection Jumper Illustration (Pin Closed) Enable Open Disable (Default Setting) Page: 3-26 BA-2602 SERIES USER MANUAL...

  • Page 45: Vccio Voltage Selection (Jp6)

    Chapter 3 Hardware Configuration 3.4.16 VCCIO VOLTAGE SELECTION (JP6) Jumper Location: JP6 Description: VCCIO Voltage Selection Jumper Setting Selection Jumper Illustration (Pin Closed) 1.0V 0.95V (Default Setting) Page: 3-27 BA-2602 SERIES USER MANUAL...

  • Page 46: Usb Standby +5V / Normal Power Selection (Jp7)

    Chapter 3 Hardware Configuration 3.4.17 USB STANDBY +5V / NORMAL POWER SELECTION (JP7) Jumper Location: JP7 USB Standby +5V / Normal Power Selection Description: Jumper Setting Selection Jumper Illustration (Pin Closed) Normal (Default Setting) Standby +5V Page: 3-28 BA-2602 SERIES USER MANUAL...

  • Page 47: Parallel Port (Lpt) Connector (Lpt1)

    Chapter 3 Hardware Configuration 3.4.18 PARALLEL PORT (LPT) CONNECTOR (LPT1) Connector Location: LPT1 Description: Parallel Port Connector LPT1 ASSIGNMENT ASSIGNMENT PRN_STRBJ_R PRN_AFD PRN_R_D0 PRN_ERRJ PRN_R_D1 PRN_INIT PRN_R_D2 PRN_SLIN PRN_R_D3 PRN_R_D4 PRN_R_D5 PRN_R_D6 PRN_R_D7 PRN_ACKJ PRN_BUSY PRN_PE PRN_SLCT Page: 3-29 BA-2602 SERIES USER MANUAL...

  • Page 48: I2C Wafer (Ji2C1, Ji2C2)

    Chapter 3 Hardware Configuration 3.4.19 I2C WAFER Connector Location: JI2C1, JI2C2 Description: I2C Wafer ASSIGNMENT 3.3V I2C_SCL I2C_SDA JI2C1 JI2C2 3.4.20 CASE OPEN CONNECTOR Connector Location: JP5 Description: Case Open Connector ASSIGNMENT COPENJ Page: 3-30 BA-2602 SERIES USER MANUAL...

  • Page 49: M_Pcie1

    Note: C246 and Q370 SKUs support Mini-PCI Express Slot only. ASSIGNMENT ASSIGNMENT WAKE_N 3.3V_SB 1.5V CLKREQ# REFCLK+ REFCLK- PERST# PE_RX_N 3.3V_SB M_PCIE1 PE_RX_P 1.5V SMB_CLK PE_TX_N SMB_DATA PE_TX_P USB_N USB_P 3.3V_SB 3.3V_SB 1.5V 3.3V_SB Page: 3-31 BA-2602 SERIES USER MANUAL...

  • Page 50: M-Key Slot (M2_Ssd)

    PCIe Lane2 RX+ PCIe Lane2 TX- PCIe Lane2 TX+ PCIe Lane1 RX- PCIe Lane1 RX+ PCIe Lane1 TX- PCIe Lane1 TX+ PCIe Lane0 RX- PCIe Lane0 RX+ PCIe Lane0 TX- PCIe Lane0 TX+ PLTRST Page: 3-32 BA-2602 SERIES USER MANUAL...
  • Page 51 Chapter 3 Hardware Configuration ASSIGNMENT ASSIGNMENT CLK REQ# PCIe CLK- Wake# PCIe CLK+ +3.3V +3.3V +3.3V Page: 3-33 BA-2602 SERIES USER MANUAL...

  • Page 52: Pcie Bus (Pci_E1 (X16), Pci_E2 (X4), Pci_E3 (X4), Pci_E4

    Description: 164-pin PCIE Bus (x16) PCI_E1 ASSIGNMENT ASSIGNMENT +12V PRSNT#1 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3V_AUX +3.3V WAKE# PERST# RSVD REFCLK+ HSOP0 REFCLK- HSON0 HSIP0 PRSNT#2 HSIN0 HSOP1 RSVD HSON1 HSIP1 HSIN1 HSOP2 Page: 3-34 BA-2602 SERIES USER MANUAL...
  • Page 53 RSVD HSOP4 RSVD HSON4 HSIP4 HSIN4 HSOP5 HSON5 HSIP5 HSIN5 HSOP6 HSON6 HSIP6 HSIN6 HSOP7 HSON7 HSIP7 PRSNT#2 HSIN7 HSOP8 RSVD HSON8 HSIP8 HSIN8 HSOP9 HSON9 HSIP9 HSIN9 HSOP10 HSON10 HSIP10 HSIN10 HSOP11 HSON11 Page: 3-35 BA-2602 SERIES USER MANUAL...
  • Page 54 Chapter 3 Hardware Configuration ASSIGNMENT ASSIGNMENT HSIP11 HSIN11 HSOP12 HSON12 HSIP12 HSIN12 HSOP13 HSON13 HSIP13 HSIN13 HSOP14 HSIN14 HSIP14 HSIN14 HSIP15 HSIN15 HSIP15 PRSNT#2 HSIN15 RSVD Page: 3-36 BA-2602 SERIES USER MANUAL...
  • Page 55 Chapter 3 Hardware Configuration Connector Location: PCI_E2 (x4) Description: PCIE Bus (x4) You will find the PCI_E2 connector with 64 pins on BA-2602. PCI_E2 (x4) is supported in C246 and Q370 SKUs only. PCI_E2 ASSIGNMENT ASSIGNMENT +12V PRSNT#1 +12V +12V...
  • Page 56 Chapter 3 Hardware Configuration ASSIGNMENT ASSIGNMENT HSIN2 HSOP3 HSON3 HSIP3 RSVD HSIN3 PRSNT#2 RSVD Page: 3-38 BA-2602 SERIES USER MANUAL...
  • Page 57 Chapter 3 Hardware Configuration Connector Location: PCI_E3 (x4) Description: PCIE Bus (x4) You will find the PCI_E3 connector with 64 pins on BA-2602. PCI_E3 (x4) is supported in C246 and Q370 SKUs only. PCI_E3 ASSIGNMENT ASSIGNMENT +12V PRSNT#1 +12V +12V...
  • Page 58 Chapter 3 Hardware Configuration ASSIGNMENT ASSIGNMENT HSIN2 HSOP3 HSON3 HSIP3 RSVD HSIN3 PRSNT#2 RSVD Page: 3-40 BA-2602 SERIES USER MANUAL...
  • Page 59 Chapter 3 Hardware Configuration Connector Location: PCI_E4 (x4) Description: PCIE Bus (x4) You will find the PCI_E4 connector with 64 pins on BA-2602. PCI_E4 ASSIGNMENT ASSIGNMENT +12V PRSNT#1 +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3V_AUX +3.3V WAKE# PERST#...
  • Page 60 Chapter 3 Hardware Configuration ASSIGNMENT ASSIGNMENT HSOP3 HSON3 HSIP3 RSVD HSIN3 PRSNT#2 RSVD Page: 3-42 BA-2602 SERIES USER MANUAL...
  • Page 61 Chapter 3 Hardware Configuration Connector Location: PCI_E5 (x1) Description: PCIE Bus (x1) You will find the PCI_E5 connector with 36 pins on BA-2602. PCI_E5 (x1) is supported in C246 and Q370 SKUs only. PCI_E5 ASSIGNMENT ASSIGNMENT +12V PRSNT#1 +12V +12V...

  • Page 62: Pci Bus Slot (Pci1, Pci2)

    3.4.24 PCI BUS SLOT (PCI1, PCI2) Connector Location: PCI1, PCI2 Description: 124-pin PCI Bus Slot PCI1 / PCI2 ASSIGNMENT ASSIGNMENT -12V TRST# +12V INTA# INTB# INTC# INTD# RST# GNT# REQ# AD31 AD30 AD29 +3.3V AD28 AD27 AD26 AD25 Page: 3-44 BA-2602 SERIES USER MANUAL...
  • Page 63 TRDY# DEVSEL# STOP# LOCK# +3.3V PERR# SDONE +3.3V SB0# SERR# +3.3V C/BE1# AD15 AD14 +3.3V AD13 AD12 AD11 AD10 AD09 AD08 C/BE0# AD07 +3.3V +3.3V AD06 AD05 AD04 AD03 AD02 AD01 AD00 ACK64# REQ64# Page: 3-45 BA-2602 SERIES USER MANUAL...

  • Page 64: Cpu / System Fan Connector

    3.4.25 CPU / SYSTEM FAN CONNECTOR (CPU_FAN1, SYS_FAN1, SYS_FAN2) Connector Location: CPU_FAN1, SYS_FAN1 Description: CPU Fan Connector (CPU_FAN1), System Fan Connector 1 (SYS_FAN1) CPU_FAN1 ASSIGNMENT +12V CPU_FANTAC CPU_FANCTRL SYS_FAN1 Connector Location: SYS_FAN2 Description: System Fan Connector 2 ASSIGNMENT +12V SYS_FAN2 Page: 3-46 BA-2602 SERIES USER MANUAL...

  • Page 65: Serial Ata (Sata) Connector (Sata1 ~ Sata6)

    Connector Location: SATA1, SATA2, SATA3, SATA4, SATA5, SATA6 Description: SATA Connectors SATA1 Pin Assignment: ASSIGNMENT SATA_TXP0 SATA_TXN0 SATA1/ SATA_RXN0 SATA3/ SATA_RXP0 SATA5 SATA2 Pin Assignment: ASSIGNMENT SATA_TXP1 SATA_TXN1 SATA_RXN1 SATA2/ SATA_RXP1 SATA4/ SATA6 SATA3 Pin Assignment: ASSIGNMENT SATA_TXP2 SATA_TXN2 SATA_RXN2 SATA_RXP2 Page: 3-47 BA-2602 SERIES USER MANUAL...
  • Page 66 ASSIGNMENT SATA_TXP3 SATA_TXN3 SATA_RXN3 SATA_RXP3 SATA5 Pin Assignment: ASSIGNMENT SATA_TXP4 SATA_TXN4 SATA_RXN4 SATA_RXP4 SATA6 Pin Assignment: ASSIGNMENT SATA_TXP5 SATA_TXN5 SATA_RXN5 SATA_RXP5 Notes: C246 SKU supports SATA1~SATA6. Q370 SKU supports SATA1~SATA6. H310 SKU supports SATA1~SATA4. Page: 3-48 BA-2602 SERIES USER MANUAL...

  • Page 67: Internal Usb 3.1 Connector (Usb1)

    Chapter 3 Hardware Configuration 3.4.27 INTERNAL USB 3.1 CONNECTOR (USB1) Connector Location: USB1 Description: Internal USB 3.1 Connector ASSIGNMENT ASSIGNMENT USB D+ USB_RX_N USB D- USB_RX_P USB_TX_P USB_TX_N USB_TX_N USB_TX_P USB_RX_P USB D- USB_RX_N USB D+ USB1 Page: 3-49 BA-2602 SERIES USER MANUAL...

  • Page 68: Internal Usb 2.0 Connector (Usb2, Usb3, Usb4)

    Chapter 3 Hardware Configuration 3.4.28 INTERNAL USB 2.0 CONNECTOR (USB2, USB3, USB4) Connector Location: USB2, USB3, USB4 Description: Internal USB 2.0 Connector ASSIGNMENT ASSIGNMENT USB D- USB D- USB D+ USB D+ USB2/ USB3/ USB4 Page: 3-50 BA-2602 SERIES USER MANUAL...

  • Page 69: Speaker Connector (Jspk1)

    Chapter 3 Hardware Configuration 3.4.29 SPEAKER CONNECTOR (JSPK1) Connector Location: JSPK1 Description: Speaker Connector ASSIGNMENT JSPK1 SPKR_VCC SPKR_SIGNAL SPKR_SIGNAL SPKR_SIGNAL Page: 3-51 BA-2602 SERIES USER MANUAL...

  • Page 70: Power Input Connector (Atx_Pwr1, Atx_Pwr2)

    3.4.30 POWER INPUT CONNECTOR (ATX_PWR1, ATX_PWR2) Connector Location: ATX_PWR1 Description: ATX Power Connector ASSIGNMENT ASSIGNMENT +3.3V +3.3V ATX_PWR1 +3.3V -12V PSON ATX_PWR1 +5V_SB +12V +12V +3.3V Connector Location: ATX_PWR2 Description: Power Connector ASSIGNMENT ASSIGNMENT +12V +12V ATX_PWR2 Page: 3-52 BA-2602 SERIES USER MANUAL...

  • Page 71: Low Pin Count (Lpc) Connector (Jlpc1)

    Chapter 3 Hardware Configuration 3.4.31 LOW PIN COUNT (LPC) CONNECTOR (JLPC1) Connector Location: JLPC1 Description: LPC Connector ASSIGNMENT ASSIGNMENT FRAME RESET VCC5 LAD3 LAD2 VCC3 LAD1 JLPC1 LAD0 SMBCLK SMBDATA 3VSB SERIRQ CLK RUN SUS_TAT DREQ0 Page: 3-53 BA-2602 SERIES USER MANUAL...

  • Page 72: Clear Cmos Data Selection (Jcmos1)

    Step 4. Power on the PC and the PC will then auto-reboot for once in order to set SoC’s register. Step 5. Done! Jumper Setting Selection Jumper Illustration (Pin Closed) Open Normal (Default Setting) JCMOS1 Clear CMOS JCMOS1 3.4.33 NMI HEADER (JNMI1) Connector Location: JNMI1 Description: NMI Header ASSIGNMENT 3.3V JNMI1 Page: 3-54 BA-2602 SERIES USER MANUAL...

  • Page 73: Flash Bios Header (Jspi_1)

    Description: Flash BIOS Header ASSIGNMENT ASSIGNMENT +3.3V SCLK MISO MOSI HOLD# JSPI_1 3.4.35 APS HEADER (JAPS1) Connector Location: JAPS1 Description: APS Header ASSIGNMENT ASSIGNMENT +3.3V +3.3V SLP_S5# SLP_S3# JAPS1 SLP_A# RTC RST# SLP_S4# SYS RST# Power BTN Page: 3-55 BA-2602 SERIES USER MANUAL...

  • Page 74: Micro Sim Card Socket (Sim1)

    3.4.36 MICRO SIM CARD SOCKET (SIM1) Connector Location: SIM1 Description: Micro SIM Push/Push type (located on the rear side of BA-2602) ASSIGNMENT SIM PWR ATTEND SIM RST SIM VPP SIM CLK SIM DATA Reserved Reserved SIM1 Page: 3-56 BA-2602 SERIES USER MANUAL...

  • Page 75: Software Utilities

    • Installing LAN Driver Utility • Installing Sound Driver Utility • Installing Intel ® Management Engine Components Driver Installer • Installing Intel ® Rapid Storage Utility • Installing Intel ® Serial I/O Driver Utility BA-2602 SERIES USER MANUAL Page: 4-1...

  • Page 76: Introduction

    Chapter 4 Software Utilities Introduction Enclosed with the BA-2602 Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: Filename (Assume that Purpose DVD-ROM drive is D:) D:\Driver\Platform\1_Main Chip\Win10(64-bit) Intel(R) Chipset Device Software installer...

  • Page 77: Installing Intel Chipset Software Installation Utility

    The utility pack is to be installed only for Windows 10 (64-bit), and it should be installed immediately after the OS installation is finished. Please follow the steps below: Connect the USB DVD-ROM device to BA-2602 and insert the driver disk. Enter the Main Chip folder where the Chipset driver is located (depending on your OS platform).

  • Page 78: Installing Graphics Driver Utility

    VGA, DP and eDP (for Q370 & C246 SKU only) interfaces and make the system work simultaneously. To install the Graphics driver utility, follow the steps below: Connect the USB DVD-ROM device to BA-2602 and insert the driver disk. Enter the Graphics folder where the driver is located (depending on your OS platform).

  • Page 79: Installing Lan Driver Utility

    Enhanced with LAN function, BA-2602 supports various network adapters. To install the LAN Driver, follow the steps below: Connect the USB DVD-ROM device to BA-2602 and insert the driver disk. Enter the LAN folder where the driver is located (depending on your OS platform).

  • Page 80: Installing Sound Driver Utility

    Chapter 4 Software Utilities Installing Sound Driver Utility To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to BA-2602 and insert the driver disk. Open the Sound folder where the driver is located (depending on your OS platform).

  • Page 81: Intel ® Management Engine Components Driver Installer

    ® Installation Instructions for Intel Management Engine Components Driver Installer Connect the USB DVD-ROM device to BA-2602 and insert the driver disk. Enter the ME folder where the driver is located. Select H310 or Q370&C246 SKU. Click SetupME.exe file for ME driver installation.

  • Page 82: Installing Raid Utility (Only For C246/Q370, Optional)

    Press <Del> to access the BIOS Setup Utility program when prompted during the Power-On Self-Test (POST). Enter Chipset > PCH-IO Configuration > SATA Configuration menu screen and select “RAID” option for SATA Controller(s) option item. See the picture below: BA-2602 SERIES USER MANUAL Page: 4-8...
  • Page 83 Press F4 to save and validate the changed BIOS configuration and reset the system. Press <Del> to enter the BIOS Setup Utility program again and the Intel(R) Rapid Storage Technology option item will display under the Advanced menu screen as below: BA-2602 SERIES USER MANUAL Page: 4-9...
  • Page 84 Chapter 4 Software Utilities Select the Intel(R) Rapid Storage Technology option item and press <Enter>, and the following screen will display. Select a RAID level that you want to enter and press <Enter>. BA-2602 SERIES USER MANUAL Page: 4-10...
  • Page 85 The hard drive(s) and hard drive information of the RAID level you selected in the previous step will display: Heed that in the user interface, the hard drive(s) and hard drive information listed for your system will differ from the example above. BA-2602 SERIES USER MANUAL Page: 4-11...
  • Page 86 RST) utility supports RAID 0, 1, 5, 10 in C246/Q370 SKU. To install the RAID utility, follow the steps below: Connect the USB DVD-ROM device to BA-2602 and insert the driver disk. Enter the RAID folder where the utility is located.

  • Page 87: Installing Intel Serial I/O Driver Utility

    Installing Intel Serial I/O Driver Utility To install the Serial I/O Driver, follow the steps below: Connect the USB DVD-ROM device to BA-2602 and insert the driver disk. Open the Serial I/O folder where the driver is located. Select Windows 10 (64-bit) for your OS platform.

  • Page 88: Bios Setup

    The BIOS Setup Utilities consist of the following menu items: • Main Menu • Advanced Menu • Chipset Menu • Security Menu • Boot Menu • Save & Exit Menu BA-2602 SERIES USER MANUAL Page: 5-1...

  • Page 89: Introduction

    Chapter 5 BIOS Setup Introduction The BA-2602 board uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the built-in BIOS setup program, Power-On Self-Test (POST), PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.

  • Page 90: Accessing Setup Utility

    POST message will be displayed: Figure 5-2. POST Screen with AMI Logo Press <Del> or <Esc> to access the Setup Utility program and the Main menu of the Aptio Setup Utility will appear on the screen as below: BA-2602 SERIES USER MANUAL Page: 5-3...
  • Page 91 English. You may use <↑> or <↓> key to select among the items and press <Enter> to confirm and enter the sub-menu. The following table provides the list of the navigation keys that you can use while operating the BIOS setup menu. BA-2602 SERIES USER MANUAL Page: 5-4...
  • Page 92 Load the previous configuration values. <F3> Load the default configuration values. <F4> Save the current values and exit the BIOS setup menu. <Esc> Close the sub-menu. Trigger the confirmation to exit BIOS setup menu. BA-2602 SERIES USER MANUAL Page: 5-5...

  • Page 93: Main

    Name No changeable options Displays the name of the PCH. PCH SKU No changeable options Displays the SKU for the PCH. Stepping No changeable options Displays the stepping of the PCH. BA-2602 SERIES USER MANUAL Page: 5-6...
  • Page 94 The “Day” is automatically changed. System Time Hour, minute, second Sets the system time. The format is [Hour: Minute: Second]. Users can directly enter values or use <+> or <-> arrow keys to increase/decrease it. BA-2602 SERIES USER MANUAL Page: 5-7...

  • Page 95: Advanced

    Sub-Menu S5 RTC Wake Parameters. Super IO Configuration Sub-Menu System Super I/O Chip Parameters. USB Configuration Sub-Menu USB Configuration Parameters. NVMe Configuration Sub-Menu NVMe Device Options Settings. Network Stack Configuration Sub-Menu Network Stack Settings. BA-2602 SERIES USER MANUAL Page: 5-8...

  • Page 96: Advanced - Cpu Configuration

    SMX (Secure Mode No changeable options Secure Mode extensions support. Extensions) / TXT When enabled, VMM can utilize the Intel Virtualization - Disabled additional hardware capabilities Technology - Enabled (default) provided by Vanderpool Technology. BA-2602 SERIES USER MANUAL Page: 5-9...

  • Page 97: Advanced - Pch-Fw Configuration

    Description/Purpose ME Firmware Version No changeable options Displays the ME Firmware Version. ME Firmware Mode No changeable options Displays the ME Firmware Mode. ME Firmware SKU No changeable options Displays the ME Firmware SKU. BA-2602 SERIES USER MANUAL Page: 5-10...

  • Page 98: Advanced - Trusted Computing

    TPM module vendor. Security Device - Enable (default) Enables or Disables BIOS support for Support - Disable security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. BA-2602 SERIES USER MANUAL Page: 5-11...

  • Page 99: Advanced - Acpi Settings

    SUSPEND (default) button is pressed. Lock Legacy - Disabled (default) Enables or Disables Lock of Legacy Resources - Enabled Resources. - Disabled (default) S3 Video Repost Enables or Disables S3 Video Repost. - Enabled BA-2602 SERIES USER MANUAL Page: 5-12...

  • Page 100: Advanced - Hardware Monitor

    Displays the voltage level of VCORE VCORE No changeable options in supply. Displays the voltage level of VCC5V VCC5V No changeable options in supply. Displays the voltage level of VCC12 VCC12 No changeable options in supply. BA-2602 SERIES USER MANUAL Page: 5-13...
  • Page 101 CPU Fan Smart Fan Control - Auto Duty-Cycle Mode Fan. (default) Manual mode fan control. Users can Manual Duty Mode Numeric (from 1 to 100) write expected duty cycle (PWM fan type) from 1 to 100. BA-2602 SERIES USER MANUAL Page: 5-14...

  • Page 102: Advanced - Super Io Watchdog

    Enables/Disables F81866 Watchdog Enable Watchdog - Disabled (default) timer settings. - 1s (default) Watchdog timer unit Watchdog timer unit. - 60s Numeric Count for Timer (Seconds) The number of count for Timer. (from 10 to 255) BA-2602 SERIES USER MANUAL Page: 5-15...

  • Page 103: Advanced - S5 Rtc Wake Settings

    Enters 0-59 to set the wake-up Wake up second Numeric (from 0 to 59) second. Enters 1-5 to set the increased Wake up minute increase Numeric (from 1 to 5) minute(s) for dynamic wake-up time. BA-2602 SERIES USER MANUAL Page: 5-16...

  • Page 104: Advanced - Super Io Configuration

    Sets Parameters of Serial Port 5 (COME). (for Q370/C246 only) Serial Port 6 Configuration Sub-Menu Sets Parameters of Serial Port 6 (COMF). (for Q370/C246 only) Parallel Port Sub-Menu Sets Parameters of Parallel Port (LPT). BA-2602 SERIES USER MANUAL Page: 5-17...

  • Page 105: Super Io Configuration - Serial Port 1 Configuration

    No changeable options Serial Port 1. Possible - Auto (default) Selects IRQ and I/O resource for - IO=3F8h; IRQ=4; Serial Port 1. - IO=3F8h; IRQ=3,4,5,6,7,10,11; - IO=2F8h; IRQ=3,4,5,6,7,10,11; - IO=3E8h; IRQ=3,4,5,6,7,10,11; - IO=2E8h; IRQ=3,4,5,6,7,10,11; BA-2602 SERIES USER MANUAL Page: 5-18...

  • Page 106: Super Io Configuration - Serial Port 2 Configuration

    Selects IRQ and I/O resource for - IO=2F8h; IRQ=3; Serial Port 2. - IO=3F8h; IRQ=3,4,5,6,7,10,11; Change Settings - IO=2F8h; IRQ=3,4,5,6,7,10,11; - IO=3E8h; IRQ=3,4,5,6,7,10,11; - IO=2E8h; IRQ=3,4,5,6,7,10,11; - RS-232 (default) Mode - RS-422 Selects COM2 mode. - RS-485 BA-2602 SERIES USER MANUAL Page: 5-19...

  • Page 107: Super Io Configuration - Serial Port 3 Configuration

    No changeable options Serial Port 3. - Auto (default) Selects IRQ and I/O resource for - IO=3E8h; IRQ=7; Serial Port 3. - IO=3E8h; IRQ=3,4,5,6,7,10,11; Change Settings - IO=2E8h; IRQ=3,4,5,6,7,10,11; - IO=2F0h; IRQ=3,4,5,6,7,10,11; - IO=2E0h; IRQ=3,4,5,6,7,10,11; BA-2602 SERIES USER MANUAL Page: 5-20...

  • Page 108: Super Io Configuration - Serial Port 4 Configuration

    No changeable options Serial Port 4. - Auto (default) Selects IRQ and I/O resource for - IO=2E8h; IRQ=6; Serial Port 4. - IO=3E8h; IRQ=3,4,5,6,7,10,11; Change Settings - IO=2E8h; IRQ=3,4,5,6,7,10,11; - IO=2F0h; IRQ=3,4,5,6,7,10,11; - IO=2E0h; IRQ=3,4,5,6,7,10,11; BA-2602 SERIES USER MANUAL Page: 5-21...

  • Page 109: Super Io Configuration - Serial Port 5 Configuration

    No changeable options Serial Port 5. - Auto (default) Selects IRQ and I/O resource for - IO=2F0h; IRQ=10; Serial Port 5. - IO=3E8h; IRQ=3,4,5,6,7,10,11; Change Settings - IO=2E8h; IRQ=3,4,5,6,7,10,11; - IO=2F0h; IRQ=3,4,5,6,7,10,11; - IO=2E0h; IRQ=3,4,5,6,7,10,11; BA-2602 SERIES USER MANUAL Page: 5-22...

  • Page 110: Super Io Configuration - Serial Port 6 Configuration

    No changeable options Serial Port 6. - Auto (default) Selects IRQ and I/O resource for - IO=2E0h; IRQ=11; Serial Port 6. - IO=3E8h; IRQ=3,4,5,6,7,10,11; Change Settings - IO=2E8h; IRQ=3,4,5,6,7,10,11; - IO=2F0h; IRQ=3,4,5,6,7,10,11; - IO=2E0h; IRQ=3,4,5,6,7,10,11; BA-2602 SERIES USER MANUAL Page: 5-23...

  • Page 111: Super Io Configuration - Parallel Port Configuration

    After the mode is changed, Mode - EPP-1.7 and SPP Mode reset the system to reflect the actual - ECP Mode device settings. - ECP and EPP 1.9 Mode - ECP and EPP 1.7 Mode BA-2602 SERIES USER MANUAL Page: 5-24...

  • Page 112: Advanced - Usb Configuration

    Optical drives Mass Storage - Forced FDD are emulated as 'CD-ROM'. Drives Devices: [drive(s)] - Hard Disk with no media will be emulated - CD-ROM according to a drive type. BA-2602 SERIES USER MANUAL Page: 5-25...

  • Page 113: Advanced - Nvme Configuration

    Chapter 5 BIOS Setup 5.4.10 Advanced – NVMe Configuration Menu Path Advanced > NVMe Configuration NVMe Configuration Screen BIOS Setting Options Description/Purpose NVMe Configuration No changeable options Displays NVMe device. BA-2602 SERIES USER MANUAL Page: 5-26...

  • Page 114: Advanced - Network Stack Configuration

    - Disabled (default) Enables or Disables UEFI Network Network Stack - Enabled Stack. Enables Ipv4 PXE Boot Support. If - Disabled (default) Ipv4 PXE Support disabled, Ipv4 PXE boot option will - Enabled not be created. BA-2602 SERIES USER MANUAL Page: 5-27...
  • Page 115 PXE boot wait time Numeric (from 0 to 5) boot to abort after the Esc key is pressed. Number of times that the media Media detect count Numeric (from 1 to 50) presence will be checked. BA-2602 SERIES USER MANUAL Page: 5-28...

  • Page 116: Chipset

    This menu allows users to configure advanced Chipset settings such as System Agent (SA) and PCH-IO configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose System Agent (SA) Parameters Sub-Menu System Agent (SA) Parameters. PCH-IO Configuration Sub-Menu PCH Parameters. BA-2602 SERIES USER MANUAL Page: 5-29...

  • Page 117: Chipset - System Agent (Sa) Configuration

    System Agent (SA) Configuration Screen BIOS Setting Options Description/Purpose Memory Configuration Sub-Menu Memory Configuration. Graphics Configuration Sub-Menu Graphics Configuration. PEG Port Configuration Sub-Menu PEG Port Configuration. - Disabled VT-d Enables or Disables VT-d function. - Enabled (default) BA-2602 SERIES USER MANUAL Page: 5-30...

  • Page 118: System Agent (Sa) Configuration - Memory Configuration

    No changeable options Displays the size of DIMM1. DIMM2 No changeable options Displays the size of DIMM2. (for Q370/C246 only) DIMM3 No changeable options Displays the size of DIMM3. DIMM4 No changeable options Displays the size of DIMM4. (for Q370/C246 only) BA-2602 SERIES USER MANUAL Page: 5-31...

  • Page 119: System Agent (Sa) Configuration - Graphics Configuration

    The Graphics Configuration allows users to configure the display settings for the LCD panel. Graphics Configuration Screen BIOS Setting Options Description/Purpose - Auto (default) Selects which Graphics device should Primary Display - IGFX be Primary Display. BA-2602 SERIES USER MANUAL Page: 5-32...

  • Page 120: System Agent (Sa) Configuration - Peg Port Configuration

    No changeable options information. - Disabled Enable Root Port - Enabled Enables or Disables the Root Port. - Auto (default) - Auto (default) - Gen1 Max Link Speed Configures PCI-E1 Max Speed. - Gen2 - Gen3 BA-2602 SERIES USER MANUAL Page: 5-33...

  • Page 121: Chipset - Pch Io Configuratioin

    - Enabled (default) to wake up the system. Specifies the state to go to when AC - Power On Restore AC Power Loss power is re-applied following a - Power Off (default) power failure (G3 state). BA-2602 SERIES USER MANUAL Page: 5-34...

  • Page 122: Pch-Io Configuration - Pci Express Configuration

    PCI Express x4 Slot settings. PCI Express x1 – SLOT#5 Sub-Menu PCI Express x1 Slot settings. (for Q370/C246 only) Mini PCI Express x1 SLOT Sub-Menu Mini PCI Express x1 Slot settings. (for Q370/C246 only) BA-2602 SERIES USER MANUAL Page: 5-35...
  • Page 123 • Disabled - Disables ASPM. - Auto - Disabled (default) L1 Substates - L1.1 PCI Express L1 Substates settings. - L1.1 & L1.2 - Disabled (default) Hot Plug Enables or Disables Hot Plug support. - Enabled BA-2602 SERIES USER MANUAL Page: 5-36...

  • Page 124: Pch-Io Configuration - Pci Express Configuration - Pci Express X4 - Slot#3 (For Q370 / C246 Sku Only)

    - Disabled (default) Sets the ASPM Level: - L0s • L0s - Force all links to L0s state. ASPM - L1 • Auto - BIOS auto configure. - L0sL1 • Disabled - Disables ASPM. - Auto BA-2602 SERIES USER MANUAL Page: 5-37...
  • Page 125 Configuration > PCI Express x4 – SLOT#4 PCI Express x4 Slot#4 Screen BIOS Setting Options Description/Purpose - Disabled Enables or Disables the PCI PCI Express x4 – SLOT#4 - Enabled (default) Express x4 slot. BA-2602 SERIES USER MANUAL Page: 5-38...
  • Page 126 Hot Plug - Enabled support. - Auto (default) - Gen1 PCIe Speed Configures PCIe Speed. - Gen2 - Gen3 - PCIe X4 slot (default) PCIe SLOT4 Select PCIe SLOT#4 function selection. - M.2 NVMe slot BA-2602 SERIES USER MANUAL Page: 5-39...

  • Page 127: Pch-Io Configuration - Pci Express Configuration - Pci Express X1 - Slot#5 (For Q370 / C246 Sku Only)

    L1 Substates - L1.1 PCI Express L1 Substates settings - L1.1 & L1.2 - Disabled (default) Hot Plug Enables or Disables Hot Plug support. - Enabled PCIe Speed - Auto (default) Configures PCIe speed. BA-2602 SERIES USER MANUAL Page: 5-40...
  • Page 128 ASPM - L1 • Auto - BIOS auto configure. - L0sL1 • Disabled - Disables ASPM. - Auto - Disabled (default) L1 Substates - L1.1 PCI Express L1 Substates settings. - L1.1 & L1.2 BA-2602 SERIES USER MANUAL Page: 5-41...

  • Page 129: Configuration

    - Enabled - AHCI (default) SATA Mode Determines how SATA controller(s) operate. - Intel RST (RAID) Serial ATA Port 1 – 6 (ports 5-6 for No changeable options Displays the SATA device’s name. Q370/C246 only) BA-2602 SERIES USER MANUAL Page: 5-42...
  • Page 130 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose - Disabled Port 1 - 6 Enables or Disables SATA Port Device. - Enabled (default) - Disabled (default) Enables or Disables SATA Port Device HotPlug HotPlug - Enabled function. BA-2602 SERIES USER MANUAL Page: 5-43...

  • Page 131: Security

    Setup utility. Security Screen BIOS Setting Options Description/Purpose Administrator Password Password can be 3-20 Specifies the administrator alphanumeric characters. password. User Password Password can be 3-20 Specifies the user password. alphanumeric characters. BA-2602 SERIES USER MANUAL Page: 5-44...
  • Page 132 <Enter>, and the password dialog entry box appears. Select the configured Administrator Password or User Password that you want to delete. Leave the dialog box blank and press <Enter>. Press <Enter> again when the password confirmation box appears. BA-2602 SERIES USER MANUAL Page: 5-45...

  • Page 133: Boot

    Specifies the power-on state of the Bootup NumLock State - Off NumLock Key. - Disabled (default) Enables or Disables Quiet Boot Quiet Boot - Enabled option. - [Drive(s)] Boot Option #1~#n Sets the system boot order. - Disabled BA-2602 SERIES USER MANUAL Page: 5-46...

  • Page 134: Save & Exit

    Discard Changes and Reset to discard any changes you have made and restore the factory BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Screen BA-2602 SERIES USER MANUAL Page: 5-47...
  • Page 135 Saves the changes done so far as User Save as User Defaults No changeable options Defaults. Restores the User Defaults to all the Restore User Defaults No changeable options setup options. Forces to boot from selected Boot Override - [Drive(s)] [drive(s)]. BA-2602 SERIES USER MANUAL Page: 5-48...

  • Page 136: Appendix A Technical Summary

    Appendix A Technical Summary This appendix will give you a brief introduction of the allocation maps for BA-2602 resources. The following topics are included: • BA-2602 Block Diagram • Interrupt Map • I/O Map • Memory Map • DMA Map •...

  • Page 137: Ba-2602 Block Diagram

    LPC SLOT Connector (SLB9665TT2.0-5.63) COM 2 RS232/422/485 HW monitor FINTEK COM 3 (5V/12V) RS232 LPC SIO PS/2 Keyboard COM 4 Mouse F81866AD-I (5V/12V) RS232 COM 5 LPT Port RS232 (wafer pitch2.0) COM 6 RS232 BA-2602 SERIES USER MANUAL Page: A-2...

  • Page 138: Interrupt Map

    IRQ 64 Microsoft ACPI-Compliant System IRQ 65 Microsoft ACPI-Compliant System IRQ 66 Microsoft ACPI-Compliant System IRQ 67 Microsoft ACPI-Compliant System IRQ 68 Microsoft ACPI-Compliant System IRQ 69 Microsoft ACPI-Compliant System IRQ 70 Microsoft ACPI-Compliant System Page: A-3 BA-2602 SERIES USER MANUAL...
  • Page 139 IRQ 97 Microsoft ACPI-Compliant System IRQ 98 Microsoft ACPI-Compliant System IRQ 99 Microsoft ACPI-Compliant System IRQ 100 Microsoft ACPI-Compliant System IRQ 101 Microsoft ACPI-Compliant System IRQ 102 Microsoft ACPI-Compliant System IRQ 103 Microsoft ACPI-Compliant System BA-2602 SERIES USER MANUAL Page: A-4...
  • Page 140 IRQ 132 Microsoft ACPI-Compliant System IRQ 133 Microsoft ACPI-Compliant System IRQ 134 Microsoft ACPI-Compliant System IRQ 135 Microsoft ACPI-Compliant System IRQ 136 Microsoft ACPI-Compliant System IRQ 137 Microsoft ACPI-Compliant System IRQ 138 Microsoft ACPI-Compliant System Page: A-5 BA-2602 SERIES USER MANUAL...
  • Page 141 IRQ 165 Microsoft ACPI-Compliant System IRQ 166 Microsoft ACPI-Compliant System IRQ 167 Microsoft ACPI-Compliant System IRQ 168 Microsoft ACPI-Compliant System IRQ 169 Microsoft ACPI-Compliant System IRQ 170 Microsoft ACPI-Compliant System IRQ 171 Microsoft ACPI-Compliant System BA-2602 SERIES USER MANUAL Page: A-6...
  • Page 142 IRQ 200 Microsoft ACPI-Compliant System IRQ 201 Microsoft ACPI-Compliant System IRQ 202 Microsoft ACPI-Compliant System IRQ 203 Microsoft ACPI-Compliant System IRQ 204 Microsoft ACPI-Compliant System IRQ 256 Microsoft ACPI-Compliant System IRQ 257 Microsoft ACPI-Compliant System Page: A-7 BA-2602 SERIES USER MANUAL...
  • Page 143 IRQ 284 Microsoft ACPI-Compliant System IRQ 285 Microsoft ACPI-Compliant System IRQ 286 Microsoft ACPI-Compliant System IRQ 287 Microsoft ACPI-Compliant System IRQ 288 Microsoft ACPI-Compliant System IRQ 289 Microsoft ACPI-Compliant System IRQ 290 Microsoft ACPI-Compliant System BA-2602 SERIES USER MANUAL Page: A-8...
  • Page 144 IRQ 319 Microsoft ACPI-Compliant System IRQ 320 Microsoft ACPI-Compliant System IRQ 321 Microsoft ACPI-Compliant System IRQ 322 Microsoft ACPI-Compliant System IRQ 323 Microsoft ACPI-Compliant System IRQ 324 Microsoft ACPI-Compliant System IRQ 325 Microsoft ACPI-Compliant System Page: A-9 BA-2602 SERIES USER MANUAL...
  • Page 145 IRQ 352 Microsoft ACPI-Compliant System IRQ 353 Microsoft ACPI-Compliant System IRQ 354 Microsoft ACPI-Compliant System IRQ 355 Microsoft ACPI-Compliant System IRQ 356 Microsoft ACPI-Compliant System IRQ 357 Microsoft ACPI-Compliant System IRQ 358 Microsoft ACPI-Compliant System BA-2602 SERIES USER MANUAL Page: A-10...
  • Page 146 IRQ 387 Microsoft ACPI-Compliant System IRQ 388 Microsoft ACPI-Compliant System IRQ 389 Microsoft ACPI-Compliant System IRQ 390 Microsoft ACPI-Compliant System IRQ 391 Microsoft ACPI-Compliant System IRQ 392 Microsoft ACPI-Compliant System IRQ 393 Microsoft ACPI-Compliant System Page: A-11 BA-2602 SERIES USER MANUAL...
  • Page 147 IRQ 420 Microsoft ACPI-Compliant System IRQ 421 Microsoft ACPI-Compliant System IRQ 422 Microsoft ACPI-Compliant System IRQ 423 Microsoft ACPI-Compliant System IRQ 424 Microsoft ACPI-Compliant System IRQ 425 Microsoft ACPI-Compliant System IRQ 426 Microsoft ACPI-Compliant System BA-2602 SERIES USER MANUAL Page: A-12...
  • Page 148 IRQ 455 Microsoft ACPI-Compliant System IRQ 456 Microsoft ACPI-Compliant System IRQ 457 Microsoft ACPI-Compliant System IRQ 458 Microsoft ACPI-Compliant System IRQ 459 Microsoft ACPI-Compliant System IRQ 460 Microsoft ACPI-Compliant System IRQ 461 Microsoft ACPI-Compliant System Page: A-13 BA-2602 SERIES USER MANUAL...
  • Page 149 IRQ 488 Microsoft ACPI-Compliant System IRQ 489 Microsoft ACPI-Compliant System IRQ 490 Microsoft ACPI-Compliant System IRQ 491 Microsoft ACPI-Compliant System IRQ 492 Microsoft ACPI-Compliant System IRQ 493 Microsoft ACPI-Compliant System IRQ 494 Microsoft ACPI-Compliant System BA-2602 SERIES USER MANUAL Page: A-14...
  • Page 150 Intel(R) USB 3.1 eXtensible Host Controller - 1.10 IRQ 4294967292 (Microsoft) IRQ 4294967293 Intel(R) UHD Graphics P630 IRQ 4294967294 Standard SATA AHCI Controller Note: These resource information were gathered using Windows 10 (the IRQ could be assigned differently depending on OS). Page: A-15 BA-2602 SERIES USER MANUAL...

  • Page 151: I/O Map

    Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B2-0x000000B3 Motherboard resources 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller BA-2602 SERIES USER MANUAL Page: A-16...
  • Page 152 Intel(R) PCI Express Root Port #11 - A332 0x00004000-0x0000403F Intel(R) UHD Graphics P630 0x00004060-0x0000407F Standard SATA AHCI Controller 0x00004080-0x00004083 Standard SATA AHCI Controller 0x00004090-0x00004097 Standard SATA AHCI Controller 0x0000EFA0-0x0000EFBF Intel(R) SMBus - A323 Intel(R) Active Management Technology - 0x0000FFF8-0x0000FFFF SOL (COM8) Page: A-17 BA-2602 SERIES USER MANUAL...

  • Page 153: Memory Map

    PCI Express Root Complex 0xA1234000-0xA1235FFF Standard SATA AHCI Controller 0xA123A000-0xA123A0FF Standard SATA AHCI Controller 0xA1239000-0xA12397FF Standard SATA AHCI Controller 0xFE010000-0xFE010FFF Intel(R) SPI (flash) Controller - A324 Intel(R) Active Management Technology - 0xFE1DF000-0xFE1DFFFF SOL (COM8) BA-2602 SERIES USER MANUAL Page: A-18...

  • Page 154: Dma Map

    PCI Express Root Complex 0xE4000-0xE7FFF PCI Express Root Complex 0xE8000-0xEBFFF PCI Express Root Complex 0xEC000-0xEFFFF PCI Express Root Complex 0xF0000-0xFFFFF PCI Express Root Complex 0x40000000-0x403FFFFF Motherboard resources DMA Map DMA MAP ASSIGNMENT Channel 3 Printer Port (LPT1) Page: A-19 BA-2602 SERIES USER MANUAL...

  • Page 155: Configuring Watchdog Timer

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. BA-2602 SERIES USER MANUAL Page: A-20...
  • Page 156 ; ---------------- Set timeout interval as 30 seconds and start counting -------------------------- ;------------------------------- Enable Watch PME--------------------------------------------------------- ;-------------------------- Set second as counting unit -------------------------------------------------- ;-------------------------- Start the watchdog timer ------------------------------------------------------ ;---------------------------------Exit the extended function mode -------------------------------------- Page: A-21 BA-2602 SERIES USER MANUAL...

  • Page 157: Flash Bios Update

    (2) Turn on the computer and press <ESC> or <DEL> during boot to enter BIOS Setup. (3) Select [Boot] menu and set the USB bootable device as the 1st boot device. (4) Press <F4> to save the configuration and exit the BIOS setup menu. BA-2602 SERIES USER MANUAL Page: A-22...
  • Page 158 BIOS ROM and make the system unable to boot up next time. After BIOS update procedure is completed, the messages below will display: Page: A-23 BA-2602 SERIES USER MANUAL...
  • Page 159 Restart the system and boot up with the new BIOS configurations. The BIOS Update is completed after the system is restarted. Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. BA-2602 SERIES USER MANUAL Page: A-24...

Table of Contents
