Room Distribution - GE SENOGRAPHE DMR+ Preinstallation Manual

GE Healthcare
REV 1
3–7

Room distribution

Note:
D
NEC 1993 Section 517–73 (a) Item 1:
The ampacity of supply branch circuit conductors and the current rating of overcurrent
protective devices shall not be less than 50 percent of the momentory rating or 100 percent
of the long-time rating, whichever is greater.
D
NEC 1993 Section 517–73 (a) Item 2:
The ampacity of supply feeders and the current rating of overcurrent protective devices
supplying two or more branch circuits supplying x-ray units shall not be less than 50
percent of the momentary demand rating of the largest unit plus 25 percent of the
momentary demand rating of the next largest unit plus 10 percent of the momentary
demand rating of each additional unit. Where simultaneous biplane examinations are
undertaken with the x-ray units, the supply conductors and overcurrent protective devices
shall be 100 percent of the momentary demand rating of each x-ray unit.
The senographe DMR provides a room distribution from the generator cabinet (using the
dedicated board 200PL4).
D
Senographe ON lamp: relay rating is 8A @ 250V AC or 5A @ 30V DC
D
X–Ray ON lamp: relay rating is 8A @ 250V AC or 5A @ 30V DC
D
Room door switch: relay coil must be supplied with 24V AC
ONLY for GEMSE: the Generic EDM is associated with an external modem (Motorola
3265) mounted on the EDM cabinet.
For GEMS A and GEMS AM the Generic EDM incorporates a modem board inside the
All
EDM cabinet.
customer-supplied.The wire path inside the generator is identical to the feeder
wire path.
2–6
hardware outside the
SENOGRAPHE DMR+
pim 5128706–1–100
generator cabinet is
