Product Shipping Information; Tools And Test Equipment; Interconnections - GE SENOGRAPHE DMR+ Preinstallation Manual

GE Healthcare
REV 1
SECTION 1

PRODUCT SHIPPING INFORMATION

PRODUCT/
COMPONENT
SENO DMR
STEREOTIX 2
(OPTION)
ACCESSORIES
STORAGE DEVICE
(OPTION)
DATAFLASH
(OPTION)
SECTION 2

TOOLS AND TEST EQUIPMENT

SECTION 3

INTERCONNECTIONS

AIR AND ROAD SHIPMENT
HEIGHT X WIDTH X DEPTH
6'36 X 3'. X 7'.
(1.94 X 0.90 X 2.14)
2.29' X 2.17' X4.85'
(0.70 X 0.66 X 1.48)
4.13' X 2.18' X 3.54'
(1.26 X 0.68 X 1.08)
17.7" X 13" X 15.75"
0.45 X 0.33 X 0.40
D NOT APPLICABLE.
D See Illustration 4-1.
1 MAXIMUM CONNECTOR SIZE: 72 mm dia (3" dia)
2 MAXIMUM CONNECTOR SIZE: 56 mm x 15 mm (2.1" x 0.6")
4–3
SENOGRAPHE DMR+
pim 5128706–1–100
WEIGHT
METHOD OF SHIPMENT
POUNDS (daN)
1476 (670)
199 (85)
308 (140)
27.5 (12.5)
PALLET
CRATE
CRATE
CRATE
