R-NIS3100 Switch GHardware Installation and Reference Guide
Figure 1-5
Rear Panel for Wall Mounting
1. DIN rail clamp
5. Bottom Panel
Figure 1-6
Bottom Panel of NIS3100-8GT4SFP-HP
1. Nameplate
2. Mounting holes
7
Product Overview
