- Page 1 Crestron ST-PC Dual AC Power Control Module Operations Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. © 2003 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron ST-PC Contents Dual AC Power Control Module: ST-PC Introduction ... 1 Features and Functions... 1 Specifications ... 2 Physical Description... 3 Setup ... 7 Identity Code ... 7 Hardware Hookup ... 7 Programming Software... 9 Earliest Version Software Requirements for the PC ... 9 Programming with SIMPL Windows... -
Page 5: Dual Ac Power Control Module: St-Pc
Operations Guide, the term ST-PC is used for either configuration, except where noted. The ST-PC is a dual power controller that switches AC power on and off at two independent AC sockets mounted on the unit. Each socket is tied to a relay that is able to support a combined load (sockets A and B) of 10 Amp, maximum (6 Amp, maximum, for the STI-PC). -
Page 6: Specifications
AC power is supplied via a 3-wire line cord (no plug on the STI-PC configuration). This power is solely for the purpose of powering the loads attached to the POWER A and B ports. Specifications The following table provides a summary of specifications for the ST-PC module. ST-PC Specifications Power Requirements Default Net ID... -
Page 7: Physical Description
FTP site). Physical Description The ST-PC, shown in the following illustrations, is housed in a black enclosure with labels on the front and rear panels. There are four LEDs on the front panel that indicate the unit’s current status. There are also two momentary pushbutton switches that are used to toggle the relay states. - Page 8 Dual AC Power Control Module ST-PC Physical Views STI-PC Physical Views 4 • Dual AC Power Control Module: ST-PC POWER A 12VDC 1.50 in (3.81 cm) CRESTRON ELECTRONICS INC. N.J. 07626 6.13 in (15.57 cm) 6.32 in (16.05 cm) 6.94 in (17.63 cm)
- Page 9 Crestron ST-PC Ports A number of labeled ports are provided on the back of the ST-PC. Refer to the following illustrations and descriptions. ST-PC Ports STI-PC Ports 12 VDC .5 A This DC power socket connector is used to supply external power via a 500 mA power pack (1000 mA power pack for STI-PC).
- Page 10 POWER IN For the ST-PC, a three-prong plug is used to connect to a three-prong outlet that supplies power. For the STI-PC, an international power cord (approximately six feet in length) is available for connection to an international power plug.
-
Page 11: Setup
Refer to “Setting the Net ID in Device Settings” on page 11 for details of the SIMPL Windows procedure. The Net ID of the ST-PC has been factory set to 2C, The Net IDs of multiple ST- Refer to the note on page 12 for a definition of Viewport. - Page 12 Downloads | Product Manuals | Wiring Diagrams section of the Crestron website (www.crestron.com). Hookup Connections for ST-PC USE ST-CNB (SOLD SEPARATELY) TO Hookup Connections for STI-PC USE ST-CNB (SOLD SEPARATELY) TO 8 • Dual AC Power Control Module: ST-PC Cresnet NOTE: CONNECT ST-PC TO CRESNET. POWER A 12VDC CRESTRON ELECTRONICS INC.
-
Page 13: Programming Software
NOTE: The following assumes that the reader has knowledge of SIMPL Windows. If not, refer to the extensive help information provided with the software. NOTE: The following are file extensions for programs that include an ST-PC, developed for specific control system types: .smw... - Page 14 Net ID of 2C as shown in the following illustration. NOTE: The first ST-PC in a system is preset with a Net ID of 2C when its symbol is dragged into the upper pane of System Views. Additional ST-PC units are assigned different Net ID numbers as they are added.
-
Page 15: Setting The Net Id In Device Settings
Setting the Net ID in Device Settings Double-click the ST-PC icon to open the “Device Settings” window. This window displays the ST-PC device information. If necessary, select the Net ID tab to change the Net ID as shown in the following figure. -
Page 16: Uploading
SIMPL Windows’ Programming Manager. ST-PC SIMPL Windows Symbol The ST-PC provides two discrete AC sockets. The <pwr> inputs supply power to a device for as long as the input is high; when a <pwr> input goes low AC power to the device is turned off. -
Page 17: Communication Settings
Crestron Viewport may be preferred over development tools when uploading programs and projects. NOTE: Firmware for the ST-PC is not field upgradable. The following section defines how to upload a SIMPL Windows program. Before attempting to upload, it is necessary to establish communications. - Page 18 Dual AC Power Control Module 14 • Dual AC Power Control Module: ST-PC 1. Open the Crestron Viewport. Either launch the standalone version of Viewport, or start SIMPL Windows, and from the menu bar, select Tools | Viewport. 2. Refer to the following illustration. From the Viewport menu, select Setup | Communications settings (alternatively, press Alt+D) to open the “Port...
-
Page 19: Uploading A Simpl Windows Program
SIMPL Program check box is enabled. If it does contain SIMPL+ modules, then the SIMPL+ Program(s) check box will also be enabled. Select one or both check boxes and then click Send Program to begin the transfer. Dual AC Power Control Module: ST-PC • 15... -
Page 20: Problem Solving
ST-PC Troubleshooting Unexpected response from control system. 16 • Dual AC Power Control Module: ST-PC “Send Program” Window 4. To verify that the program has been transferred successfully, select Diagnostics | Report Program Information. This should display a window that provides details about the current program loaded into the control system. -
Page 21: Further Inquiries
Future Updates As Crestron improves functions, adds new features, and extends the capabilities of the ST-PC, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision. -
Page 22: Return And Warranty Policies
All brand names, product names, and trademarks are the sole property of their respective owners. Windows is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP and WindowsNT/2000 are trademarks of Microsoft Corporation. 18 • Dual AC Power Control Module: ST-PC Crestron ST-PC... - Page 23 Crestron ST-PC Dual AC Power Control Module This page intentionally left blank. Dual AC Power Control Module: ST-PC • 19 Operations Guide – DOC. 5708A...
- Page 24 Crestron Electronics, Inc. Operations Guide – DOC. 5708A 15 Volvo Drive Rockleigh, NJ 07647 11.03 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
