Summary of Contents for Crestron Green Light DIN-PWS50
- Page 1 Crestron Green Light™ DIN-PWS50 ® DIN Rail 50 Watt Cresnet Power Supply Operations & Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2008 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Future Updates ... 15 Return and Warranty Policies ... 16 Merchandise Returns / Repair Service ... 16 CRESTRON Limited Warranty... 16 Operations & Installation Guide – DOC. 6667A DIN Rail 50 Watt Cresnet ® Power Supply: DIN-PWS50 1 Power Supply Contents • i... -
Page 5: Crestron Green Light™ Din Rail 50 Watt Cresnet ® Power Supply: Din-Pws50
Crestron Green Light™ DIN Rail 50 Watt Cresnet Power Supply: DIN-PWS50 Introduction The DIN-PWS50 is a 50 Watt Cresnet to snap onto a standard DIN rail for installation in a wall mount enclosure. DIN rail mounting enables modular installation alongside ®... -
Page 6: Applications
DIN Rail 50 Watt Cresnet Applications The following diagram shows a DIN-PWS50 in a typical application. DIN-PWS50 in a Typical Application 2 • DIN Rail Power Supply: DIN-PWS50 Power Supply Crestron DIN-PWS50 Operations & Installation Guide – DOC. 6667A... -
Page 7: Specifications
Crestron DIN-PWS50 Specifications Specifications for the DIN-PWS50 are listed in the following table. DIN-PWS50 Specifications SPECIFICATION Output Power Per Output Port Module Total Ripple/Noise Power Requirements Environmental Temperature Humidity Heat Dissipation Enclosure Dimensions Height Width Depth Weight Available Accessories DIN-BLOCK DIN-HUB Operations &... -
Page 8: Physical Description
DIN Rail 50 Watt Cresnet Physical Description This section provides information on the connections, controls and indicators available on your DIN-PWS50. DIN-PWS50 Physical View 4 • DIN Rail Power Supply: DIN-PWS50 Power Supply Crestron DIN-PWS50 Operations & Installation Guide – DOC. 6667A... - Page 9 DIN-PWS50 Overall Dimensions 106 mm (4.18 in) Operations & Installation Guide – DOC. 6667A DIN Rail 50 Watt Cresnet 90 mm (3.55 in) 94.2 mm (3.71 in) DIN Rail Power Supply: DIN-PWS50 • 5 Power Supply 58 mm (2.29 in)
-
Page 10: Connectors*, Controls
CONNECTORS*, CONTROLS & INDICATORS 100-240V~50/60Hz 24VDC FUSE * Interface connectors for NET ports are provided with the unit. 6 • DIN Rail Power Supply: DIN-PWS50 Power Supply Crestron DIN-PWS50 DESCRIPTION (2) Sets of (3) captive screw terminals, each set paralleled... -
Page 11: Industry Compliance
This unit has been manufactured to comply with UL’s Standards for Safety in Canada and the United States. Formal approval is pending. As of the date of manufacture, the DIN-PWS50 has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. -
Page 12: Setup
For more details, refer to “Check Network Wiring” which starts on page Installation The DIN-PWS50 must be installed by a licensed electrician, in accordance with all national and local codes. CAUTION: This equipment is for indoor use only. Mount in a well ventilated area. - Page 13 Installing the DIN-PWS50 DIN RAIL RELEASE 1. Place the top of the DIN-PWS50’s rail mount over the top of the DIN rail. 2. Tilt the bottom of the DIN-PWS50 toward the DIN rail until it snaps into place.
-
Page 14: Hardware Hookup
NOTE: Use copper wire only. For high-voltage connections, use wire rated for at least 75º C (167º F). NOTE: Ensure the unit is properly grounded. When making network connections to the DIN-PWS50, use a Crestron power supply. 10 • DIN Rail Power Supply: DIN-PWS50... - Page 15 POWER LINE FUSE IS LOCATED UNDER THIS COVER Operations & Installation Guide – DOC. 6667A DIN Rail 50 Watt Cresnet POWER TO OTHER DEVICES TO CONTROL SYSTEM AND OTHER CRESNET DEVICES DIN Rail Power Supply: DIN-PWS50 • 11 Power Supply NET:...
- Page 16 DIN Rail 50 Watt Cresnet Fuse If the DIN-PWS50 does not power up when it is plugged into an AC Replacement outlet, the fuse may need to be replaced. The fuse holder is located on the front panel, under the cover in the lower left corner. To replace the fuse: 1.
-
Page 17: Problem Solving
250 V, 3.15 A, time lag, ceramic cartridge). Refer to “Fuse Replacement” on page 12. Output is Disconnect all output short-circuited. connectors. LED will light if problem was a short circuit on output. DIN Rail Power Supply: DIN-PWS50 • 13 Power Supply CORRECTIVE ACTION... -
Page 18: Check Network Wiring
(18 AWG) Crestron Certified Wire and drawing 20 watts should not have a length of run more than 101 meters (333 feet). Cresnet HP cannot be used. 14 • DIN Rail Power Supply: DIN-PWS50 Power Supply Where: L = Length of run (or chain) in feet R = 6 Ohms (Crestron Certified Wire: 0.75 MM (18 AWG)) -
Page 19: Further Inquiries
Future Updates As Crestron improves functions, adds new features and extends the capabilities of the DIN-PWS50, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision. -
Page 20: Return And Warranty Policies
All brand names, product names and trademarks are the sole property of their respective owners. Windows is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP/Vista and WindowsNT/2000 are trademarks of Microsoft Corporation. 16 • DIN Rail Power Supply: DIN-PWS50 Power Supply Crestron DIN-PWS50 Operations &... - Page 21 ® Crestron DIN-PWS50 DIN Rail 50 Watt Cresnet Power Supply This page is intentionally left blank. DIN Rail Power Supply: DIN-PWS50 • 17 Operations & Installation Guide – DOC. 6667A...
- Page 22 ® DIN Rail 50 Watt Cresnet Power Supply Crestron DIN-PWS50 This page is intentionally left blank. 18 • DIN Rail Power Supply: DIN-PWS50 Operations & Installation Guide – DOC. 6667A...
- Page 23 ® Crestron DIN-PWS50 DIN Rail 50 Watt Cresnet Power Supply This page is intentionally left blank. DIN Rail Power Supply: DIN-PWS50 • 19 Operations & Installation Guide – DOC. 6667A...
- Page 24 Crestron Electronics, Inc. Operations & Installation Guide – DOC. 6667A 15 Volvo Drive Rockleigh, NJ 07647 (2020749) Tel: 888.CRESTRON 05.08 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
