Crestron GLA-PWSI50 Installation Manual

Functional Summary
The GLA-PWSI50 is a 50 Watt Cresnet
designed for use with a Crestron
or anywhere a wall-mountable Cresnet power supply is
needed. It is compatible with any line voltage from 100 to
240 Volts, 50 or 60 Hz.
The GLA-PWSI50 mounts conveniently over the front of
an electrical box, with all connections made inside the
box via flying leads using terminal block connectors. An
adapter plate is included for installation over a 1 or
2-gang UK or Euro style electrical box. Without the
adapter plate, the GLA-PWSI50 may be mounted over a 4
inch square or 2-gang US electrical box.
•
50 Watt Cresnet power supply
•
Powers the IPAC and other Cresnet devices
•
Provides backup power for Crestron Green Light
cabinets
•
Compatible with 100 to 240 VAC mains
•
Mounts to a 1 or 2-gang UK (BS 4662) or Euro
(DIN 49073) electrical box
•
Also compatible with 4 inch square or 2-gang US
electrical boxes
GLA-PWS50 (shown with Adapter Plate) Physical View
Crestron Electronics, Inc.
15 Volvo Drive Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576
www.crestron.com
®
Power Supply
®
Green Light™ system,

Specifications

GLA-PWSI50 Specifications
SPECIFICATION
Output Power
Output Power
Ripple/Noise
Power Requirements
Input
Enclosure
Environmental
Temperature
Humidity
Heat Dissipation
Dimensions
(without adapter plate)
Height
Width
Depth
Weight
Installation Guide – DOC. 6747A
GLA-PWSI50
DETAILS
50 Watts (2.1 Amps) @ 24 Volts
DC, regulated, limited power
source
<1%
0.6 Amps @ 100-240 Volts AC,
50/60 Hz
Metal construction, 1- or 2-gang
(BS4662 UK or DIN 49073)
backbox, includes adapter plate
0° to 40°C (32° to 104°F)
10% to 90% RH
(non-condensing)
26 BTU/Hr
10.16 cm (4.00 in)
14.09 cm (5.55 in)
5.76 cm (2.27 in)
0.54 kg (1.2 lbs)
(2022674)
02.09
Specifications subject to
change without notice.
