Crestron CSA-PWS10S-HUB Installation Manual

Introduction
The CSA-PWS10S-HUB power supply provides support for up to 10 Crestron
5-segment hub with network diagnostics capabilities. Local controls and indicators allow for easy testing of shades
without connecting to a control system. The CSA-PWS10S-HUB is convection cooled for silent operation and can
be surface mounted. It is also available pre-assembled in a CAEN-1X1 enclosure, model
CSA-PWS10S-HUB-CAEN-1X1, which can be surface mounted or recessed in a wall.
CSA-PWS10S-HUB Specifications
SPECIFICATION
Load Rating
Total Shades Supported
Output
Load Protection
Power Requirements
Environmental
Installation Location
Temperature
Humidity
Enclosure
CSA-PWS10S-HUB
CSA-PWS10S-HUB-
CAEN-1X1
Dimensions
CSA-PWS10S-HUB
Height
Width
Depth
CSA-PWS10S-HUB-
CAEN-1X1
Height
Width
Depth
Weight
CSA-PWS10S-HUB
CSA-PWS10S-HUB-
CAEN1x1
(Continued on the following page)
Crestron Electronics, Inc.
15 Volvo Drive Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576
www.crestron.com
Provides power for up to (10) Crestron shades, each homerun to the power
supply
24 Vdc
50 W per output LPS
350 W total continuous load
425 W for 2 minute on 2 minute off discontinuous shade load
(10) Self resetting thermal fuses and (10) 4 A time lag fuses, Littelfuse JDYX2
0213 004 MXP (5 x 20 mm, 250 V, 4 A, time lag, cartridge) provided for each
50 W segment, (1) of each per output
120–240 Vac, 50/60 Hz;
5 A maximum
Indoor use only
32º to 104ºF (0º to 40ºC)
10% to 90% RH (non-condensing)
Metal, gray, surface mount (indoor use only)
Includes CAEN-1X1, 16 gauge galvanized steel enclosure with vented gray steel
cover, surface mount or recessed in a wall (indoor use only)
7 9/16 in (194 mm)
12 15/16 in (330 mm)
2 11/16 in (68 mm)
16 9/16 in (421 mm)
16 1/8 in (409 mm)
4 7/16 in (113 mm)
5.6 lb (2.6 kg)
15.0 lb (6.8 kg)
CSA-PWS10S-HUB
®
shades and features a built-in,
DETAILS
Installation Guide – DOC. 7438C
Specifications subject to
change without notice.
(2037987)
06.14
