- Page 1 Crestron C2N-SPWS300 System Power Supply Operations Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2003 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Rack Mounting ...11 Hardware Hookup...11 Programming Software ...14 C2Net-Device Slot in Configuration Manager ...15 Setting the Net ID in Device Settings ...15 C2N-SPWS300 Symbol in Programming Manager ...16 Example Program ...18 Uploading and Upgrading...19 Communication Settings...19 Uploading a SIMPL Windows Program ...21 Firmware Upgrade ...23... -
Page 5: System Power Supply: C2N-Spws300
Introduction Features and Functions The C2N-SPWS300 is a 300-watt system power supply designed for large Cresnet control systems (herein referred to as Cresnet system). It operates with an input of 100 to 240 VAC, 4A (maximum) and a noise rating less than 150mV. - Page 6 PWR ON position. PWR ON Position In the PWR ON position, the C2N-SPWS300 acts as a stand-alone system. All of the green LEDs illuminate successively as power is applied to each channel (1 through 8) until all eight channels are powered up.
-
Page 7: Specifications
Weight 5.3 lb (2.4 kg) The C2N-SPWS300 ships with two cable assemblies; one for domestic use and the other for international use or installation within the Crestron CAEN. The latest versions can be obtained from the Downloads | Software Updates section of the Crestron website (www.crestron.com). -
Page 8: Physical Description
Ports With the exception of the IEC320 connector on a pigtail cord (for application of AC power), all connections to the C2N-SPWS300 are made via the ports on the front panel. The single four-pin network connector in the upper right corner on the front panel is used to accept 24 VDC when the power switch is set to the PWR OFF SLAVE position. - Page 9 3.29 in (8.36 cm) Each power supply channel (1 through 8) has a green LED (PWR), which illuminates when 24V is present at that output. A red LED (OVLD) for each channel illuminates when there has been a short circuit or the load exceeds the nominal 75 watts for any channel.
-
Page 10: Industry Compliance
Refer to “Method B (Touch Settable IDs)” on page 9 for detailed information. Industry Compliance As of the date of manufacture, the C2N-SPWS300 has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling (N11785) NOTE: This device complies with part 15 of the FCC rules. -
Page 11: Network Wiring
R = Resistance (refer to table below). L = Length of run (or chain) in feet. PF = Power factor of entire run (or chain). RESISTANCE (R) WIRE GAUGE Doubled CAT5 Tripled CAT5 System Power Supply: C2N-SPWS300 • 7 System Power Supply... -
Page 12: Identity Code
System Power Supply Identity Code NOTE: The C2N-SPWS300 can be polled in Cresnet while the power switch is in either position as long as the appropriate data signal (Y & Z) connections are made to any of the 17 NET connectors on the power supply. - Page 13 9. In the Current Network Devices text window, verify the new NET ID code. 10. In the "Set Network ID" window, click Close. 11. Repeat this procedure for each C2N-SPWS300 to be added to the network. Ensure that all C2N-SPWS300s are connected to the control system.
- Page 14 Alpha characters in serial numbers or TSID numbers may be entered in upper or lower case. 10 • System Power Supply: C2N-SPWS300 is similar to the report produced by pressing F4 (Report Network Devices); the first eight digits of each line constitute the TSID number (hexadecimal form of the serial number).
-
Page 15: Rack Mounting
(Crestron Rack Mounting Kit – sold separately). Hardware Hookup By design, the C2N-SPWS300 is rated to withstand elevated operating temperatures (internal temperatures can reach 122°F (50°C)). Therefore, the unit should be used in a well-ventilated area. The venting holes should not be obstructed under any circumstances. -
Page 16: Operations Guide - Doc
C2N-SPWS300 (PWR ON Position), Hardware Hookup NOTE: Never connect multiple C2N-SPWS300s in parallel. NOTE: Always disconnect AC power to the C2N-SPWS300 supplying power to a Cresnet system before connecting a network unit to that system or installing a card in the control system. - Page 17 Crestron C2N-SPWS300 C2N-SPWS300 (PWR OFF SLAVE Position), Hardware Hookup Hookup Procedure Operations Guide – DOC. 8190 C2N-SPWS300 24 Y Z G HOME RUN METHOD POWER EXPANSION (NETWORK DATA LINK TO EXPANSION POWER SUPPLY, C2NSPWS300 OR CNPWS-75) DAISY CHAIN METHOD 1. Connect each network unit to the appropriate network connector.
-
Page 18: Programming Software
NOTE: The following are acceptable file extensions for programs that include a “Further Inquiries” on page 26 for assistance. C2N-SPWS300, developed for specific control system types: SIMPL (Symbol Intensive Master Programming Language) Windows is Crestron's software for programming Crestron control systems. It provides a well-designed graphical environment with a number of workspaces (i.e., windows) in which a... -
Page 19: C2Net-Device Slot In Configuration Manager
NET ID of 15 as shown in the following illustration. NOTE: The first C2N-SPWS300 in a system is preset with a NET ID of 15 when its symbol is dragged into the upper pane of System Views. Additional units are assigned different NET ID numbers as they are added. -
Page 20: C2N-Spws300 Symbol In Programming Manager
C2N-SPWS300 Symbol in Programming Manager Programming Manager is where programmers “program” a Creston control system by assigning signals to symbols. The following diagram shows the C2N-SPWS300 symbol in the SIMPL Windows’ Programming Manager. Detail View of the C2N-SPWS300 in SIMPL Windows’ Programming Manager 16 •... - Page 21 Operations Guide – DOC. 8190 Digital = Blue Analog = Red Serial = Black Undefined/Other = Green -1). This 16-bit property makes analog signals useful for System Power Supply: C2N-SPWS300 • 17 System Power Supply...
-
Page 22: Example Program
Digital Input Signal Descriptions Analog Output Signal Descriptions Example Program An example program for the C2N-SPWS300 is available from the Crestron FTP site (ftp://ftp.crestron.com/Examples). Search for the file C2NSPWS300.ZIP that contains the example program, associated files and a README.TXT file that describes the program. -
Page 23: Uploading And Upgrading
The following sections define how one would upload a SIMPL Windows program or upgrade the firmware of the C2N-SPWS300. However, before attempting to upload or upgrade, it is necessary to establish communications. Communication Settings NOTE: For laptops and other PCs without a built-in RS-232 port, Crestron recommends the use of PCMCIA cards, rather than USB-to-serial adapters. - Page 24 System Power Supply Typical Connection Diagram when Uploading a Project Setup | Communications Settings Command 20 • System Power Supply: C2N-SPWS300 1. Open the Crestron Viewport. Either launch the stand-alone version of Viewport, or start SIMPL Windows and from the menu bar, select Tools | Viewport.
-
Page 25: Uploading A Simpl Windows Program
2. Select File | Open to view the “Open” window, navigate to the SIMPL Window file (.smw), and click Open. 3. Select Project | Transfer Program. 1. Verify that the procedure for “Communication Settings” that begins on page 19 has been performed. System Power Supply: C2N-SPWS300 • 21 System Power Supply... - Page 26 NOTE: Refer to the respective Operations Guide for the control system for details about the other fields shown on the “Send Program” window. “Send Program” Window 22 • System Power Supply: C2N-SPWS300 2. As shown after this step, select File Transfer | Send Program (alternatively, press Alt+P) from the Viewport menu.
-
Page 27: Firmware Upgrade
Crestron C2N-SPWS300 Firmware Upgrade A firmware upgrade file has the To take advantage of all the C2N-SPWS300 features, it is important that the unit extension .csf. contains the latest firmware available. Therefore, please check the Crestron website (http://www.crestron.com/downloads/software_updates.asp) for the latest version of firmware. - Page 28 System Power Supply Crestron C2N-SPWS300 “Open” Window 4. Browse to the desired .upg file and click Open to begin the transfer. 24 • System Power Supply: C2N-SPWS300 Operations Guide - DOC. 8190...
-
Page 29: Problem Solving
LED (OVRLD) is illuminated. Some network units are not receiving power. * Track Temp_Warning (digital output signal) from the C2N-SPWS300 symbol. This signal returns to its low Operations Guide – DOC. 8190 POSSIBLE TROUBLE CAUSE(S) C2N-SPWS300 is not receiving power. -
Page 30: Further Inquiries
System Power Supply Further Inquiries If, after reviewing this Operations Guide for the C2N-SPWS300, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team in your area. Dial one of the following numbers. -
Page 31: Return And Warranty Policies
All brand names, product names, and trademarks are the sole property of their respective owners. Windows is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP and WindowsNT/2000 are trademarks of Microsoft Corporation. Operations Guide – DOC. 8190 System Power Supply System Power Supply: C2N-SPWS300 • 27... - Page 32 Crestron Electronics, Inc. Operations Guide – DOC. 8190 15 Volvo Drive Rockleigh, NJ 07647 06.03 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
