Crestron CSA-PWS300-CAEN Installation Manual

Introduction
The CSA-PWS300-CAEN and CSA-PWS600-CAEN are
wall-mounted power supplies that use one or two
C2N-SPWS300 power supplies.
The power supply provides regulated 24 volt DC, 300
Watt power to shade components. It operates with an
input of 100 to 240 VAC, 4 A (maximum) and a noise
rating of less than 150 mV. The power supply is capable
of delivering a nominal 75 Watts of power at 24 Volts
DC on any of its eight channels. Each channel is
accessed at the front panel of the unit via Cresnet
connectors. Outputs are limited to 75 Watts (3.125 Amps
typical) by an electronic circuit breaker. Each output
connector also has Cresenet Y-Z signals. All Cresnet
signals are parallel.
For simplicity within this guide, the term
"CSA-PWS300/600-CAEN" is used except where noted.
Functional Summary
• One (CSA-PWS300-CAEN) or two
(CSA-PWS600-CAEN) 24 Volt, 300 Watt
Cresnet power supplies
• Eight output channels per power supply (each
with 75 W rating) monitored and controlled by a
Cresnet port
• Power switch allows for single-point shutdown
• Ventilated cover for convection cooling of
modules encased in enclosure
• Conveniently located electrical knockouts for
both Class 1 and Class 2 wiring
• 16 gauge hot dipped galvanized steel enclosure
CSA-PWS300/600-CAEN Specifications
SPECIFICATION
Input Power
Output Voltage
Environmental
Installation Location
Temperature
Humidity
Weight
(Continued in following column)
Crestron Electronics, Inc.
15 Volvo Drive Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576
www.crestron.com
®
type
DETAILS
100 VAC to 240 VAC,
4 A, 50/60 Hz
24 VDC (regulated)
Indoor use only
41º to 104º F
(5º to 40º C)
10% to 90% RH
(non-condensing)
C2N-PWS300: 20 lbs
(9.1 kg)
C2N-PWS600: 25 lbs
(11.4 kg)
CSA-PWS300/600-CAEN
CSA-PWS300/600-CAEN Specifications (Continued)
SPECIFICATION
Controls
Power On, (1) Rocker switch; selects
Power Off, "SLAVE" mode to allow
Slave
enabling the power supply
system remotely by applying
an external 24V DC signal to
the NET port
Reset 1-8 (8) Miniature push buttons;
each resets its respective
output channel, or momentarily
disables the channel while
held
System Reset (1) Miniature push button;
resets all output channels
sequentially, or momentarily
disables all channels while
held
Setup Not used
LED Indicators
PWR 1-8 (8) Green LEDs, indicate
24 VDC power present at each
channel output
OVRLD 1-8 (8) Red LEDs indicate a load
in excess of 75 watts on a
given channel, channel output
disabled
SYSTEM (1) Red LED, indicates a total
OVRLD load in excess of 300 Watts on
the power supply system, all
channels disabled
PWR (1) Green LED, indicates
power supply system is
enabled
NET (1) Yellow LED, indicates
communication with Cresnet
network
SETUP Not used
Installation Guide – DOC. 7407A
DETAILS
(2034068)
08.12
Specifications subject to
change without notice.
