Functional Summary
The GLA-PWS50 is a 50 Watt Cresnet
designed for use with a Crestron
or anywhere a wall-mountable Cresnet power supply is
needed. The GLA-PWS50 mounts conveniently over a 4"
square or 2-gang electrical box. All connections are made
inside the electrical box via flying leads using twist-on
wire connectors. A partition is included to isolate high
voltage from Class 2 wiring within the box.
•
50 Watt Cresnet power supply
•
Powers the IPAC and other Cresnet devices
•
Provides backup power for Crestron Green Light
cabinets
•
Mounts to a 4" square or 2-gang electrical box
GLA-PWS50 Physical View
Crestron Electronics, Inc.
15 Volvo Drive Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576
www.crestron.com
®
Power Supply
®
Green Light™ system,
Specifications
GLA-PWS50 Specifications
SPECIFICATION
Output Power
Output Power
Ripple/Noise
Power Requirements
Input
Enclosure
Environmental
Temperature
Humidity
Heat Dissipation
Dimensions
Height
Width
Depth
Weight
Installation Guide – DOC. 6734B
GLA-PWS50
DETAILS
50 Watts (2.1 Amps) @ 24 Volts
DC, regulated, limited power
source
<1%
1.0 Amp @ 100-240 Volts AC,
50/60 Hz
Metal construction, mounts to a
4-inch square or 2-gang
electrical box, includes low-
voltage partition
32° to 104°F (0° to 40°C)
10% to 90% RH
(non-condensing)
26 BTU/Hr
4.00 in (10.16 cm)
5.55 in (14.09 cm)
2.27 in (5.76 cm)
1.2 lbs (0.54 kg)
(2022081)
04.09
Specifications subject to
change without notice.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Crestron GLA-PWS50
Summary of Contents for Crestron GLA-PWS50
-
Page 1: Specifications
Crestron Green Light™ system, or anywhere a wall-mountable Cresnet power supply is needed. The GLA-PWS50 mounts conveniently over a 4” square or 2-gang electrical box. All connections are made inside the electrical box via flying leads using twist-on wire connectors. -
Page 2: Industry Compliance
This product is Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc. As of the date of manufacture, the GLA-PWS50 has been tested and found to comply with specifications for CE marking. NOTE: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 3 Crestron GLA-PWS50 50 Watt Cresnet Power Supply Application The following diagram shows a GLA-PWS50 module in a typical application. GLA-PWS50 in a Lighting Application Wall Mount 50 Watt Cresnet Power Supply: GLA-PWS50 • 3 Installation Guide – DOC. 6734B...
-
Page 4: Physical Description
GLA-PWS50 Overall Dimensions 5.55 in (14.09 cm) 4.00 in (10.16 cm) 5.03 in (12.77 cm) GLA-PWS50 4 • Wall Mount 50 Watt Cresnet Power Supply: GLA-PWS50 Connectors, Controls & Indicators 2.15 in 0.12 in (5.45 cm) (0.31 cm) Setup Important Notes Read before installation. -
Page 5: Hardware Hookup
• • Fuse Replacement If the GLA-PWS50 does not power up when it is connected to line power, the fuse may need to be replaced. The fuse holder is located on the right side of the power supply (next to the LED). To replace the fuse: 1. -
Page 6: Problem Solving
Crestron products. First-time users will need to establish a user account to fully benefit from all available features. 6 • Wall Mount 50 Watt Cresnet Power Supply: GLA-PWS50 Return and Warranty Policies Merchandise Returns / Repair Service CORRECTIVE...
